GLOW+LED STRIP Installation and Operation Manual EMAUX WATER TECHNOLOGY CO., LTD USER MANUAL STRIVE FOR CLEAR WATER www.emauxgroup.com...
Page 2
6. HOW TO USE GLDIYSC TO CUT THE STRIP AND END CAP ASSEMBLE 2.2 DIMENSIONS (mm) 16.5mm 2.3 WIRING CONNECTOR TYPE AND PART NUMBER CODE Model Description 9042915 GL10 LED strip max 20m length 9042901 GL10SR Power connector side right 9042903 GL10SL Power connector side left...
Page 3
Description length(m) Quantity Code Mode Description 9042915 + 9042901 GL10, 10m, color temp 3000K, GL10SR connector side right E042901 Dimmer Controller LED Dimmer with remote 9042915 + 9042901 GL10, 3m, color temp 3000K, GL10SR connector side right 106328534 24V, 240W, 100-240V AC 50/60Hz input voltage, IP67...
Page 4
2. Mounting clip Code Description length(m) Quantity There are 3 different length of plastic mounting accessories to fit into the mounting and one stainless steel for corner mounting reinforcement. 9042915 + 9042909 10m, color temp 3000K, power connector both side direct 9042915 + 9042907 3m, color temp 3000K, power connector side direct 9042915 + 9042907...
Page 5
2.Wiring diagram with dimmer Bending: >100mm -V(Black) 24V Power Supply AC Mains +V(Red) Do not bend Connect to LED STRIP against light terminals. >100mm waterproof GLOW+ LED STRIP connector Dimmer wiring diagram Mount the cable junction in waterproof junction box when apply to outdoor mounting. Waterproof 6.
