Comeup Seal 9.5si Quick Start Manual

Introduction

Feature

Line pull:
Synthetic rope: 10mm × 30.5 m (3/8"×100') synthetic rope SK-75
Brake:
Clutch:
Control:

Unpacking

．Winch assembly..................................................................... 1 pc
．Control box............................................................................ 1 pc
．Remote control..................................................................... 1 pc
． Synthetic rope with clevis hook................................................. 1 pc
．Hawse fairlead...................................................................... 1 pc
．1.8 m (6') 2 gauge battery lead................................................. 1 pc
Read this manual carefully
You should carefully read and understand this manual before operating it.
Careless winch operation may result in personal injury hazards or property
damage.

Installation

Before using the winch, make sure all electrical components have no
corrosion or damaged; the environment should be clear and dry.
Winch and hawse fairlead mountings
It is very important that the winch will be mounted on
a flat and hard surface of mounting channel in order
to make sure the motor, drum and gearbox housing
are aligned correctly.
Hawse fairlead does not mount to the winch
directly.
The synthetic rope shall be wound in an
4,309 kg / 9,500 lb synthetic rope first layer
Patented cone brake holds full load
Turn the T-handle for rapid rope payout
Handheld pendant switch powers the winch
Self-Recovery Winch
Seal 9.5si
Model:
PN: 293220 12V DC
