  • Page 1 8-Port Managed Industrial Ethernet Switch ISW-800M User's Manual...

  • Page 2: Fcc Warning

    Copyright ○ PLANET Technology Corp. 2006. Contents subject to which revision without prior notice. PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose.

  • Page 3: Table Of Contents

    1. INTRODUCTION ... 5 1.1 Packet Contents ... 5 1.2 How to Use This Manual ... 5 1.3 Product Feature... 5 1.4 Product Specification... 6 2. HARDWARE INSTALLATION ... 9 2.1 Product Description ... 9 2.2 Mounting Installation ... 14 3.
  • Page 4 4.12 IP Configuration... 35 4.13 SNTP Configuration ... 36 4.14 IP Security ... 38 4.15 RSTP Configuration ... 39 4.16 Redundant Ring ... 41 4.17 QoS Configuration... 43 4.18 IGMP ... 44 4.19 SNMP Configuration... 45 4.20 Security Manager ... 46 4.21 Configuration Backup...

  • Page 5: Introduction

    The 8-Port 10/100TX with redundant ring Web management industrial switch is a cost- effective solution and meets the high reliability requirements demanded by industrial applications. The switch can be easily managed through the Web GUI. It also provides the redundant ring function that can prevent the network connection failure.

  • Page 6: Product Specification

    E-mail event alert ▫ IP security for illegal access prevention ▫ TFTP firmware upgrade ▫ Port mirror transmission monitoring 1.4 Product Specification Model ISW-800M Hardware Standard IEEE 802.3af, IEEE 802.3, IEEE802.3u, 10/100Base-TX 10/100Mbps TP Protocol CSMA/CD Switching Architecture Store and forward...
  • Page 7 MAC address Memory Buffer 1Mbit Network Cable 10Base-T : 2-pair UTP/STP Cat 3, 4, 5 cable 100Base-TX: 2-pair UTP/STP Cat. 5 cable 10Base-T: EIA/TIA-568 100-ohm (100m) Per port: Link/Activity (Green), Full duplex/Collision (Yellow) Per unit: Power (Green), Power 1 (Green), Power 2 (Green), Fault (Yellow), Master (Green) Back-plane 1.6Gbps...
  • Page 8 128kbps, 256Kbps, 512Kbps, 1MB, 2MB, 4MB, and 8MB. Ingress filter packet type combination rules are Broadcast/Multicast/Unknown Unicast packet, Broadcast/Multicast packet, Broadcast packet only and all of packet. The packet filter rate can be set follow as:1Mbps、2Mbps、4Mbps、 8Mbps、16Mbps、32Mbps、64Mbps. Port mirror Support TX packet only or both of TX and RX packet. Packet filter 4 selection rules for different type of packet combination: IEEE 802.3 10Base-T Ethernet...

  • Page 9: Hardware Installation

    2. HARDWARE INSTALLATION This section describes the functionalities of the Switch's components and guides how to install it on the rack or mount to the wall. Basic knowledge of networking is assumed. Please read this chapter completely before continuing. 2.1 Product Description The PLANET Management Industrial Ethernet Switch provides substation hardened, fully managed, Ethernet switches specifically designed to operate reliably in electrically and environmentally harsh environments.

  • Page 10: Led Indications

    Green R. M. (Ring Master) LNK/ACT Green (Port 7 & 8) Blinks Figure 2-1 ISW-800M Front Panel Meaning The switch unit is power on. The switch unit is no power input. Power on No power inputs Power on No power inputs...

  • Page 11: Reset Button

    Yellow FDX/COL Blinks (Port 7 & 8) 2.1.4 Reset Button The reset button provides user a quick and easy way to restart and set the configuration back to default value. Restart: press the button for 2 seconds and release. 。 Set to factory default value: press the button for 5 seconds and release.

  • Page 12: Wiring The Power Inputs

    2. Please restart the switch after the Redundant ring DIPswitch is set. 2.1.6 Switch Bottom Panel The bottom panel of the ISW-800M consists one terminal block connector within two DC power inputs and one DC IN power jack for extra AC/DC power adapter.

  • Page 13: Wiring The Fault Alarm Contact

    1. Insert the positive and negative wires into the V+ and V- connector on the terminal block connector. 2. To tighten the wire-clamp screws for preventing the DC wires to loose. Power Notice: The wire range of terminal block is from 12~ 24 AWG. 2.1.8 Wiring the Fault Alarm Contact The fault alarm contact is in the middle of terminal block connector as below figure shows.

  • Page 14: Mounting Installation

    Fault Alarm Contact The open circuit will form when the power failure or port link failure. 24V DC Buzzer 24V Battery The fault alarm device will send a warning signal t warn the user, ex: alarm sound or flash light. 2.2 Mounting Installation This section describes how to install the Ethernet Switch and make connections to it.

  • Page 15: Wall Mount Plate Mounting

    Step2: Lightly push the button of DIN-Rail into the track. Step3: Check the DIN-Rail is tightly on the track. Step4: To remove the industrial switch from the track, reverse steps above. 2.2.2 Wall Mount Plate Mounting To install the switch on the wall, please follows the instructions described below. Step1: Remove the DIN-Rail from the industrial switch;...
  • Page 16 Step3: Use the screws to screw the wall mount plate on the industrial switch. Step4: Use the hook holes at the corners of the wall mount plate to hang the industrial switch on the wall. Step5: To remove the wall mount plate, reverse steps above.

  • Page 17: Network Installation

    3.1 Hardware Installation In this paragraph, we will describe how to install the 8-Port 10/100TX with redundant ring Web management industrial switch and the installation points for attention. Unpacked the Industrial switch. Check the DIN-Rail is screwed on the Industrial switch. If the DIN-Rail is not screwed on the Industrial switch.

  • Page 18: Redundant Ring Application

    3.3 Redundant Ring Application The industrial switch supports the redundant ring protocol that can help your network system to recovery from network connection failure within 300ms or less, and make your network system more reliable. The redundant ring algorithm is like as spanning tree protocol (STP) algorithm but it has faster recovery time than STP.

  • Page 19: Coulping Ring Application

    3.4 Coulping Ring Application In the network, it may have more than one redundant ring group. By using the coupling ring function can connect each redundant ring for the redundant backup. It can ensure the transmissions between two ring groups will no failure. The following figure is a sample of coupling ring application.

  • Page 20: Dual Homing Application

    3.5 Dual Homing Application Dual Homing function is to prevent the connection lose between redundant ring group and upper level/core switch. Assign two ports to be the Dual Homing ports that one is working port and one is backup port in the redundant ring group. The backup port that has smaller MAC address value will be selected by switch automatically.

  • Page 21: Web Management

    This section introduces the configuration and functions of the Web-Based management. The following configuration steps are based on the firmware version 1.00. 4.1 About Web-based Management Inside the CPU board of the switch exists an embedded HTML web site residing in flash memory. It offers advanced management features and allow users to manage the switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer.

  • Page 22: Port Status

    4.4 Port Status In Port status, you can view every port status that depended on user's setting and the negotiation result. 。 Port: the port number. 。 Type: the speed mode, ex: 100TX = 100Mbps. 。 Link: "Down" is "No Link". "UP" is "Link". 。...

  • Page 23: Single Port Information

    4.5 Single port information You can click the port on the Panel figure on the left side of web GUI. Then, the single port information window will pop up and display the port current status information. Port information interface 4.6 Port Statistics The following information provides a view of the current port statistic information.

  • Page 24: Port Control

    to clean all counts. 4.7 Port Control You can change the port status. Select the port by scroll the Port column. State: disable or enable control of his port. Negotiation: you can set auto negotiation mode is Auto, Nway (specify the speed/duplex on this port and enable auto-negotiation), or Force.

  • Page 25: Switch Settings

    4.8 Switch Settings You can assign the system name and location and view the system information. 。 System Name: assign the name of switch. The maximum length is 64 bytes. 。 System Location: assign the switch physical location. The maximum length is 64 bytes. 。...

  • Page 26: Port Mirroring

    Remember to execute the "Save Configuration" action, otherwise the new configuration will lose [NOTE] when the switch power off. 4.9 Port Mirroring The Port mirroring is a method for monitor traffic in switched networks. Traffic through ports can be monitored by one specific port. That is, traffic goes in or out monitored ports will be duplicated into mirror port.

  • Page 27: Vlan Configuration

    Port Mirroring intrerface 4.10 VLAN configuration A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast domain. It allows you to isolate network traffic so only members of the VLAN receive traffic from the same VLAN members. Basically, creating a VLAN from a switch is logically equivalent of reconnecting a group of network devices to another Layer 2 switch.
  • Page 28 4.10.1 Port-based VLAN Packets can go among only members of the same VLAN group. Note all unselected ports are treated as belonging to another single VLAN. If the port-based VLAN enabled, the VLAN-tagging is ignored. In order for an end station to send packets to different VLANs, it itself has to be either capable of tagging packets it sends with VLAN tags or attached to a VLAN-aware bridge that is capable of classifying and tagging the packet with different VLAN ID based on not only default PVID but also other information about the packet, such as the protocol.
  • Page 29 You will see the VLAN group displays. If the groups' list is more than one page, you can click button to delete unwanted VLAN. button to modify existing VLAN group. Remember to execute the "Save Configuration" action, otherwise the new configuration will lose [NOTE] when the switch power off.
  • Page 30 4.10.2.1 Basic Click button. Management VLAN ID: it is used for remote management security. Only the port of VLAN group ID is equal to the Management VLAN ID can remote management that include telnet, SNMP, and Web browse the switch. Fill the specific VLAN ID number in Management VLAN ID column and mark the check box, and then click VLAN ID is 101, the VLAN group ID 101 includes the port 1, 2, and 4.
  • Page 31 802.1Q VLAN – Add interface Click . Then you will see the page as follow.

  • Page 32: Alert

    To set the outgoing frames are VLAN-Tagged frames or untagged. Then click 。 Tag: outgoing frames with VLAN-Tagged. 。 Untag: outgoing frames without VLAN-Tagged. : Configure port VID settings 4.10.2.2 Port VID Port VLAN ID: enter the port VLAN ID. Click To reset back to default value, click 802.1q VLAN - Port VLAN ID interface...

  • Page 33: Event Configuration

    user. You can set up the mail server IP, mail account, and forwarded email account for receiving the event alert. Email Alert: enable or disable the email alert function. SMTP Server IP Address: set up the mail server IP address. Authentication: mark the check box to enable and configure the email account and password for authentication.

  • Page 34: Power Alarm Configuration

    alert to the dedicate SMTP server. Power status: when the device power status has changed, the system will send out the alert to the dedicate SMTP server. SMNP Authentication Failure: when the SNMP authentication fail, the system will send out the alert to the dedicate SMTP server.

  • Page 35: Ip Configuration

    4.12 IP Configuration Power alarm function enables the Relay alarm action. Without enabling power alarm function, the Relay alarm action will not work even the Relay alarm is set. Mark the check box and click ■ DHCP Client: Enable or Disable the DHCP client function. When DHCP client function is enabling, the industrial switch will be assigned the IP address from the network DHCP server.

  • Page 36: Sntp Configuration

    4.13 SNTP Configuration You can configure the SNTP (Simple Network Time Protocol) settings. The SNTP allows you to synchronize switch clocks in the Internet. SNTP Client: enable or disable SNTP function to get the time from the SNTP server. UTC Timezone: set the switch location time zone. The following table lists the different location time zone for your reference.
  • Page 37 ALA - Alaskan Standard HAW - Hawaiian Standard Nome, Alaska CET - Central European FWT - French Winter MET - Middle European MEWT - Middle European Winter SWT - Swedish Winter EET - Eastern European, USSR Zone BT - Baghdad, USSR Zone 2 ZP4 - USSR Zone 3 ZP5 - USSR Zone 4 ZP6 - USSR Zone 5...

  • Page 38: Ip Security

    4.14 IP Security IP security function allows you to assign 10 specific IP addresses that have permission to access the switch through the web browser for the securing switch management. Enable the IP Security: mark the check box to enable the IP security function. Security IP 1 ~ 10: you can assign up to 4 specific IP address.

  • Page 39: Rstp Configuration

    4.15 RSTP Configuration The Rapid Spanning Tree Protocol (RSTP) is an evolution of the Spanning Tree Protocol and provides for faster spanning tree convergence after a topology change. The system also supports STP and the system will auto detect the connected device that is running STP or RSTP protocol. 4.15.1 System Configuration You can view spanning tree information about the Root Bridge.

  • Page 40: Per Port Configuration

    Rapid Spanning-Tree Protocol learning and listening states to the forwarding state. Enter a value between 4 through 30. [NOTE] Must follow the rule to configure the MAX Age, Hello Time, and Forward Delay Time. 2 x (Forward Delay Time value -1) > = Max Age value >= 2 x (Hello Time value +1) Remember to execute the "Save Configuration"...

  • Page 41: Redundant Ring

    mathematic calculation. False is including the STP mathematic calculation. Click button. Remember to execute the "Save Configuration" action, otherwise the new configuration will lose [NOTE] when the switch power off. RSTP – Per Port Configuration interface 4.16 Redundant Ring Redundant ring provide a faster redundant recovery than Spanning Tree topology. The action is similar with STP or RSTP, but the algorithms not the same.
  • Page 42 The system also supports the coupling ring that can connect 2 or more redundant ring group for the redundant backup function and dual homing function that prevent connection lose between redundant ring group and upper level/core switch. ■ Enable Redundant ring: to enable the redundant ring function. Marking the check box to enable the redundant ring function.

  • Page 43: Qos Configuration

    [NOTE] When you enable the redundant ring function, you must disable the RSTP. The redundant ring function and RSTP function cannot exist at the same time. Remember to execute the "Save Configuration" action, otherwise the new configuration will lose when the switch power off. 4.17 QoS Configuration You can configure Qos setting of the every port.

  • Page 44: Igmp

    4.18 IGMP The Internet Group Management Protocol (IGMP) is an internal protocol of the Internet Protocol (IP) suite. IP manages multicast traffic by using switches, routers, and hosts that support IGMP. Enabling IGMP allows the ports to detect IGMP queries and report packets and manage IP multicast traffic through the switch.

  • Page 45: Snmp Configuration

    4.19 SNMP Configuration The SNMP is a Protocol that governs the transfer of information between management and agent. The switch supports SNMP V1. You can define management stations as trap managers and to enter SNMP community strings. You also can define a name, location, and contact person for the switch. Fill in the system options data, and then click Apply to update the 4.19.1 System Operations Name: enter a name for the switch.

  • Page 46: Security Manager

    4.19.3 Trap Manager A trap manager is a management station that receives traps, the system alerts generated by the switch. If no trap manager is defined, no traps will issue. Create a trap manager by entering the IP address of the station and a community string.

  • Page 47: Configuration Backup

    4.21 Configuration Backup In Configuration Backup, you can restore the backup configuration into the industrial switch. Also, you can backup the configuration to TFTP server. 4.21.1 TFTP Restore Configuration You can restore flash ROM value from TFTP server, but you must put the backup image in TFTP server, industrial switch will download the image back to the flash.

  • Page 48: Tftp Backup Configuration

    TFTP Restore Configuration interrface 4.21.2 TFTP Backup Configuration You can save current flash ROM value from the industrial switch to the TFTP server, then go to the TFTP restore configuration page to restore the image value back to the industrial switch. TFTP Server IP Address: fill in the TFTP server IP Backup File Name: fill the file name Click...

  • Page 49: Factory Default

    4.21.3 TFTP Update Firmware It provides the functions to allow a user to update the switch firmware. Before updating, make sure you have your TFTP server ready and the firmware image is on the TFTP server. TFTP Server IP Address: fill in your TFTP server IP. Firmware File Name: the name of firmware image.

  • Page 50: Save Configuration

    Factory Default interface 4.23 Save Configuration Save the industrial switch configuration to the flash memory. Power off the industrial switch without the saving, all changed configuration will lost. Click the button the save the configuration. Save Configuration interface...

  • Page 51: System Reboot

    4.24 System Reboot Reboot the Switch in software reset. Click 4.25 Rate Control You can set up every port's bandwidth rate and packet limitation type. ■ Limit Packet type: select the packet type that want to filter. The packet types have all type packet, broadcast/multicast/unknown unicast packet, broadcast/multicast packet, and broadcast packet only.

  • Page 52: System Log

    Qos and Rate control cannot be existed at the same. Rate Control interface 4.26 System Log You can set up system log events and view the system log events. 4.26.1 System Log Configuration You can view the system log events in here. Click button to get newest system log event and button to clear the log events.
  • Page 53 4.26.2 Event Configuration You can select the system log events. When selected events occur, the system will send out the log information. Also, per port log events can be selected. ■ System event selection: 4 selections - Device cold start, Power status, SNMP Authentication Failure, and Redundant ring topology change.
  • Page 54 Event Configuration interface...

  • Page 55: Troubleshooting

    5. TROUBLESHOOTING This section is intended to help you solve the most common problems on the industrial Ethernet switch. 5.1 Incorrect connections The switch port can auto detect straight or crossover cable when you link switch with other Ethernet device. For the RJ-45 connector should use correct UTP or STP cable, 10/100Mbps port use 2-pairs twisted cable.
  • Page 56 IF the power indicator does turn on when the power cord is plugged in, you may have a problem with power outlet, or power cord. However, if the Switch powers off after running for a while check for loose power connections, power losses or surges at power outlet. IF you still cannot resolve the problem, contact your local dealer for assistance.

  • Page 57: Appendix

    6.1 100BASE-TX/10BASE-T Pin Assignments With 100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and pins 3 and 6 for receiving data. RJ-45 Pin Assignments Pin Number "+" and "-" signs represent the polarity of the wires that make up each wire pair. Note: All ports on this switch support automatic MDI/MDI-X operation, you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs.
