emaux UL-CP100 Operating Manual

Maintenance of the Lights

• Do not leave the lights "on" above water for longer than 1 minute.
• Do not leave the lights directly under sunlight. Fill the pool with fresh water as soon as
possible after the lights are installed.
• Before switching on the lights, check whether the lights are fully submerged
underwater and the circuit boxes are running properly.
• This unit does not need any kind of maintenance. If it is not working properly, please
contact EMAUX authorized dealer where you purchase the unit from.
• Warranty will be voided if the Emaux Underwater Light was dismantled by
unauthorized personnel.

REPLACEMENT PARTS

Key No. Part No. Description
1 03011321 M5X20 screws (316#)
2 01040212 Lights Lens
3 01012031 Face plate
4 01110027 Compression screw
5 02010237 O-ring
6 89045601 Bulb plate(White Colour),12V/8W 198LEDs
6 89045602 Bulb Plate(RGB) 12V/6W 102LEDs
6 89045603 Bulb Plate(RGB) 12V/8W 198LEDs
6 89045604 Bulb Plate(White Colour), 12V/6W 102LEDs
7 89044501 Lights Vinyl Pool Fitting for P100/ CP100
8 89040203 Lights Concrete Pool Fitting for P100/ CP100
Key No. Part No. Description
1 03011321 M5*20 Screw (316#)
2 01050102 Face plate
3 01110027 Compression screw
4 01040212 Lights Lens
5 04011073 Bulb 12V/75W for ULH/ UL-NS
6 03011132 M4*8 Screw
7 03011150 Screw
8 04011031 Lamp Socket
9 03013039 But
10 03017118 Reflector Plate
11 04014016 Closed-End Wire Connector
12 02021084 O-Ring for UL-CP100
13 01231008 UL-CP100 Light Body Set
14 04013004 2.5M Cable
15 89044501 Vinyl pool Fitting for P100
16 89040203 Fitting for Concrete Pool
Qty
1
1
1
1
1
1
1
1
1
1
1
LED-CP100
Qty
1
1
1
1
1
3
2
1
2
1
2
1
1
1
1
1
U -CP100 L
4-4
UL-CP100
LED-CP100
ROTARY TYPE UNDERWATER LIGHT OPERATING MANUAL
Keep this manual for future reference

SAFETY WARNINGS

• Only qualified electrician is allowed to carry out the installation of this product.
• Avoid direct contact with electrical power.
• Respect all regulations in effect for preventing accidents.
• All units are required to be disconnected from the main electricity before any operation of
maintenance.
• Never handle with wet hands and feet.
• This unit is design for use only when fully submerged in fresh water, connecting with a safety
transformer.
• Never operate this Underwater Light for more than 1 minute unless it is totally submerged in
water.
• Be sure power is off before installing or removing light bulb. Allow light bulb to cool before
replacing.
• This product should be installed according to your local electrical installation ordinances and
regulations.
• Maximum Depth for Light installation at 1 meter.
• Maximum Water Temperature Range for light operation 0 - 30 C.

SPECIFICATION

A.Electrical Specification: 1) Voltage: AC12V 2) Frequency: 50Hz 3) Power: 75W(UL-CP100),
6W/8W(LED-CP100)

INSTALLATION NOTES

1) Each cable is 2.5m long. You should follow the procedures closely when installing the light.
2) It is recommended to install a light every 20m , the approximate exposure area of each
unit.
3) The lights should be installed in the direction that they will not shine directly into the house.
4) For training or competition pools, the lights must be installed on the sides in order to
prevent swimmers from seeing any glare.
5) Nothing should be placed on the poolside directly above the lights for ease of future
maintenance.
6) If the wires are connected inside the lights, you must seal the connections with leak-proof
tapes or products with the same function.
o
2
1-4
