Framery 2Q Lounge
English
Installation instructions
Version 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2Q Lounge and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Framery 2Q Lounge

Summary of Contents for Framery 2Q Lounge

  • Page 1 Framery 2Q Lounge English Installation instructions Version 2.0...

  • Page 3: Table Of Contents

    Contents 1 Warranty checklist..................7 2 Safety......................8 3 Installation requirements................10 3.1 Tools and accessories..................10 3.2 Main dimensions....................11 3.3 Installation space....................11 3.4 Operating space....................12 4 Prepare the carpet for installation............13 5 Install the back half of the pod..............14 5.1 Install the back half of the floor................
  • Page 4 9 Install the interior and its electrics............61 9.1 Install the carpet....................61 9.2 Install the control unit................... 61 9.3 Install the seal and the metal sheets..............64 9.4 Install the power outlet..................70 9.5 Install the feet of the sofas.................. 71 9.6 Install the power mounting plate under the sofa..........
  • Page 5 16 Install the whiteboard ................155 17 Install the display bracket and display cord (optional)......160 18 Finalize the installation................. 168...

  • Page 7: Warranty Checklist

    For the product warranty to be valid: Fill this checklist and send it to Framery after pod installation. Take a photo or scan the filled list and send it to Framery at warranty@frameryacoustics.com. Leave the completed list inside the pod.

  • Page 8: Safety

    Note: Never drop or insert any object into any opening unless instructed. Note: Do not place heavy objects on the roof of the pod. Note: Do not attach or hang extra weight from the door. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 9 Installation environment The pod is intended to be used in the following conditions. • Ambient temperature: +15°C ... +30°C (59°F ... 86°F) • Humidity: max. 50% Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 10: Installation Requirements

    Note: Use a draw wire in the electrical installations. Note: Use a separate piece of carpet in the door installation. Note: Use a lint-free cloth to clean the pod. Note: Use a mild alcohol-based cleaning solution to clean the pod. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 11: Main Dimensions

    Tip: Use glass washing liquid as a lubricant to help install the seal. 3.2 Main dimensions Figure 2: Main dimensions of the 2Q pod 3.3 Installation space Figure 3: Installation space measurements of the 2Q pod Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 12: Operating Space

    (7 ft 11 5/16 in). The dimensions for 2Q include the minimum recommended space for the air to circulate: 200 mm (7 7/8 in) above the pod and 50 mm (1 15/16 in) around the pod. Figure 4: Operating space measurements of the 2Q pod Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 13: Prepare The Carpet For Installation

    4 Prepare the carpet for installation Unroll the carpet. Roll the carpet the other side up from the long side. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 14: Install The Back Half Of The Pod

    Note: Support the pieces at all times. Make sure that the nut in the I-beam faces the inside of the back half of the pod. Join the wooden pins into the holes in the corner pieces. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 15 Press wooden pins (14 pcs) into the corner pieces. Press the floor board onto the corner pieces. Note: Make sure that the narrow end of the floor board is at the open end of the back half of the floor. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 16 Lay down the back half of the floor. Install guide pins (4 pcs) to the installation holes. There are two guide pins for each floor corner piece. Position the back half of the floor at the intended final location. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 17: Install The Back Half Of The Roof

    Note: Make sure that the black ABS strips are against the ground. Unscrew the 4x30 screws (8 pcs) and remove the cover plates (8 pcs). Set the cover plates and screws aside. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 18 Install guide pins (2 pcs) into the installation holes. Push the roof modules together. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 19: Fix The Roof Modules Together (Back)

    Install the support plate with steel colored M6x20 screws (4 pcs). Use a hex key to fully tighten the screws. Note: Pull the roof modules straight to fit the support plate into place. Use a hand tool to tighten the screws and bend the roof modules further, if needed. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 20 Install the other support plate with steel colored M6x20 screws (4 pcs). Use a hex key to fully tighten the screws. Note: Pull the roof modules straight to fit the support plate into place. Bend the roof modules further to install the screws, if needed. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 21: Install The Upper Frame (Back)

    Note: Press the acoustic panel aside to reach the bolt holes. Make sure that you return the acoustic panel to its original position. Note: Pull the roof modules straight to fit the upper frame into place. Bend the modules further to install the screws, if needed. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 22: Install The Wall Modules And The Roof Of The Back Half Of The Pod

    (2 pcs). Install the extra support with 5x50 screws (4 pcs) in the middle of the support beams. Assemble two support beams. Unscrew the 4x30 screws (20 pcs) and remove the cover panels (8 pcs). Set the cover panels and screws aside. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 23: Assemble The Roof Support Beams (Back)

    Install the angle irons to the roof support beams with M8x90 bolts (2 pcs), M8 washers (2 pcs) and flanged M8 nuts (2 pcs). Place the angle irons on top of the blue foam covering. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 24: Fix The (Back) Half Of The Roof To The Wall Modules

    Install guide pins (4 pcs) to the installation holes at the top of the wall modules. Note: Make sure that the guide pin is in the installation hole that is closer to the wall felt. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 25 Install the roof support beams to the roof with M8x55 bolts (2 pcs each) and flanged M8 nuts (2 pcs each). Place the blue foam covering against the ceiling felt. Tighten the screws by hand. Note: Install the bolt on the inside and the nut on the outside. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 26 Note: Make sure that the guide pin meets the installation hole in the roof. Install M8x35 bolts (4 pcs each side) and M8 washers (4 pcs each side). Tighten the screws by hand. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 27: Fix The Combined Roof And Walls To The Floor (Back)

    Lifting requires four people. Warning: Keep the installation area clear of obstacles that you may stumble over. Note: Make sure that the guide pin meets the installation hole in the wall module. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 28 Install M8x35 bolts (4 pcs each side) and M8 washers (4 pcs each side). Tighten the screws by hand. Remove the support beams and store them for later use. Warning: Do not go inside the pod before fully tightening the bolts after connecting the pod halves. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 29: Install The Front Half Of The Pod

    6 Install the front half of the pod 6.1 Install the front half of the floor Stand two corner pieces on their wide ends. Note: Support the pieces at all times. Press wooden pins (12 pcs) in the corner pieces. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 30 Note: Install the screws from the ends of the floor module towards the middle. Make sure that the pins are in place. Note: Make sure that the screw heads are level with the floor or deeper. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 31 Lay down the front half of the floor. Install guide pins (4 pcs) to the installation holes. There are two guide pins for each floor corner piece. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 32: Install The Front Half Of The Roof

    Note: Make sure that the black ABS strips are against the ground. Unscrew the 4x30 screws (8 pcs) and remove the cover plates (8 pcs). Set the cover plates and screws aside. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 33 Install guide pins (2 pcs) into the installation holes. Join the roof modules together. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 34: Fix The Roof Modules Together (Front)

    Install the support plate with steel colored M6x20 screws (4 pcs). Use a hex key to fully tighten the screws. Note: Pull the roof modules straight to fit the support plate into place. Use a hand tool to tighten the screws and bend the roof modules further, if needed. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 35 Install the other support plate with steel colored M6x20 screws (4 pcs). Use a hex key to fully tighten the screws. Note: Pull the roof modules straight to fit the support plate into place. Bend the roof modules further to install the screws, if needed. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 36: Install The Wall Modules And The Roof Of The Front Half Of The Pod

    Stand one of the wall modules on the floor board and the other on the outside of the floor. Note: Make sure that the black ABS strips are on the outer side of the wall modules. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 37: Fix The (Front) Half Of The Roof To The Wall Modules

    Install guide pins (4 pcs) to the installation holes at the top of the wall modules. Note: Make sure that the guide pin is in the installation hole that is closer to the wall felt. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 38 Install the roof support beams to the roof with M8x55 bolts (2 pcs each) and flanged M8 nuts (2 pcs each). Place the blue foam covering against the ceiling felt. Tighten the screws by hand. Note: Install the bolt on the inside and the nut on the outside. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 39 Note: Make sure that the guide pin meets the installation hole in the roof. Install M8x35 bolts (4 pcs each side) and M8 washers (4 pcs each side). Tighten the screws by hand. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 40: Fix The Combined Roof And Walls To The Floor (Front)

    Lifting requires four people. Warning: Keep the installation area clear of obstacles that you may stumble over. Note: Make sure that the guide pin meets the installation hole in the wall module. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 41 Install M8x35 bolts (4 pcs each side) and M8 washers (4 pcs each side). Tighten the screws by hand. Remove the inner support beam and store it for later use. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 42: Connect The Back And Front Halves Of The Pod

    Install guide pins (14 pcs) to the installation holes in the back half of the pod. Install the "H" shaped profile to the groove in the floor board of the back half of the pod. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 43 Use the support beam as leverage. Press the floor board if it does not fit easily into the H profile. Make sure that the halves connect fully at all points. Note: Avoid lifting the front half. Note: It is recommended to use clamps to press the halves closer together. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 44 Note: Install the two bolts located at the center of the roof modules from the inside of the pod. Note: Press the acoustic panel aside to reach the bolt holes. Make sure that you return the acoustic panel to its original position. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 45: Check The Straightness Of The Pod Halves After Connecting

    7.1 Check the straightness of the pod halves after connecting Check the straightness of the pod halves with a spirit level slightly below the roof and wall module junction in each corner of the pod. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 46 Note: You need two people to tighten the bolts on both sides at the same time. Tighten the bolts (2 pcs) connecting the back and front halves of the pod in the floor and wall module junction. Tighten the bolts on both sides at the same time. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 47 Tighten the bolts on both sides at the same time. Tighten the bolts (2 pcs) connecting the back and front halves of the pod in the roof and wall module junction. Tighten the bolts on both sides at the same time. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 48 Tighten the bolts (2 pcs) connecting the back and front halves of the pod at the center of the roof from the inside of the pod. Tighten the bolts (4 pcs) connecting the back and front halves of the pod on the roof. Warning: Do not lean on the roof. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 49 Tighten the bolts on both sides at the same time. Tighten the bolts (8 pcs per side) on the roof and wall module junction of the back and front halves of the pod. Tighten the bolts on both sides at the same time. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 50 10. Check the straightness of the pod with a spirit level slightly below the roof and wall module junction in each corner. If the pod is tilted, loosen the bolts and repeat the straightening procedure. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 51: Install The Back Frames And Glasses

    Tip: Line the piece with the other frames with a clamp or a rubber mallet. When the frame is in place, tighten the screws fully. 8.1 Install the left-hand frames Install guide pins (8 pcs) to the installation holes. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 52 Install the lower corner frame of the left-hand side with black M8x50 countersunk screws (3 pcs). Note: The seismic support bracket is optional. The maximum size of the anchor bolt is M10. Follow the local regulations regarding seismic anchoring. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 53: Install The First Side Glass And The Center Glass

    Install the left-hand side frame with M8x55 bolts (3 pcs) and M8 washers (3 pcs). Tip: Use a clamp to straighten the frames if needed. 8.2 Install the first side glass and the center glass Guide the side glass almost fully into the grooves. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 54 Note: Install the seal all the way from the top to the bottom of the glass and cut off the excess. Slide the side glass into place. Guide the center glass almost fully into the grooves. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 55 Install the seal strip on the side of the center glass. Note: Do not stretch the seal. Note: Install the seal all the way from the top to the bottom of the glass and cut off the excess. Slide the center glass into place. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 56: Install The Right-Hand Frames And The Other Side Glass

    Install the lower corner frame of the right-hand side with black M8x50 countersunk screws (3 pcs). Note: The seismic support bracket is optional. The maximum size of the anchor bolt is M10. Follow the local regulations regarding seismic anchoring. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 57 Slide the other side glass into place. Note: Tilt the glass to guide it into the groove. Install the guide pins (2 pcs). Note: Hold the glass in place. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 58 Note: One person holds the glass in place. Note: Press the acoustic panel aside to reach the bolt holes. Make sure that you return the acoustic panel to its original position. Install the guide pins (2 pcs). Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 59: Finalize The Installation Of The Back Frames And Glasses

    Tighten the nylon screws (2 pcs each side) on the sides of the back half of the pod with a flat-head screwdriver. Note: The nylon screws are only for pushing the glasses together. Tighten the screws until you feel resistance. Do not overtighten. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 60 Seal the whole frame with wedge-shaped seal between the glasses and frames. Note: Install the seal on the outside of the back half of the pod. Tip: Use glass washing liquid as a lubricant to help install the seal. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 61: Install The Interior And Its Electrics

    9 Install the interior and its electrics 9.1 Install the carpet Lay the carpet into place. Press the edges under the wall felt. 9.2 Install the control unit Insert the control unit bracket into the back of the control unit. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 62 Turn the bracket into place. Install the bracket with the control unit into the front opening in the ceiling with 3x12 mm screws (2 pcs). Note: Place the control unit on the left-hand side of the roof beam. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 63 Connect the DC extension cord to the PWR IN connector of the control unit. Guide the DC extension cord to the center of the roof. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 64: Install The Seal And The Metal Sheets

    Install the U-profile seal with the cord on the right side of the pod from the ceiling to the middle of the floor module. Note: Press the DC extension cord inside the U-profile seal. Note: Start installing the seal from the edge of the motion detector opening. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 65 Cut the U-profile seal in the middle of the floor module. Install the newly cut end of the seal from the middle of the floor module to the floor and leave the DC extension cord outside. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 66 Cut the seal to the correct length. Note: Measure the seal to the floor. Cut 20 mm (13/16 in) off the top of the U-profile seal and install the seal. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 67 String the rubber grommet to the DC extension cord. Press the grommet against the wall. Slide the inlet in the groove around the grommet. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 68 10. Install the other half of the U-profile seal on the left side of the pod from the ceiling to the floor. Note: Start the installation with the end where the top is cut off. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 69 11. Cut the seal to the correct length. Note: Measure the seal to the floor. 12. Cut 20 mm (13/16 in) off the top of the U-profile seal and install the seal. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 70: Install The Power Outlet

    Note: Pull the DC extension cord out of the way during the installation of the metal sheets. 9.4 Install the power outlet Install the power outlet mounting plate under the sofa with 4x20 screws (3 pcs). Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 71: Install The Feet Of The Sofas

    Lay down the sofas on their backs. Place one sofa in its approximate place at the back of the pod and the other outside the pod. Note: Pull the power cord on the floor from under the sofa at the back wall. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 72 Note: Install the sofa foot with two holes at the back on the right-hand side. Guide the main power cord in from the lower end and out of the top of the sofa foot with two holes. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 73: Install The Power Mounting Plate Under The Sofa

    Note: Install the feet of the sofa at the ready-made holes. 9.6 Install the power mounting plate under the sofa Push the power unit and the converter on the holders on the power mounting plate. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 74 Make sure that the ON/OFF switch of the power unit is in the "I" position. Press and slide the power mounting bracket on the clamps between the power unit and the converter on the power mounting plate. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 75 Note: Make sure to push the female connectors first to the mounting bracket. Press the power mounting plate approximately in the middle of the bottom of the sofa. Install the power mounting plate to the sofa bottom with 3x12 screws (2 pcs). Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 76: Install The Electrical Connections To The Power Mounting Plate

    Guide the cord through two cable ties. Tip: The power unit AC connector has a locking mechanism. To bypass the locking mechanism, tilt the connector of the AC extension cord first down and then up. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 77 Connect the phase power outlet to the AC splitter. Guide the cord through five cable ties. Connect the AC extension cord to the AC splitter. Guide the cord through three cable ties. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 78 Connect the power unit to the AC splitter. Loosen the two screws at the end of the sofa bottom to install the table support leg. Turn the sofa at the back wall up into sitting position. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 79 Push the cable ties (3 pcs) in the holes on the bottom of the sofa at the front. Note: Close the cable ties, but leave enough space for the plugs to pass through. Guide the phase power outlet cord through two cable ties. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 80 10. Turn the sofa up into sitting position and push it into place against the other sofa. Make sure that the DC extension cord is not damaged. 11. Connect the phase power outlet to the AC splitter. Guide the cord through four cable ties. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 81: Install The Table

    Guide the cord through three cable ties. 9.8 Install the table Attach the wall shelf bracket to the table top with black 5x30 screws (2 pcs). Note: Install the bracket at the ready-made holes. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 82 Install the power outlet to the bracket under the table. Turn the power outlet so that it catches on the grooves of the bracket. Note: Check that the power outlet cord is behind the power outlet. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 83 Pull off the cover of the electrical channel. Guide the power outlet cord through the electrical channel and through the table support leg. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 84 Position the table on the wall and the support bracket into place under the sofa. Note: Check that the seal on the wall is in the middle of the table bracket. Tighten the two screws at the end of the sofa bottom. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 85 Note: Check with a spirit level that the table is straight. Note: Check that the seal on the wall is in the middle of the table bracket. 10. Install the table support leg on the sofa with black 5x30 screws (2 pcs). Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 86 11. Connect the power outlet cord to the AC extension cord. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 87: Install The Front Frames And Glasses

    Tip: Line the piece with the other frames with a clamp or a rubber mallet. When the frame is in place, fully tighten the screws. 10.1 Install the corner and side frames Install the guide pins (12 pcs). Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 88 Install the upper corner frames (2 pcs) with M8x55 bolts (2 pcs each) and M8 washers (2 pcs each). Note: Press the acoustic panel aside to reach the bolt holes. Make sure that you return the acoustic panel to its original position. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 89: Install The Control Panel

    Install the side frames with M8x55 bolts (3 pcs each) and M8 washers (3 pcs each). Tip: Use a clamp to straighten the frames if needed. 10.2 Install the control panel Insert the rubber cover to the U-profile on top of the lock-side glass frame. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 90 Remove the plastic sticker over the holes for the control panel cord and screws on the lock-side glass frame. Install the control panel bracket on the lock-side glass frame with M5x16 screws (2 pcs). Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 91 U-profile on top of the lock-side glass frame. Note: Guide the flat (1x4 pins) end of the control panel cord in first. Install the rubber grommet into the hole in the control panel case. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 92 Install the magnets (2 pcs) behind the control panel with M4x10 screws (2 pcs). Use a hand tool to tighten the screws. Connect the control panel cord to the panel. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 93: Install The Booking System Bracket (Optional)

    Note: Make sure that the cord is not caught between the magnets and the case. 10.3 Install the booking system bracket (optional) Note: If the option does not include the booking system bracket, go to Install the side glasses on page 104. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 94: Install The Usb Cord Into The Lock-Side Glass Frame (Optional)

    Guide the customer supplied USB cord in through the hole behind the strike plate and out through the U-profile at the top edge of the lock-side glass frame. Note: Make sure the USB-A connector of the cord is at the top of the aluminum frame. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 95: Install The Booking System Bracket (Optional)

    10.3.2 Install the booking system bracket (optional) Choose the small or large wooden back plate according to the size of the customer supplied tablet bracket. Note: The booking system tablet is customer supplied. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 96 Note: Do not use power tools to remove the strike plate. Note: Set the screws aside for later use. The standard strike plate is not needed. Cut the rubber grommet open vertically. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 97 Note: Make sure that you leave enough cord on the outside to reach the customer supplied tablet. Install the large rubber grommet to the strike plate of the booking system bracket. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 98 Measure the correct place for the rubber spacer on the chosen wooden back plate and install with a 4x20 screw. Lead the USB cord through the grommet in the strike plate. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 99 Assemble the booking system bracket with one M6x30 screw and one M6 barrel nut. Hold the nut in the slot while tightening the screw. Pull the excess cord out of the slot in the strike plate. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 100 Note: Make sure that the USB cord is not pinched or damaged during the installation. 10. Feed the excess USB cord into the frame. Tip: You may need to pull on the cord at the opening near the ceiling to adjust the length. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 101: Install The Usb-Dc Splitter (Optional)

    3.5x12 screws (2 pcs). 10.3.3 Install the USB-DC splitter (optional) The USB-DC splitter is only installed if the delivery includes the optional booking system bracket. Punch out the precut holes in the ceiling felt. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 102 Guide the USB and control panel cords from the U-profile on the lock-side glass frame to the control unit and pull them out of the front opening in the ceiling. Disconnect the DC extension cord from the PWR IN connector of the control unit. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 103 Connect the DC extension cord to the USB-DC splitter. Connect the USB-DC splitter to the PWR IN connector of the control unit. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 104: Install The Side Glasses

    Connect the USB cord to the USB connector of the USB-DC splitter. Place the USB-DC splitter carefully on the ceiling felt between the ceiling beams. 10.4 Install the side glasses Note: If the option includes the booking system bracket, go to step 3. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 105 You can tape the cord to the aluminum frame to keep it out of the way. Note: Make sure that the lock-side glass with the strike plate is on the correct side for the door handing. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 106 Guide the hinge-side glass into the grooves and slide it into place. Note: Make sure that the aluminum profile of the glass is level with the corner frame. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 107 Note: Check with a spirit level that the hinge-side frame is straight. Push the pod if needed when installing the screws. Check the straightness of the hinge-side glass and push it straight if needed. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 108: Finalize The Installation Of The Front Frames And Glasses

    Seal the side glasses with wedge-shaped seal between the glasses and frames. Note: Install the seal on the inside of the front half of the pod. Tip: Use glass washing liquid as a lubricant to help install the seal. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 109: Install The Control Panel Cord And The Ceiling Threshold

    Punch out the precut holes in the ceiling felt. Guide the control panel cord from the U-profile on the lock-side glass frame to the control unit and pull it out of the front opening in the ceiling. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 110 Connect the control panel cord to the UI connector of the control unit. Peel back 50 mm (2 in) of the lock-side glass frame seal from the door frame. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 111 Guide first the lock-side end and then the hinge-side end of the ceiling threshold in place against the door frames. Note: Install the ceiling threshold from the inside of the door. Note: Make sure that the threshold and the door frames are not scratched. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 112 Note: Make sure that the side frame seals are not between the threshold and the door frame. Note: Make sure that the protective plastic on the aluminum frames is not under the threshold. Peel back further, if needed. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 113 Note: Make sure that the side frame seals are not between the threshold and the door frame. Cut 2 mm (1/16 in) off the upper end of the side frame seals. Note: Make sure that the side frame seals and the threshold seal do not overlap. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 114 10. Reinstall the loose ends of the side frame seals into the door frame. Note: Make sure that the side frame seals and the threshold seal do not overlap. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 115: Install The Electrics In The Ceiling

    Pull the long fan extension cord from the back of the pod through the groove in the center beam and and into the pod from the light opening at the back. Note: Pull the extension cord to the same side of the ceiling beam as the control unit. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 116 Connect the fan extension cord to the FAN 2 connector of the control unit. Connect the fan DC cords to the short fan extension cord at the front. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 117 Connect the short fan extension cord to the FAN 1 connector of the control unit. Connect the light extension cord to the LED 2 connector of the control unit. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 118: Install The Motion Detector

    Pull the light extension cord from the back of the pod to the front and out of the the light opening. 11.2 Install the motion detector Guide the motion detector DC cord to the control unit. Note: Pull the cord to the same side of the ceiling beam as the control unit. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 119 Lift the motion detector into place so that it snaps onto the magnets. Note: Make sure that the cord is not caught between the motion detector and the magnets. Note: Install the seal and the edge of the motion detector in a butt joint. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 120: Install The Lights

    Install the light onto the back ceiling, edge to edge with the motion detector. The light attaches to the ceiling with magnets. Note: Make sure that the light and the motion detector are level with each other. Use the ceiling felt center line as the midpoint reference. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 121 Install the light on the front ceiling, edge to edge with the motion detector. The light attaches to the ceiling with magnets. Note: Make sure that the lights and the motion detector are level with each other. Use the ceiling felt center line as the midpoint reference. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 122: Install The Door

    Neatly cut the side frame seal to the correct length, if needed. Note: Make sure that the protective plastic on the aluminum frames is not under the threshold. Peel back further if needed. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 123: Install The Door

    Note: Cut the side frame seal to the correct length, if needed. 12.2 Install the door Peel back enough of the protective plastic from the door frame to install the hinges. Do not remove the protective plastic completely. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 124 Attach the door leaves to the door with black M6x30 Taptite screws (4 pcs each). Use a hand tool to tighten the screws. Note: The door leaves have two small holes in the side. Note: Make sure that the door leaves do not overlap the seal. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 125 Note: If separate screws are attached to the hinge-side glass frame, use those to attach the frame leaves. Note: Install the adjustment plate under the lower hinge only. Note: Make sure that the seal is not squashed between the hinge and the door frame. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 126: Install The Door Handle

    Make sure that the air goes out of the seal when you close the door. Cut the seal 2 mm (1/16 in) shorter on the lower end if needed. 12.3 Install the door handle Remove the protective plastic on the inside of the door. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 127 Push the handle with the spindle attached to it into place on the outside of the door. Pierce the plastic in the lock case with the spindle. Push the second handle into place on the inside of the door. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 128 Install an M5x46 screw in the hole at the center of the handle from the inside of the door. Note: Make sure that the cover plate is positioned straight. Note: Do not overtighten the screws. Install M5x46 screws (2 pcs) in the vacant holes from the inside of the door. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 129: Adjust The Door Height

    3 mm (1/8 in). In all cases, it is recommended to adjust the height of the door to a position where the hinge halves do not rub against each other. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 130 Close the door. Turn the bottom screw of the upper hinge clockwise with a hex key. Lift the door a maximum of 3 mm (1/8 in). Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 131: Adjust The Closing Speed Of The Door

    Make sure that the door closes correctly and smoothly. 12.5 Adjust the closing speed of the door If you want the door to close faster, you can adjust it. Test the door before adjustment. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 132 Remove the M5x6 screw from the upper hinge, if preinstalled. Insert the 5 mm hex key into the top of the hinge. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 133 Hold the hex key against the resistance and insert the lock pin into the hole on the left- hand side of the hinge close to the door frame. Note: To insert the lock pin, align the hole in the inner cylinder of the hinge with the hole in the outer surface. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 134 Remove the hex key. Note: Do not remove the lock pin. It holds the spring in place so it does not unwind and break. Reinsert the 5 mm hex key into the top of the hinge. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 135 Turn the hex key a ¼ turn and insert the lock pin into the hole on the left-hand side of the hinge close to the door frame. Note: To insert the lock pin, align the hole in the inner cylinder of the hinge with the hole in the outer surface. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 136 Note: Do not remove the lock pin. It holds the spring in place so it does not unwind and break. 10. Install the M5x6 screw. Note: Do not remove the lock pin before the screw is fully in place. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 137 Note: You can tighten the springs a maximum of 6 x ¼ turns from the point of resistance. Note: The closing of the door must take at least 1.5 seconds from a 70° angle. 13. Adjust the lower hinge to the same setting as the upper hinge. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 138: Adjust The Automatic Door Seal

    Pull out the adjustment stick from the lower inside frame of the door. Adjust the screw on the stick. The further the stick comes out of the door frame, the lower the door seal descends. The seal descends automatically when you close the door. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 139 Push the stick back into place with a snap. Check with a flashlight that there is no gap under the door. If the light shines through from under the door, readjust the door seal. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 140: Install The Cover Panels And The Body Covers

    Note: Position the hole for the cords as close to the edge of the front half of the roof as possible. Note: Place the countersunk holes upwards. Use the existing screw holes. Note: Do not lean against the roof. Make sure that your ladder is high enough. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 141: Install The Roof Cover Plates

    Note: Do not lean against the roof. Make sure that your ladder is high enough. 13.2 Install the roof cover plates Reinstall the cover plates (16 pcs) to the roof with 4x30 screws (16 pcs). Note: Place the countersunk holes upwards. Use the existing screw holes. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 142: Install The Wall Cover Panels

    13.3 Install the wall cover panels Reinstall the small cover panels (8 pcs) to the walls with 4x30 screws (16 pcs). Note: Place the countersunk holes upwards. Use the existing screw holes. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 143 Note: Place the countersunk holes upwards. Use the existing screw holes. Note: Make sure that the grooves in the panels are on the outer edge of the panel and that the panels touch the wall module on the inner edge. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 144: Install The Bottom Body Covers

    Note: Make sure that the cover has flanged edges. Install the bottom body covers (2 pcs each side) on the sides of the floor of the pod. Guide the edges of the covers against the flanges in the middle cover. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 145: Install The Wall Body Covers

    Note: Make sure that the cover has flanged edges. Note: Use a plastic chisel, if you must remove the cover. Press the body cover into the upper groove with one hand and let go of the cover with your other hand. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 146 Note: Make sure that the wall body covers are installed evenly and aligned correctly with the other body covers. Use a white rubber mallet to tap the wall covers into alignment if needed. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 147: Install The Roof Body Covers

    Guide the cover first to the middle of the roof. Then pull down and guide the lower edge to the groove on the wall. If you have installed the main power cord and optional LAN cord through the roof, cut the roof body cover at the left-hand back corner. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 148 Note: The covers for the right-hand front and left-hand back corners are identical, as are the covers for the left-hand front and right-hand back corners. Note: Do not lift the cover from the opening. The narrow metal strip bends. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 149 Then pull down and guide the lower edge into the groove on the wall. Note: Do not lift the cover from the opening. The narrow metal strip bends. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 150: Finalize The Installation Of The Body Covers

    Install the black cover plate on each side of the back half of the pod floor with black wronic 4.2x25 screws (5 pcs). Note: The back cover partly overlaps the front cover. Install the screw in the middle of the pod through both back and front covers. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 151: Install The Cord Duct

    Remove the plastic from the cord duct sticky label. Install the cord duct onto the back wall on the floor level of the pod. Leave the cord duct 12 mm (½ in) off from the hole in the back wall. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 152 Install the main power cord into the cord duct. Note: Pull the main power cord tight and push the excess cord outside the pod from the hole in the back wall. Install the inlet on the hole with an M8x20 screw. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...

  • Page 153: Install The Piaggio Table

    Note: Place the countersunk holes upwards. Install the table top with M5x15 screws (2 pcs). Note: Install the washer plate between the leg and the top of the table. Note: Place the countersunk holes upwards. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 154 Place the table into the pod. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 155 Note: Make sure that the screws are level with the bracket so that they do not scratch the whiteboards. Install the whiteboard brackets on the wall with 4x40 screws (10 pcs). Note: Do not overtighten. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 156 Install the wooden backplate between the whiteboard brackets with 5x60 screws (4 pcs). Note: Install the backplate in a butt joint with the whiteboard brackets. Note: Use the U-profile seal as the midpoint reference. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 157 Install the magnets with 15 mm plastic spacers on the wall felt. The upper edge of the magnet touches the wooden backplate. Note: Measure the distance from the outer edge of the U-profile seal. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 158 Note: Measure the distance from the outer edge of the U-profile seal. Note: Make sure that the outer magnets are level with the inner magnets. Lift the whiteboards on the brackets. The whiteboards attach to the magnets. Warning: Lifting requires two persons. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 159 Push the whiteboards together. Attach the cork board on the wooden backplate. The cork board attaches to the backplate with magnets. Tip: The cork board also attaches to the body covers outside the pod. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 160 17 Install the display bracket and display cord (optional) Note: The display is not included in the delivery. For display recommendations, contact your dealer. Remove the cork board from the wooden backplate. Push the whiteboards to the sides. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 161 Note: Make sure that the display cord fits between the wall and the table. Cut the U-profile seal under or behind the table. Note: Make sure that you cut the seal below the table top. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 162 Cut the U-profile seal at the opening of the wooden backplate. Pull the U-profile seal fully out of the U-profile. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 163 Cut 50 mm (1 15/16) off of the seal. Connect the display cord to the power outlet. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 164 10. If you have a customer supplied HDMI cord, guide one end through the U-profile to the display bracket and out of its opening and the other end from the U-profile onto the table. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 165 11. Install the U-profile seal from below the table up to the opening in the display bracket. 12. Push the table against the wall. Note: Make sure that the cut seam of the U-profile seal is behind the table and the cords are fully hidden. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 166 13. Reinstall the wall shelf bracket with black 5x30 screws (2 pcs). 14. Install the display bracket in the middle of the wooden backplate. Note: Measure the height of the bracket according to the display. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 167 15. Push the whiteboards back into place. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 168 18 Finalize the installation Install the profile hole covers on the inside of the door frame near the floor. Connect the main power cord to a power outlet. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
  • Page 169 Fill out the warranty checklist and send it to Framery. Note: The warranty is only valid with the filled-out warranty checklist. Framery 2Q Lounge Installation instructions info@frameryacoustics.com...
