Framery Six
Quick Installation Guide
SCREWS AND BOLTS ARE IN THE
FASTENERS ACCESSORIES 1 BOX.
1. CHASSIS
1.1 Front frame
1.2 Back frame
6mm
Make sure that the bolts are properly
tightened.
1.4 Floor boards
Place a carpet on the floor before
flipping the bottom frame to protect
the floor from scratches.
1.6 Horizontal frames & middle
frame
6mm
Make sure that the bolts are properly
tightened.
1.3 Bottom corners & floor
extensions
12x
M8x25
13mm
16x
M6x16
TX30
2x
Place the corner frame boxes under
the floor boards to avoid bending the
boards.
6x
13mm
M8x12
1/2"
2x
13mm
M8
1/2"
3x
6mm
Make sure that the bolts are properly
tightened.
INSTALLATION INSTRUCTIONS, SEE
THE FULL INSTALLATION MANUAL
PROVIDED IN THE FASTENERS AND
6x
13mm
M8x12
1/2"
2x
13mm
M8
1/2"
3x
37x
M6x16
TX30
Make sure that the screw heads are
level with the floor boards.
1.5 Vertical frames
4x
6mm
13mm
1/4"
M8x12
1/2"
Make sure that the bolts are properly
tightened.
8x
M6x16
TX30
FOR MORE DETAILED
ACCESSORIES 1 BOX.
3x
2x
1
