- Page 1 Object Scanner ObjectScan 1600 User's Manual www.microtek.com...
-
Page 2: Preface
The contents of this manual have been checked carefully for accuracy, and every effort has been made to ensure that there are no errors. However, Microtek makes no guarantee as to the accuracy of the contents of this document and reserves the right to make changes to the contents without prior warning. -
Page 3: Fcc Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ObjectScan 1600 User's Manual... -
Page 4: Safety Precautions
• Do not place the scanner on any slippery, slanted, or unstable surface. The product may slide or fall, causing serious injury to people as well as serious damage to the product. ObjectScan 1600 User's Manual... - Page 5 When you need a repair service, unplug the scanner from the power outlet and consult qualified service personnel. • When replacement parts are required, use replacement parts that are specified by the manufacturer or have the same characteristics as the original parts. ObjectScan 1600 User's Manual...
-
Page 6: Table Of Contents
To the Hi-Speed USB Cable ............16 Scanning the Materials ..............17 Positioning the Materials ..............17 Using ScanWizard Graph Software ............ 19 Maintenance ..................22 Appendix ...................23 Optional Magnet Helpers ..............23 Troubleshooting ................25 Specifications ................. 26 ObjectScan 1600 User's Manual... -
Page 7: Knowing About Your Scanner
At the same time, the ObjectScan 1600 is also able to scan paper materials, for example, prints and researching papers. -
Page 8: System Requirements
Color display with 24-bit color output capability • 8 GB RAM or more recommended • Intel Core i5 at 3.0 GHz PC or higher with USB 2.0 port • Microsoft Windows 7 (64-bit), 8 (64-bit) or 10 (64-bit) ObjectScan 1600 User's Manual... -
Page 9: Taking A Closer Look
Drawer of the Scanner Carries the upper scan bed and the lower scan bed of the scanner. Handle of the Drawer Holds to open or close the drawer of the scanner. Right Handle Holds to move the scanner. ObjectScan 1600 User's Manual... -
Page 10: Back View
Power Connector Connects the scanner to the power cord. Power Button Turns the scanner on or off. Hi-Speed USB Port Connects the Hi-Speed USB (USB 2.0) cable to the computer. Left Handle Holds to move the scanner. ObjectScan 1600 User's Manual... -
Page 11: Initiate Setup
Initiate Setup Step 1: Unpacking Package Contents After unpacking your scanner package, please check for the major components listed below. Upper scan bed Scanner Power cord Software DVD Hi-Speed USB cable ObjectScan 1600 User's Manual... -
Page 12: Step 2: Installing The Software
Computer”; the DVD-ROM icon; then Setup.exe to start the installer program. 4. Click EXIT on the Microtek Software Installer screen when all the software has been installed. 5. Restart your computer. NOTE: If the system displays a message “Found a new hardware” after the computer is restarted, please select the installer program automatically. -
Page 13: Step 3: Unlocking The Scanner
When successfully unlocked, the screw will push out a little, protruding slightly from the side of the scanner. Also, the pattern of the hollow side of the locking screw will be turned horizontally. Locked Unlocked b) Turn counterclockwise a) Push to the end with force ObjectScan 1600 User's Manual... - Page 14 Push down with force and turn the locking screw clockwise 90 degrees to the lock position. 4. Shut down ScanWizard Graph software program and turn off your scanner. Hereby, the scanner is ready for transport. ObjectScan 1600 User's Manual...
-
Page 15: Step 4: Installing The Upper Scan Bed
Hollows 3. Insert the stools at bottom of the upper scan bed into the hollows on the lower scan bed. Make sure the upper scan bed has been assembled in the scanner firmly. ObjectScan 1600 User's Manual... -
Page 16: Step 5: Connecting The Scanner
3. Switch the Power button at the back side of the scanner to ON, and wait for the indicators light on the front panel to stop blinking and stay on steady. The system will detect your scanner automatically. ObjectScan 1600 User's Manual... -
Page 17: Scanning The Materials
When placing the scanned object, do not block the calibration area. Upper scan bed The calibration area is next to the upper scan bed which is an independent and unremovable entity located at the right side of the drawer. ObjectScan 1600 User's Manual... - Page 18 4. When done, grab the handle of the drawer and push it back into the scanner. When "click" sound is heard, the drawer has been closed properly. NOTE: The maximum loading weight for scan beds is 5.5 lbs (2.5 kg). Do not load any material heavier than the loading limit. ObjectScan 1600 User's Manual...
-
Page 19: Using Scanwizard Graph Software
OK button to accept the settings. You can always change the settings at a later time. For more information, see the Color Matching Setup section in the ScanWizard Graph Reference Manual in the Microtek Software DVD. Pertains to how your monitor displays color,... - Page 20 Save button, and the scanner will automatically scan and save your image based on your settings. NOTE: For more information about ScanWizard Graph scanning software, see the manual of ScanWizard Graph in the Microtek Software DVD. ObjectScan 1600 User's Manual...
- Page 21 ObjectScan 1600 User's Manual...
-
Page 22: Maintenance
NOTE: Your scanner need a professional to perform the required service or maintenance. Do not attend to fix or perform the maintenance by yourself, or it may cause dangers to you or the scanner. ObjectScan 1600 User's Manual... -
Page 23: Appendix
This section is only available for the user who purchase the scanner with an iron upper scan bed. For your convenience, Microtek offers you a set of magnets to purchase additionally. When your scanned originals are pressed, creased or wrinkled, the two Magnet Helpers are handful to make the scanned target flat on the scan bed and thus you can get better after-scan results. - Page 24 Magnet Helper has been raised up like a seesaw. Press down the side with the bevel design 2. Use two fingers to grab and hold the lifted-up side and then remove the Magnet Helper from the upper scan bed. ObjectScan 1600 User's Manual...
-
Page 25: Troubleshooting
Make sure your scanner is connected to your computer and plugged in to a power source (see “Connecting the Scanner” in the “Initial Setup” section). Uninstall and reinstall the ScanWizard Graph software. 4. After clicking “Scan,” a blank screen appears. Uninstall and reinstall the ScanWizard Graph software. ObjectScan 1600 User's Manual... -
Page 26: Specifications
1 year for normal use Important: Please never attempt to open or service the machine by yourself; or, this will void your warranty. Specifications, software bundles, and accessories are subject to change without notice. Not responsible for typographic errors. ObjectScan 1600 User's Manual...
