Framery 2Q Lounge
Version 1.0
Tampere, Finland 16.2.2022
Installation instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2Q Lounge and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Framery 2Q Lounge

Summary of Contents for Framery 2Q Lounge

  • Page 1 English Framery 2Q Lounge Version 1.0 Tampere, Finland 16.2.2022 Installation instructions...

  • Page 3: Table Of Contents

    Framery 2Q Lounge Contents 1 Warranty checklist..................5 2 Important safety and product instructions..........6 2.1 Preface........................6 2.2 Product information....................6 2.3 Copyright.........................6 2.4 Manual contents..................... 6 2.5 Intended use......................6 2.5.1 Non-conventional use.................6 2.5.2 Ambient conditions for use.................7 2.6 Warning, information, and safety symbols in this manual........7 2.7 Main safety risks related to the installation, maintenance, disassembly, and...
  • Page 4 Framery 2Q Lounge 7.3.1 Install the USB cord into the strike plate-side glass frame (optional)..61 7.3.2 Install the booking system bracket (optional)........... 62 7.3.3 Install the 5V unit (optional)..............68 7.4 Install the side glasses..................72 7.5 Install the front center frame................76 7.6 Finalize the installation of the front frames and glasses........

  • Page 5: Warranty Checklist

    For the product warranty to be valid: Fill this checklist and send it to Framery after pod installation. Take a photo or scan the filled list and send it to Framery at warranty@frameryacoustics.com. Leave the completed list inside the pod.

  • Page 6: Important Safety And Product Instructions

    • Installation instructions 2.5 Intended use The Framery 2Q is a pod intended for short term indoor commercial and household use by one to six (1-6) people at a time. Warning: WARNING –To reduce the risk of burns, fire, electric shock, or injury to persons: Use this product only for its intended use as described in the user instructions.

  • Page 7: Ambient Conditions For Use

    Framery 2Q Lounge • Making alterations to the pod • Using the pod in spite of obvious defects or damage • Using the pod outdoors or in conditions where the temperature or air quality is not safe • Climbing on top of the product or placing any load on the roof of the product •...

  • Page 8: Main Safety Risks Related To The Installation, Maintenance, Disassembly, And Use Of The Product

    Framery 2Q Lounge 2.7 Main safety risks related to the installation, maintenance, disassembly, and use of the product 2.7.1 Installation, maintenance, and disassembly WARNING! To reduce the risk of burns, fire, electric shock, or injury to persons, obey the following: Use cut resistant safety gloves during the installation, maintenance, or disassembly of the product.

  • Page 9: Fire Safety

    Do not use the pod if you notice any defects or damage to the electrical equipment. Do not connect any extension cords to the power outlet(s) of the product. 2.7.3 Fire safety The fire load for the Framery 2Q is approx. 10400 MJ. Installation instructions info@frameryacoustics.com...

  • Page 10: Use

    Note: Framery does not supply seats for the 2Q Huddle. Maximum load for the display bracket is 65 lbs (30 kg). Maximum load for the 2Q Lounge whiteboard bracket is 33 lbs (15 kg). Note: UL962 compliance is only guaranteed with Framery supplied furniture.
  • Page 11 Risk of injury! Keep hands and other body parts clear of the side edges of the table when raising or lowering the electrically adjustable table top. This applies to all Framery pods with an electric adjustable table. Do not use the product if the surrounding conditions are in any way hazardous;...
  • Page 12 Framery 2Q Lounge Do not obstruct the view through the front and back glasses by posting signs, decorations, or by installing blinds or draperies that would prevent occupants from seeing the visible alarm appliances located in the structure where the pod is installed.

  • Page 13: Packaging Information

    Framery 2Q Lounge 3 Packaging information Figure 1: Variant pallet (*optional components) Installation instructions info@frameryacoustics.com...
  • Page 14 Framery 2Q Lounge Figure 2: Glass pallet Installation instructions info@frameryacoustics.com...
  • Page 15 Framery 2Q Lounge Figure 3: Sofa pallet Installation instructions info@frameryacoustics.com...

  • Page 16: Installation Requirements

    Framery 2Q Lounge 4 Installation requirements 4.1 Tools and accessories Figure 4: Tools and accessories needed for installation Note: Use a white rubber mallet to prevent marks on the body covers. Note: Use a plastic chisel to remove the body covers.

  • Page 17: Install The Back Frames And Glasses

    Framery 2Q Lounge 5 Install the back frames and glasses When installing frames, push them into place and lightly tighten the screws with a wrench. Tip: Line the piece with the other frames with a clamp or a rubber mallet.
  • Page 18 Framery 2Q Lounge Install the back center frame with M8x55 bolts (3 pcs) and M8 washers (3 pcs). Note: Press the acoustic panel aside to reach the bolt holes. Make sure that you return the acoustic panel to its original position.
  • Page 19 Framery 2Q Lounge Install the lower center frame with black M8x50 countersunk screws (2 pcs). Install the screws from the inside of the pod. Note: Make sure that there is at least 2.75 m/9 ft (maximum 3.0/10 ft) of the main power cord inside the pod.
  • Page 20 Framery 2Q Lounge Install the upper corner frame of the left-hand side with M8x55 bolts (3 pcs) and M8 washers (3 pcs). Note: Press the acoustic panel aside to reach the bolt holes. Make sure that you return the acoustic panel to its original position.

  • Page 21: Install The Right-Hand Frames And The Other Side Glass

    Framery 2Q Lounge 5.2 Install the right-hand frames and the other side glass Install the guide pins (2 pcs). Install the lower corner frame of the right-hand side with black M8x50 countersunk screws (3 pcs). Note: The seismic support bracket is optional. The maximum size of the anchor bolt is M10.
  • Page 22 Framery 2Q Lounge Slide the other side glass into place. Note: Tilt the glass to guide it into the groove. Install the guide pins (2 pcs). Note: Hold the glass in place. Installation instructions info@frameryacoustics.com...
  • Page 23 Framery 2Q Lounge Install the upper corner frame of the right-hand side with M8x55 bolts (3 pcs) and M8 washers (3 pcs). Use a hand tool to tighten the bolts. Note: One person holds the glass in place. Note: Press the acoustic panel aside to reach the bolt holes. Make sure that you return the acoustic panel to its original position.

  • Page 24: Install The First And Center Glasses

    Framery 2Q Lounge Install the right-hand side frame with M8x55 bolts (3 pcs) and M8 washers (3 pcs). Tighten the bolts on the upper corner frame of the right-hand side. 5.3 Install the first and center glasses Guide the first side glass almost fully into the grooves.
  • Page 25 Framery 2Q Lounge Slide the first side glass into place. Guide the center side glass almost fully into the grooves. Installation instructions info@frameryacoustics.com...

  • Page 26: Finalize The Installation Of The Back Frames And Glasses

    Framery 2Q Lounge Slide the center glass into place. 5.4 Finalize the installation of the back frames and glasses Tighten the nylon screws (2 pcs each side) on the sides of the back half of the pod with a flat-head screwdriver.
  • Page 27 Framery 2Q Lounge Seal the whole frame with the wedge-shaped seal between the glasses and frames. Note: Install the seal on the outside of the back half of the pod. Tip: Use glass washing liquid as a lubricant to help install the seal.

  • Page 28: Install The Interior And Its Electrics

    Framery 2Q Lounge 6 Install the interior and its electrics 6.1 Install the control unit Insert the control unit bracket into the back of the control unit. Turn the bracket into place. Installation instructions info@frameryacoustics.com...
  • Page 29 Framery 2Q Lounge Install the bracket with the control unit into the front opening in the ceiling with 3x12 mm screws (2 pcs). Note: Place the control unit on the right-hand side of the roof beam. Guide the DC extension cord to the center of the roof.

  • Page 30: Install The Seal And The Metal Trims

    Framery 2Q Lounge Connect the DC extension cord to the PWR IN connector of the control unit. 6.2 Install the seal and the metal trims Cut 58 mm (2 5/16 in) off the top of the U-profile seal at both ends.
  • Page 31 Framery 2Q Lounge Install the U-profile seal with the cord on the right side of the pod from the ceiling to the middle of the floor module. Note: Press the DC extension cord into the U-profile seal. Note: Start installing the seal from the edge of the motion detector opening.
  • Page 32 Framery 2Q Lounge Install the newly cut end of the seal slightly below the cut end and leave the DC extension cord outside. Cut the seal to the correct length. Note: Measure the seal to the floor. Installation instructions info@frameryacoustics.com...
  • Page 33 Framery 2Q Lounge Cut 40 mm (1 9/16 in) off the top of the U-profile seal. Install the rubber grommet onto the DC extension cord. Press the grommet against the wall. Installation instructions info@frameryacoustics.com...
  • Page 34 Framery 2Q Lounge Slide the inlet into the groove around the grommet. Install the inlet with black 5x30 screws (2 pcs). Installation instructions info@frameryacoustics.com...
  • Page 35 Framery 2Q Lounge 10. Install the other half of the U-profile seal on the left side of the pod from the ceiling to the floor. Note: Start the installation with the end where the top is cut off. 11. Cut the seal to the correct length.
  • Page 36 Framery 2Q Lounge 12. Cut 40 mm (1 9/16 in) off the top of the U-profile seal. 13. Install the black metal trims with black 5x30 screws (20 pcs) on the inside of the pod. Note: Install the trims in a butt joint.

  • Page 37: Install The Power Outlet

    Framery 2Q Lounge 6.3 Install the power outlet Install the power outlet mounting plate under the sofa with 4x20 screws (3 pcs). Slide the power outlet into the mounting plate. Repeat the steps for the power outlet under the other sofa.

  • Page 38: Install The Power Mounting Plate Under The Sofa

    Framery 2Q Lounge 6.4 Install the power mounting plate under the sofa Push the power unit and the converter into the holders on the power mounting plate. Make sure that the ON/OFF switch of the power unit is in the "I" position.
  • Page 39 Framery 2Q Lounge Remove the plastic studs from the installation plate. Press the removed platic studs into the installation plate ja slide the GST splitter onto it. Installation instructions info@frameryacoustics.com...
  • Page 40 Framery 2Q Lounge Install the installation plate to the mounting bracket using the plastic studs. Note: Make sure that the male connector is next to the lower side flange. Press the mouting bracket onto the power mounting plate in between the power unit and the converter.

  • Page 41: Install The Legs Of The Back Sofa

    Framery 2Q Lounge Place the power mounting plate approximately in the middle of the right-hand side recess on the bottom of the back sofa and install it to the sofa bottom with 3x12 screws (2 pcs). 6.5 Install the legs of the back sofa Lay down the sofas on their backs.
  • Page 42 Framery 2Q Lounge Guide the main power cord in from the lower end and out of the top of the sofa leg with two holes. Install the legs to the back sofa with black 5x30 screws (3 pcs each). Note: Make sure that you install the leg with the power cord to the lower right- hand back corner of the sofa.

  • Page 43: Install The Legs Of The Side Sofa

    Framery 2Q Lounge 6.6 Install the legs of the side sofa Install the legs to the side sofa outside the pod with black 5x30 screws (3 pcs each). Note: Make sure that you install the legs of the side sofa to the ready-made holes.
  • Page 44 Framery 2Q Lounge Connect the main power cord to the power unit. Guide the cord through two cable holders. Tip: The power unit AC connector has a locking mechanism. To bypass the locking mechanism, tilt the connector of the AC extension cord first down and then up.
  • Page 45 Framery 2Q Lounge Connect the AC extension cord to the AC splitter. Guide the cord through three cable holders. Connect the power unit to the AC splitter. Installation instructions info@frameryacoustics.com...
  • Page 46 Framery 2Q Lounge Turn the sofa at the back wall up into sitting position. Push the cable holders (3 pcs) into the holes on the bottom of the side sofa. Installation instructions info@frameryacoustics.com...
  • Page 47 Framery 2Q Lounge Guide the power outlet cord through two cable holders. Turn the sofa up into sitting position and push it into place against the other sofa. Make sure that the DC extension cord is not damaged. Installation instructions...
  • Page 48 Framery 2Q Lounge 10. Connect the power outlet to the AC splitter. Guide the cord through four cable holders. 11. Connect the DC extension cord from the floor module to the DC converter. Guide the cord through three cable holders.

  • Page 49: Install The Table

    Framery 2Q Lounge 6.8 Install the table Attach the side table bracket to the table top with black 5x30 screws (2 pcs). Note: Install the bracket at the ready-made holes. Install the table support leg to the table with black 5x30 screws (2 pcs).
  • Page 50 Framery 2Q Lounge Install the power outlet to the bracket under the table. Turn the power outlet so that it catches on the grooves of the bracket. Note: Check that the power outlet cord is behind the power outlet. Pull off the cord duct cover.
  • Page 51 Framery 2Q Lounge Guide the power outlet cord through the cord duct and through the table support leg. Press the duct cover into place. Installation instructions info@frameryacoustics.com...
  • Page 52 Framery 2Q Lounge Position the table on the wall and the bracket of the support leg into place under the sofa. Note: Make sure that the seal on the wall is in the middle of the table bracket. Install the table support leg to the sofa with black 5x30 screws (2 pcs).
  • Page 53 Framery 2Q Lounge Install the table to the wall with black 5x30 screws (4 pcs). Note: Use a spirit level to make sure that the table is level. Note: Make sure that the seal on the wall is in the middle of the table bracket.

  • Page 54: Install The Front Frames And Glasses

    Framery 2Q Lounge 7 Install the front frames and glasses When installing frames, push them into place and lightly tighten the screws with a wrench. Tip: Aling the piece with the other frames pieces with a clamp or a rubber mallet.
  • Page 55 Framery 2Q Lounge Install the lower corner frames (2 pcs) with black M8x50 countersunk screws (2 pcs each). Install the screws from the inside of the pod. Note: The lower corner frames have a beveled edge on the doorway side.

  • Page 56: Install The Control Panel

    Framery 2Q Lounge Install the side frames with M8x55 bolts (3 pcs each) and M8 washers (3 pcs each). Tip: Use a clamp to straighten the frames if needed. 7.2 Install the control panel Insert the rubber cover to the U-profile on top of the strike plate-side glass frame.
  • Page 57 Framery 2Q Lounge Remove the plastic sticker over the holes for the control panel cord and screws on the strike plate-side glass frame. Install the control panel bracket on the strike plate-side glass frame with M4x10 screws (2 pcs). Installation instructions...
  • Page 58 Framery 2Q Lounge Guide the control panel cord in through the hole in the middle of the strike plate-side glass frame and out through the U-profile on top of the strike plate-side glass frame. Note: Guide the flat (1x4 pins) end of the control panel cord in first.
  • Page 59 Framery 2Q Lounge Install the magnets (2 pcs) behind the control panel with M4x10 screws (2 pcs). Use a hand tool to tighten the screws. Connect the control panel cord to the panel. Installation instructions info@frameryacoustics.com...

  • Page 60: Install The Booking System Bracket (Optional)

    Framery 2Q Lounge Install the control panel into the bracket. Note: The control panel attaches to the bracket with magnets. Note: Make sure that the cord is not caught between the magnets and the case. 7.3 Install the booking system bracket (optional)

  • Page 61: Install The Usb Cord Into The Strike Plate-Side Glass Frame (Optional)

    Framery 2Q Lounge 7.3.1 Install the USB cord into the strike plate-side glass frame (optional) Remove the protective plastic approximately 100 mm (4 in) from the top and bottom of the aluminum frame of the strike plate-side glass. Guide the customer supplied USB cord in through the hole behind the strike plate and out through the U-profile at the top edge of the strike plate-side glass frame.

  • Page 62: Install The Booking System Bracket (Optional)

    Framery 2Q Lounge Guide the strike plate-side glass into the grooves and slide it in place. Note: Make sure that the control panel and the USB cord are not damaged during the installation. You can tape the cords to the aluminum frame to keep them out of the way.
  • Page 63 Framery 2Q Lounge Unscrew the M5x25 Taptite screws (2 pcs) and remove the strike plate from the strike plate-side aluminum frame. Note: Do not use power tools to remove the strike plate. Note: Set the screws aside for later use. The standard strike plate is not needed.
  • Page 64 Framery 2Q Lounge Install the small rubber grommet onto the USB cord and insert the grommet into the hole in the strike plate-side glass. Note: Make sure that you leave enough cord on the outside to reach the customer supplied tablet.
  • Page 65 Framery 2Q Lounge Measure the correct place for the rubber spacer on the chosen wooden back plate and install with a 4x20 screw. Installation instructions info@frameryacoustics.com...
  • Page 66 Framery 2Q Lounge Lead the USB cord through the grommet in the strike plate. Assemble the booking system bracket with one M6x30 screw and one M6 barrel nut. Hold the nut in the slot while tightening the screw. Installation instructions...
  • Page 67 Framery 2Q Lounge Pull the excess cord out of the slot in the strike plate. Install the strike plate with the bracket assembly to the strike plate-side aluminum frame with the M5x25 Taptite screws (2 pcs) set aside earlier. Note: Do not use power tools to install the strike plate.

  • Page 68: Install The 5V Unit (Optional)

    Framery 2Q Lounge 10. Feed the excess USB cord into the frame. Tip: You may need to pull on the cord at the opening near the ceiling to adjust the length. 11. Install the plastic cover to the slot in the strike plate.
  • Page 69 Framery 2Q Lounge Punch out the right-hand side precut hole in the ceiling felt. Guide the USB and control panel cords from the U-profile on the strike plate-side glass frame to the control unit and pull them out of the front opening in the ceiling.
  • Page 70 Framery 2Q Lounge Disconnect the DC extension cord from the PWR IN connector of the control unit. Connect the DC splitter cord to the 5V unit. Installation instructions info@frameryacoustics.com...
  • Page 71 Framery 2Q Lounge Connect the DC extension cord to the DC splitter cord. Connect the USB cord to the USB connector of the 5V unit. Installation instructions info@frameryacoustics.com...

  • Page 72: Install The Side Glasses

    Framery 2Q Lounge Connect the 5V unit to the PWR IN connector of the control unit. Place the 5V unit carefully on the ceiling felt between the ceiling beams. 7.4 Install the side glasses Note: If the delivery includes the booking system bracket, go to step 3.
  • Page 73 Framery 2Q Lounge Peel back the protective plastic approximately 100 mm (4 in) from the top and bottom of the aluminum frame of the strike plate-side glass. Guide the strike plate-side glass into the grooves and slide it into place.
  • Page 74 Framery 2Q Lounge Peel back the protective plastic approximately 100 mm (4 in) from the top and bottom of the aluminum frame of the hinge-side glass. Guide the hinge-side glass into the grooves and slide it into place. Note: Make sure that the aluminum profile of the glass is level with the corner frame.
  • Page 75 Framery 2Q Lounge Check the straightness of the pod slightly below the roof and wall module junction with a spirit level. Install the screws on the glass frames first on the front half of the roof and then on the front half of the floor.

  • Page 76: Install The Front Center Frame

    Framery 2Q Lounge 7.5 Install the front center frame Install the guide pins (2 pcs). Install the front center frame with M8x55 bolts (3 pcs) and M8 washers (3 pcs). Note: Press the acoustic panel aside to reach the bolt holes. Make sure that you return the acoustic panel to its original position.

  • Page 77: Finalize The Installation Of The Front Frames And Glasses

    Framery 2Q Lounge 7.6 Finalize the installation of the front frames and glasses Tighten the nylon screws (2 pcs each side) on the sides of the front half of the pod with a flat-head screwdriver. Note: The glass adjustment screws are only for pushing the glasses together.

  • Page 78: Install The Control Panel Cord And The Ceiling Threshold

    Framery 2Q Lounge 7.7 Install the control panel cord and the ceiling threshold If the delivery includes the booking system bracket, go to step 3. Punch out the precut holes in the ceiling felt. Guide the control panel cord from the U-profile on the strike plate-side glass frame to the control unit and pull it out of the front opening in the ceiling.
  • Page 79 Framery 2Q Lounge Connect the control panel cord to the UI connector of the control unit. Peel back 50 mm (2 in) of the strike plate-side glass frame seal from the door frame. Installation instructions info@frameryacoustics.com...
  • Page 80 Framery 2Q Lounge Peel back 280 mm (11 in) of the hinge-side glass frame seal from the door frame. Guide first the right-hand side end and then the left-hand side end of the ceiling threshold in place against the door frames.
  • Page 81 Framery 2Q Lounge Slide the ceiling threshold against the front center frame. Note: Make sure that the control panel cord is in the cord channel of the threshold. If the delivery includes the booking system bracket, make sure that the optional customer supplied USB cord is in the cord channel of the threshold.
  • Page 82 Framery 2Q Lounge Install the ceiling threshold with black 5x30 screws (4 pcs). Note: Make sure that the threshold is in the middle of the door opening. Install the screws carefully. The threshold is easily tilted. Note: Make sure that the side frame seals are not between the threshold and the door frame.
  • Page 83 Framery 2Q Lounge 10. Reinstall the loose ends of the side frame seals into the door frame. Note: Make sure that the side frame seals and the threshold seal do not overlap. Installation instructions info@frameryacoustics.com...

  • Page 84: Install The Electrics In The Ceiling

    Framery 2Q Lounge 8 Install the electrics in the ceiling 8.1 Install electrical connections to the control unit Connect the fan DC cords at the back opening to the long fan extension cord. Feed the long fan extension cord from the back of the pod through the groove in the center beam and and into the pod from the light opening at the front.
  • Page 85 Framery 2Q Lounge Connect the long fan extension cord to the FAN 2 connector of the control unit. Connect the fan DC cords to the short fan extension cord at the front. Installation instructions info@frameryacoustics.com...
  • Page 86 Framery 2Q Lounge Connect the short fan extension cord to the FAN 1 connector of the control unit. Connect the light extension cord to the LED 2 connector of the control unit. Installation instructions info@frameryacoustics.com...

  • Page 87: Install The Motion Detector

    Framery 2Q Lounge Feed the light extension cord from the front of the pod to the back and out of the light opening. 8.2 Install the motion detector Feed the motion detector DC cord to the control unit. Note: Feed the cord to the same side of the ceiling beam as the control unit.
  • Page 88 Framery 2Q Lounge Connect the motion detector DC cord to the PIR connector of the control unit. Lift the motion detector into place so that it snaps onto the magnets. Note: Make sure that the cord is not caught between the motion detector and the magnets.

  • Page 89: Install The Lights

    Framery 2Q Lounge 8.3 Install the lights Connect the light at the back to the light extension cord connector. Install the light onto the back ceiling, edge to edge with the motion detector. The light attaches to the ceiling with magnets.
  • Page 90 Framery 2Q Lounge Connect the cord of the remaining light to the LED 1 connector of the control unit. Install the light on the front ceiling, edge to edge with the motion detector. The light attaches to the ceiling with magnets.

  • Page 91: Install The Door

    Framery 2Q Lounge 9 Install the door 9.1 Install the floor threshold Peel back 50 mm (2 in) of the side frame seal from both sides of the door frame. Set the floor threshold down at the doorway and slide agains the door frame.

  • Page 92: Install The Door

    Framery 2Q Lounge Install the floor threshold with 3x12 screws (5 pcs). Reinstall the loose ends of the side frame seals into the door frame. Note: Cut the side frame seal to the correct length, if needed. 9.2 Install the door Peel back enough of the protective plastic from the door frame to install the hinges.
  • Page 93 Framery 2Q Lounge Remove M5x6 screw from the upper part of both hinges. Separate the hinges into two parts each. Note: Set the screw aside and make sure that you do not loose it. Attach the upper halves of the hinges to the door with black M6x30 Taptite screws (4 pcs each).
  • Page 94 Framery 2Q Lounge Attach the lower halves of the hinges to the door frame with black M6x30 Taptite screws (4 pcs each) and install a 1 mm (1/16 in) adjustment plate into the lower hinge mounting hole. Use a hand tool to tighten the screws.
  • Page 95 Framery 2Q Lounge Lift the door into place and guide both hinges together. Warning: Lifting requires two people. Make sure that the lower hinge falls into place. Note: Keep the door in the open position (170° angle). Note: Use a separate piece of carpet in the installation. Set the separate piece of carpet on the ground to protect the door.

  • Page 96: Install The Door Handle

    Framery 2Q Lounge 9.3 Install the door handle Install the smart lock handle. If you intend to install a smart lock handle to the door, see Remove the protective plastic on the inside of the door. Push the handle with the spindle attached to it into place on the outside of the door.
  • Page 97 Framery 2Q Lounge Install an M5x46 screw in the hole at the center of the handle from the inside of the door. Note: Check that the cover plate is positioned straight. Install M5x46 screws (2 pcs) in the vacant holes from the inside of the door.

  • Page 98: Install The Smart Lock Handle (Optional)

    Framery 2Q Lounge Tighten the set screw on the inside handle. The resistance increases steadily until the screw pierces the spindle. You can feel the resistance stop when the set screw pierces the spindle. Note: In the final position, the head of the set screw is slightly above the handle surface.
  • Page 99 Framery 2Q Lounge Shorten the M5 screws to the correct length. Warning: Wear safety glasses when cutting the screws. Shorten the twist spindle to the correct length at the first groove in the twist spindle. Warning: Wear safety glasses when cutting the twist spindle.
  • Page 100 Framery 2Q Lounge Assemble the connector plate, twist spindle, and the previously cut M5x40 screws (2 pcs). Assemble the smart lock cylinder and the cylinder escutcheon. Note: Make sure that you install the cylinder escutcheon the right side up. Installation instructions...
  • Page 101 Framery 2Q Lounge Shorten the twist spindle to the correct length at the third groove in the twist spindle. Warning: Wear safety glasses when cutting the twist spindle. Push the twist spindle through the extension plates to the smart lock.
  • Page 102 Framery 2Q Lounge Place the connector plate assembly onto the upper opening in the door. Install the smart lock assembly and the door handle with the spindle onto the door from outside, and tighten the screws (2 pcs) from inside.
  • Page 103 Framery 2Q Lounge 10. Push the counter part of the door handle onto the door from inside. 11. Tighten the M5x32 screw above the door handle from inside. Note: Check the straightness of the cover plate before fully tightening the screw.
  • Page 104 Framery 2Q Lounge 12. Install the thumb turn with the previously cut M5x61 screws (2 pcs), and the handle plate with the remaining M5x32 screw from inside. Note: Check the straightness of the cover plate outside the door before fully tightening the thumb turn screws.

  • Page 105: Adjust The Strike Plate

    Framery 2Q Lounge 14. Check the gap between the lock and the strike plate. If the gap is larger than 4 mm, see Adjust the strike plate. 9.4.1 Adjust the strike plate The gap between the lock and strike plate can be adjusted with the adjustment plates included in the delivery.

  • Page 106: Check The Lock Function

    Framery 2Q Lounge Re-install the strike plate and the adjustment plates. 9.4.2 Check the lock function With the door open, press the thumb turn down and push the sliding snib up. Installation instructions info@frameryacoustics.com...
  • Page 107 Framery 2Q Lounge Press the door handle down to check the lock latch function. If the lock latch does not return easily to the starting position, see for instructions. Press the smaller latch in with your thumb and try pressing the door handle down.
  • Page 108 Framery 2Q Lounge With the smaller latch pressed in, press the thumb turn down to test the lock latch function. The lock latch should retract inside the lock case. Go into the pod and close the door. Press the door handle down.

  • Page 109: Adjust The Door Height

    Framery 2Q Lounge Press the door handle and the thumb turn down. The door should open. Program the smart lock as instructed by the manufacturer. Note: Once the smart lock system is in use, the door cannot be opened by pressing the door handle down.
  • Page 110 Framery 2Q Lounge Pull out the adjustment stick from the lower inside frame of the door. Close the door. Installation instructions info@frameryacoustics.com...
  • Page 111 Framery 2Q Lounge Turn the bottom screw of the upper hinge clockwise with a hex key. Lift the door a maximum of 3 mm (1/8 in). Adjust the lower hinge to the same level as the upper hinge. The lower hinge is at the same level with the upper hinge when you feel resistance.

  • Page 112: Adjust The Closing Speed Of The Door

    Framery 2Q Lounge Make sure that the door closes correctly and smoothly. 9.6 Adjust the closing speed of the door If you want the door to close faster, you can adjust it. Test the door before adjustment. Remove the M5x6 screw from the upper hinge.
  • Page 113 Framery 2Q Lounge Insert the 5 mm hex key into the top of the hinge. Tighten the spring clockwise with a 5 mm hex key to the point where you feel resistance. The key bounds back when it encounters resistance.
  • Page 114 Framery 2Q Lounge Hold the hex key against the resistance and insert the lock pin into the hole on the left- hand side of the hinge close to the door frame. Note: To insert the lock pin, align the hole in the inner cylinder of the hinge with the hole in the outer surface.
  • Page 115 Framery 2Q Lounge Reinsert the 5 mm hex key into the top of the hinge. Hold the hex key in place and remove the lock pin. Installation instructions info@frameryacoustics.com...
  • Page 116 Framery 2Q Lounge Turn the hex key a ¼ turn and insert the lock pin into the hole on the left-hand side of the hinge close to the door frame. Note: To insert the lock pin, align the hole in the inner cylinder of the hinge with the hole in the outer surface.
  • Page 117 Framery 2Q Lounge 10. Install the M5x6 screw. Note: Do not remove the lock pin before the screw is fully in place. 11. Remove the lock pin. 12. Adjust the lower hinge to the same setting as the upper hinge.

  • Page 118: Adjust The Automatic Door Seal

    Framery 2Q Lounge 13. Test the door and repeat if needed. Note: You can tighten the springs a maximum of 6 x ¼ turns from the point of resistance. Note: The closing of the door must take at least 1.5 seconds from a 70° angle.
  • Page 119 Framery 2Q Lounge Adjust the screw on the stick. The further the stick comes out of the door frame, the lower the door seal descends. The seal descends automatically when you close the door. Push the stick back into place with a snap.

  • Page 120: Install The Cover Panels And The Body Covers

    Framery 2Q Lounge 10 Install the cover panels and the body covers 10.1 Install the roof cover panels Install the roof cover panel to the front half of the roof with 4x30 screws (6 pcs). Push the cords into the electrical channel.

  • Page 121: Install The Roof Cover Plates

    Framery 2Q Lounge Install the roof cover panel to the back half of the roof with 4x30 screws (6 pcs). Note: Place the countersunk holes upwards. Use the existing screw holes. Note: Do not lean against the roof. Make sure that your ladder is high enough.

  • Page 122: Install The Wall Cover Panels

    Framery 2Q Lounge 10.3 Install the wall cover panels Reinstall the small cover panels (8 pcs) to the walls with 4x30 screws (16 pcs). Note: Place the countersunk holes upwards. Use the existing screw holes. Reinstall the large cover panels (8 pcs) to the walls with 4x30 screws (64 pcs).

  • Page 123: Install The Bottom Body Covers

    Framery 2Q Lounge 10.4 Install the bottom body covers Install the bottom body covers (1 pc each side) in the middle of the floor of the pod. Push the lower part first under the pod and then guide the flange into the groove on the wall.

  • Page 124: Install The Wall Body Covers

    Framery 2Q Lounge 10.5 Install the wall body covers Install the center body covers on both sides of the pod. Place the upper fold of the body cover against the wall of the pod and slide it into the upper installation groove.
  • Page 125 Framery 2Q Lounge Press the body cover into the upper groove with one hand and bend the body cover lightly outward with your other hand. Slide the lower edge of the body cover into the groove at the bottom of the wall and press the body cover into place.
  • Page 126 Framery 2Q Lounge Install the wall body covers (2 pcs each side) on the edges of the wall of the pod. Guide the edges of the covers against the flanges in the middle cover. Note: If you are installing the optional whiteboard body covers, make sure that the sticker is in the upper outer corner when you install the wall body cover.

  • Page 127: Install The Roof Body Covers

    Framery 2Q Lounge 10.6 Install the roof body covers Install the roof body covers (2 pcs) in the center of the roof. Installation requires two people: One guides the cover from the ladder, one from the floor. Guide the cover first to the center of the roof. Then pull down and guide the lower edge to the groove on the wall.
  • Page 128 Framery 2Q Lounge Install the roof body covers (2 pcs) to the left-hand back and right-hand front corners of the roof. Installation requires two people: One guides the cover from the ladders, one from the floor. Guide the cover first to the center of the roof and guide the edges of the covers against the flanges in the middle cover.
  • Page 129 Framery 2Q Lounge Install the roof body covers (2 pcs) to the left-hand front and right-hand back corners of the roof. Installation requires two people: One guides the cover from the ladder, one from the floor. Guide the cover first to the center of the roof and guide the edges of the covers against the flanges in the middle cover.

  • Page 130: Finalize The Installation Of The Body Covers

    Framery 2Q Lounge 10.7 Finalize the installation of the body covers Install the black cover plate on each side of the front half of the pod floor with black wronic 4.2x25 screws (4 pcs). Note: Do not install the screw in the middle of the pod.

  • Page 131: Install The Cable Clips

    Framery 2Q Lounge 11 Install the cable clips Remove the plastic from the cable clips' sticky labels (2 pcs). Install the cable clips onto the back wall on the floor level of the pod. Note: Make sure to install the cable clips the right way up.
  • Page 132 Framery 2Q Lounge Guide the internal power cord into the cable clips. Note: Pull the main power cord tight and push the excess cord outside the pod from the hole in the back wall. Install the inlet on the hole with an M8x20 screw.

  • Page 133: Install The Piaggio Table

    Framery 2Q Lounge 12 Install the piaggio table Install the leg of the table with black M5x25 screws (2 pcs). Note: Place the countersunk holes upwards. Install the table top with black M5x25 screws (2 pcs). Note: Install the washer plate between the leg and the top of the table.
  • Page 134 Framery 2Q Lounge Place the table into the pod. Installation instructions info@frameryacoustics.com...

  • Page 135: Install The Whiteboard

    Framery 2Q Lounge 13 Install the whiteboard Measure the locations for the whiteboard brackets on the wall with a spirit level. Install the brackets in a butt joint with the U-profile seal. Note: Install the flat part of the bracket level with the edge of the wall felt.
  • Page 136 Framery 2Q Lounge Install the wooden backplate below the whiteboard brackets with 5x60 screws (4 pcs). Note: Install the backplate in a butt joint with the whiteboard brackets. Note: Use the U-profile seal as the midpoint reference. Install magnets (2 pcs) below the wooden backplate. Measure 45 mm (1 ¾ in) from the U-profile seal to the screw hole in the magnet and install with 4x40 screws (2 pcs).
  • Page 137 Framery 2Q Lounge Install magnets (2 pcs) for the outer edges of the whiteboards. Measure 1150 mm (3 ft 9 ¼ in) from the U-profile seal to the screw hole in the magnet and install with 4x40 screws (2 pcs).
  • Page 138 Framery 2Q Lounge Push the whiteboards together. Attach the cork board onto the wooden backplate. The cork board attaches to the backplate with magnets. Tip: The cork board can also be attached to the body covers on the out side of the pod.

  • Page 139: Install The Display Bracket And Display Cord (Optional)

    Framery 2Q Lounge 14 Install the display bracket and display cord (optional) Note: The display is not included in the delivery. For display recommendations, contact your dealer. Remove the cork board from the wooden backplate. Push the whiteboards to the sides.
  • Page 140 Framery 2Q Lounge Remove the black 5x30 screws (2 pcs) from the wall shelf bracket and pull the table away from the wall. Note: Make sure that the display cord fits between the wall and the table. Cut the U-profile seal under or behind the table.
  • Page 141 Framery 2Q Lounge Cut the U-profile seal at the opening of the wooden backplate. Pull the U-profile seal fully out of the U-profile. Installation instructions info@frameryacoustics.com...
  • Page 142 Framery 2Q Lounge Cut 50 mm (2 in) off of the seal. Connect the display cord to the power outlet. Installation instructions info@frameryacoustics.com...
  • Page 143 Framery 2Q Lounge Guide the customer supplied display cord through the U-profile to the display bracket from below the table. 10. If you have a customer supplied HDMI cord, guide one end through the U-profile to the display bracket and out of its opening and the other end from the U-profile onto the table.
  • Page 144 Framery 2Q Lounge 11. Install the U-profile seal from below the table up to the opening in the display bracket. 12. Push the table against the wall. Note: Make sure that the cut seam of the U-profile seal is behind the table and the cords are fully hidden.
  • Page 145 Framery 2Q Lounge 13. Reinstall the wall shelf bracket with black 5x30 screws (2 pcs). 14. Install the display bracket in the middle of the wooden backplate. Note: Measure the height of the bracket according to the display. Installation instructions...
  • Page 146 Framery 2Q Lounge 15. Push the whiteboards back into place. Installation instructions info@frameryacoustics.com...

  • Page 147: Finalize The Installation

    Framery 2Q Lounge 15 Finalize the installation Install the profile hole covers on the inside of the door frame near the floor. Connect the main power cord to a power outlet. Installation instructions info@frameryacoustics.com...
  • Page 148 Framery 2Q Lounge Fill out the warranty checklist and send it to Framery. Note: The warranty is only valid with the filled-out warranty checklist. Installation instructions info@frameryacoustics.com...
  • Page 149 Framery 2Q Lounge...
  • Page 150 Framery 2Q Lounge Installation instructions Patamäenkatu 7 33900 Tampere FINLAND VAT: FI 23527139...

This manual is also suitable for:

Huddle 2q

Table of Contents
