Fluke 2640A Service Manual page 214

NetDAQ
Service Manual
Reference
Designator
BT1
C1, 18
C2
C3, 8, 38,
C89
C4- 6, 11,
C15, 30, 31
C7
C9, 32, 34
C10, 35, 53,
C81
C12, 13
C14
C16, 19- 22
C24, 25, 29,
C33, 36, 40-
C42, 60, 62-
C65, 67- 69,
C71, 73, 75-
C80, 82- 84,
C86- 88, 90,
C92, 93, 95,
C96
C17
C23, 28
C26
C27, 37
C39,102
C43- 52, 54-
C59
C61
C97
C98-101
CR1, 10
CR2, 3
CR4, 14, 15,
CR18, 19, 21
CR5, 6, 16
CR7
CR8, 9, 13,
CR17
CR11, 12, 20,
CR22
DS1
DS2, 3
J2
J3
J4
J5
J6
L1
6-10
Table 6-2. A1 Main PCA Assembly
Description
BATTERY,LITHIUM,3.0V,0.560AH
CAP,AL,220UF,+-20%,35V,SOLV PROOF
CAP,CER,0.033UF,+-20%,100V,X7R,1206
CAP,CER,22PF,+-10%,50V,C0G,1206
CAP,AL,47UF,+-20%,50V,SOLV PROOF
CAP,AL,10000UF,+-20%,35V,SOLV PROOF
CAP,AL,1UF,+-20%,50V,SOLV PROOF
CAP,CER,1000PF,+-5%,50V,C0G,1206
CAP,AL,470UF,+-20%,16V,SOLV PROOF
CAP,AL,2200UF,+-20%,10V,SOLV PROOF
CAP,CER,0.1UF,+-10%,25V,X7R,1206
CAP,AL,2.2UF,+-20%,50V,SOLV PROOF
CAP,CER,1000PF,+-20%,3000V,Z5U
CAP,AL,47UF,+-20%,100V,SOLV PROOF
CAP,CER,0.01UF,+-10%,50V,X7R,1206
CAP,CER,0.047UF,+-10%,100V,X7R
CAP,CER,180PF,+-10%,50V,C0G,1206
CAP,CER,0.01UF,+100-0%,1600V,Z5U
CAP,CER,4700PF,+-10%,50V,X7R,1206
CAP,TA,10UF,+-20%,16V,6032
DIODE,SI,60 PIV,3 AMP,SCHOTTKY
DIODE,SI,600 PIV,1.5 AMP
* DIODE,SI,BV=70V,IO=50MA,DUAL,SOT23
DIODE,SI,40 PIV,1 AMP,SCHOTTKY
* DIODE,SI,SCHOTTKY,DUAL,30V,SOT-23
* DIODE,SI,BV=100,IO=100MA,DUAL,SOT23
*
* DIODE,SI,BV=75V,IO=250MA,SOT23
*
LED,YELLOW,RIGHT ANGLE,3 MCD
LED,RED,RIGHT ANGLE,3.0 MCD
HEADER,1 ROW,.050CTR,20 PIN
HEADER,1 ROW,.100CTR,3 PIN
CONN,D-SUB,PWB,RT ANG,9 PIN
HEADER,1 ROW,.197CTR,RT ANG,10 PIN
HEADER,1 ROW,.197CTR,RT ANG,8 PIN
FERRITE CHIP,95 OHMS @100 MHZ,3612
Fluke Stock
Tot Qty
No
821439 1
929708 2
886655 1
740563 4
740563
822403 7
822403
875203 1
782805 3
867408 4
867408
772855 2
875208 1
747287 40
747287
747287
747287
747287
747287
747287
747287
747287
747287
769687 1
832709 2
837492 1
747261 2
844733 2
769778 16
769778
106930 1
832279 1
867572 4
943097 2
112383 2
742544 6
742544
837732 3
942594 1
821116 4
821116
830489 4
830489
914242 1
927389 2
831529 1
845334 1
855221 1
875695 1
875690 1
867734 1
Notes
