MTP DA4 and DA8 • Setup Guide (Continued)
Step 4 — Power
Wire the 2-pole captive screw connector for the external
12 VDC power supply as shown in figure 4. Plug it into
the DA.
Operation — Mutes
To mute an output, tie the Output Mute pin to the
ground ( ). To mute all outputs, tie the A pin to the
ground (see figure 5 for more information).
MTP DA8
Output Mute Connector
1 2 3 4 5 6 7 8 A
MTP DA4
Output Mute Connector
1 2 3 4 A
