CENTRIFUGAL FILTER
Installation and
Operation Manual
This equipment must be installed and serviced by a qualified technician.
!
WARNING
Improper installation may result in property damage, serious injury or death.
Improper installation and/or operation will void the warranty.
Notice to Installer
This manual contains important information about the installation, operation
& safe use of this product. Once the product has been installe this manual
must be given to the owner / operator of this equipment.
www.waterco.com
Advertisement
Table of Contents
Related Manuals for Waterco MultiCyclone12 Plus
Summary of Contents for Waterco MultiCyclone12 Plus
- Page 1 Improper installation and/or operation will void the warranty. Notice to Installer This manual contains important information about the installation, operation & safe use of this product. Once the product has been installe this manual must be given to the owner / operator of this equipment. www.waterco.com...
-
Page 2: Table Of Contents
5. The operating safety of the filter is only guaranteed if the installation and operation instructions are correctly followed. 6. In the event of defective operation or fault, contact Waterco or its nearest authorised service agent. 7. To reduce the risk of injury, do not permit children to use this product. -
Page 3: Multicyclone Plus/Ultra
MultiCyclone Plus/Ultra I pg 02 MULTICYCLONE PLUS/ULTRA MultiCyclone Plus/Ultra combines centrifugal and cartridge filtration into one streamlined housing, creating an ultra compact filtration system. • Dual stage filtration. • Minimal maintenance. • Save water and energy. • 12/16 hydrocyclones. • Plus 40ft &... - Page 4 12 Plus/Ultra: 40mm/50mm (EU) 1 ½” Quick Fit Union. 16 Plus/Ultra: 50mm/63mm (EU) 2” Quick Fit Union. Air Release Valve Pressure Gauge Filter Cartridge Housing Lid Filter Housing Retaining Clamp Band Filter Housing Retaining Clamp 12 & 16 Plus/Ultra 3.7m / 40ft Band Tightening Nut Pleated Filter Cartridge...
-
Page 5: Multicyclone Total Head Loss Curve
The PRV should be set to 90% of the maximum operating pressure of the tank. If the incoming water flow is less than the filter’s minimum flow requirements, the filter’s filtration efficiency will be affected, please consult Waterco. Typical Installation 1. - Page 6 5. The filter should be placed on a level concrete slab, very firm ground, or equivalent. Ensure that the ground will not subside, preventing any strain from the attached plumbing. 6. Ensure that there is no movement of the filter during operation of the purge valve. 7.
-
Page 7: Start Up Procedures
“o”-rings and create sealing problems. Note: Waterco recommends that a shut off valve be installed after the MultiCyclone Plus/ Ultra on the pool return line to assist with flushing out the collected debris. Please refer to “Insufficient Water Pressure”. -
Page 8: Multicyclone Plus/Ultra Filter Maintenance
INSUFFICIENT WATER PRESSURE In situations where the water flow from the pump is not powerful enough purge the sediment out of the sediment chamber. Waterco recommends fitting a 2 way valve after the MultiCyclone Plus/Ultra on the pool water return line. -
Page 9: Filter Cartridge Maintenance
MultiCyclone Plus/Ultra I pg 08 FILTER CARTRIDGE MAINTENANCE To ensure maximum life from your MultiCyclone Plus/Ultra’s filter cartridge you need to maintain the filter cartridge regularly. When the filter is first started and has been purged of air, note the pressure on the pressure gauge. -
Page 10: General Maintenance Guide
Some swimming pool stores offer a filter cartridge cleaning service using the correct solutions otherwise you may wish to use Waterco Cartridge cleaning solution. Directions of use are on the product. The cleaning time depends upon the swimming pool condition and use. Intervals between cleaning the element should not exceed a period of 12 months in any instance. -
Page 11: Troubleshooting Guide
Worn “o”-ring seal inside filter, replace o-ring. WARRANTY MultiCyclone Plus/Ultra is covered by a 2 year warranty and 1 year warranty on labour. Commercial installations are covered by a 1 year warranty. Please refer to Waterco’s warranty terms and conditions. - Page 12 Tel: +61 8 8244 6000 Tel: +1 450 748 1421 Tel: +65 6344 2378 ACT diSTRiBUTiON WATERCO (NZ) LiMiTEd Tel: +61 2 6280 6476 Auckland, New Zealand Tel: +64 9 525 7570 Waterco Limited ABN 62 002 070 733 (W99279) 07/2013...
