- Page 1 GLOW+LED STRIP Installation and Operation Manual USER MANUAL EMLI22080103...
-
Page 2: Table Of Contents
TABLE OF CONTENT ..1. PRODUCT INTRODUCTION ..2. SPECIFICATION 2.1 ELECTRICAL 2.2 DIMENSIONS (mm) 2.3 WIRING CONNECTOR TYPE AND PART NUMBER 2.4 POWER SUPPLY AND DIMMER 3. DESIGN EXAMPLE ..4. MOUNTING ..5. ELECTRICAL INSTALLATION ..6. HOW TO USE GLDIYSC TO CUT THE STRIP AND END CAP ASSEMBLE .. -
Page 3: Product Introduction
1. PRODUCT INTRODUCTION The underwater LED strip is designed for to latest waterproof technologies in IP68. It is an extendable and top view bendable LED light strip tube with a 120-degree beam angle and flat rectangular emission for creating underwater profile lighting. It can be controlled by a manual or wireless remote dimmer for lighting effect tuning. -
Page 4: Power Supply And Dimmer
GL10SR GL10LR GL10SL GL10SD GL10BD GL10BB GL10SB Code example: 9042915 (length 5 meter, CCT 3000K) + 9042901 = 5m LED strip, color temp 3000K with power connector side right. 2.4 POWER SUPPLY AND DIMMER 24V DC power supply provides LED strip power source and dimmer with remote control to adjust the brightness of the strip. -
Page 5: Mounting
Order details for side power connection cable Code Description length(m) Quantity 9042915 + 9042901 GL10, 10m, color temp 3000K, GL10SR connector side right 9042915 + 9042901 GL10, 3m, color temp 3000K, GL10SR connector side right GL10, 7m, color temp 3000K, GL10SR connector side right 9042915 + 9042901 GL10, 10m, color temp 3000K, GL10SL connector side left 9042915 +9042903... - Page 6 2. Mounting clip There are 3 different length of plastic mounting accessories to fit into the mounting and one stainless steel for corner mounting reinforcement. Description Code Mode Plastic Mounting Clips Transparent 35mm 106090026 GLPMC Plastic Mounting Channel Transparent 1m 106090027 GLPMC1M 106090028...
-
Page 7: Electrical Installation
5. ELECTRICAL INSTALLATION The system operation is 24Vdc only and current rating is 5A per 10 m strips. Therefore, a 120W minimum power supply is required to turn on the light in full brightness. Rated power 120W 240W LED Strip length 9.5m Locate the power supply nearby the LED strip and connect the terminal wiring. -
Page 8: Dimmer And Remote Operation
Step 1 Step2 Step4 finished assembly view Step3 Step5 Step 1 - Place the anti-skidding clip on the very end of the tubing with the 2 tiny tabs that are pointing inwards still touching the end of the material and crimp in place. Step 2 - Line up the aluminum mounting piece so the screw hole face the plug and slide on over the anti-skidding clip. -
Page 9: Wireless Remote Control Code Value Setting Method
Name of key Description ON in any time OFF in any time 3 static modes: Mode DIM: 20%, 50%, 100% CCT: warm white, cool white, pure white Brightness + Bright up the brightness by 1024 levels. Long-press will get fast adjusting. Brightness - Dim down the brightness by 1024 levels. -
Page 10: Remote Control Accessories Installation Instructions
(3) Code learning operation between remote controls: Used to unify system code values or copy a new remote controls. Since each remote controller has its own unique code at the time of delivery, when there are multiple remote controllers in one system, one of them (for example, remote controller A) must be selected as the system code value, and the code value of the rest remote controllers (for example, remote controller B) should be copied to the same one. -
Page 11: Dimmer Operation
7.2 Dimmer Operation 7.2.1 Specification Working temperature -20-60℃ Supply voltage DC12-24V Output 1 channel Static power consumption <1W Max. output current Max. output power 300W/12V; 600W/24V Net weight External dimension L103*W40*H24 mm Gross weight Packing size L140*W48*H35mm 2KHz (factory default),500Hz,1KHz, Memory function PWM frequency 4KHz, 7.8KHz, 15.6KHz... - Page 12 EMAUX WATER TECHNOLOGY CO., LTD YOUR PREMIER SUPPLIER www.emauxgroup.com...
