- Page 1 Installation Instruction Roller Blind (Fascia) Clutch Operation Type 5-151 REV 01 August`11...
- Page 2 Installation Place the clutch (with short chain) in the bracket 1 ... until it snaps into the bracket. If there is no leveller Fix the chain outlet set with the screws provided. option you can continue with installing of the lower and slide it down until it clicks 2.
- Page 3 Install the lower leveller and roller blind after hori- Slide the end caps onto the brackets. Slide a screw driver between bearing plug and zontal adjusting of the upper blind. The integrated bracket and push the bearing in the clutch direc- leveller is already installed in the bracket.
- Page 4 Inside: Place a screw driver under the pin of the clutch and pull it outwards. Take the clutch out of the bracket. Loosen the screws of the chain outlet set and remove the upper clutch in the same way. REV 01 August`11...
