3 NOMENCLATURE
3.1 COMPONENTS AND CONTROLS
The nomenclature graphics below, Figure 3.1,
indicate the general locations of the exterior
components of the Intelect Transport Combo
System.
Power
On/Off
LCD
Clinical
Library
TIME
Back
STOP
Down
Arrow
Parameter
Display / Enter
PAUSE
Power Cord
Connection
Serial
Decal
Know the components and their functions before
performing any operation of or service to the Intelect
Transport Combo System.
LCD Intensity/
Contrast Dial
Sound Head
(Output Power)
Up
Arrow
INTENSITY
Applicator
Channel 1
Lead Wire
Connection
START
Accessory
Panel
Battery
Compartment
FIGURE 3.1
6
Intelect Transport® Combo Therapy System
LED Indicator
Channel 2
Lead Wire
Connection
Ultrasound
Applicator
Connection
