- Page 1 HPSBOC 3524C v.1.1 HPSBOC 27,6V/3A/2x17Ah/OC Buffer switch mode power supply unit with technical outputs. Edition: 9 from 01.03.2018 Supercedes edition: 8 from 01.06.2016...
-
Page 2: Table Of Contents
PSU, with high energy efficiency. The PSU is housed in a metal enclosure (colour RAL 9003) which can accommodate two 2x17Ah/12V batteries. A micro switch indicates door opening (front cover). OPTIONAL POWER SUPPLY CONFIGURATIONS: (visualisation available at: www.pulsar.pl) 1. Buffer power supply unit HPSBOC 27,6V/8x0,3A/2x17Ah. - HPSBOC3524C + LB 8x0,3A (AWZ577 or AWZ580) + 2x17Ah 2. - Page 3 GREEN POWER plus www.pulsar.pl HPSBOC3524C 6. Buffer power supply unit HPSBOC 27,6V/24V/8x0,3A/2x17Ah. - HPSBOC3524C + RN25024 (27,6V/24V) + LB8 8x0,3A (AWZ577 or AWZ580) +2x17Ah 7. Buffer power supply unit HPSBOC 27,6V/2x5V÷18V/2x2A ÷1,3A/2x17Ah. - HPSBOC3524C + 2xDCDC20 (2x5V÷18V/2A÷1,3A) + 2x17Ah 8. Buffer power supply unit HPSBOC 27,6V/2x5V÷18V/2x2A ÷1,3A/8x0,5A/2x17Ah.
- Page 4 GREEN POWER plus www.pulsar.pl HPSBOC3524C Fig. 2. The view of the PSU. Element no. Description [Fig. 3] PSU module TAMPER, contact, sabotage protection (NC) Tab.2. Output terminals of the PSU. Fig.3. The view of the PSU.
-
Page 5: Specifications
GREEN POWER plus www.pulsar.pl HPSBOC3524C 1.4 Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) Electrical parameters (tab. 3). 176÷264V AC Mains supply Current up to 0,9A@230VAC Supply power 100W max. Efficiency 22V÷... -
Page 6: Installation
GREEN POWER plus www.pulsar.pl HPSBOC3524C Mechanical parameters (tab. 4). Dimensions W=400, H=350, D+D =92+8 [+/- 2mm] =405, H =355 [+/- 2mm] The dimensions of the 370x170x80mm (WxHxD) max battery compartment Fixation See figure 3 Net/gross weight 3,5kg/ 3,8kg Enclosure Steel plate, DC01 0,7mm colour: RAL 9003... -
Page 7: Installation Procedure
GREEN POWER plus www.pulsar.pl HPSBOC3524C Before installation, prepare a PSU load balance. 1. Output current 3A + 0,5A battery charge 2. Output current 2,5A + 1A battery charge Total device current + battery: 3,5A max As the PSU is designed for a continuous operation and is not equipped with a power-switch, therefore an appropriate overload protection shall be guaranteed in the power supply circuit. -
Page 8: Technical Outputs
GREEN POWER plus www.pulsar.pl HPSBOC3524C 3.2 Technical outputs The PSU has indication outputs: EPS - absence of AC supply output: - OC type output that indicates AC power loss. Under normal status, with 230V AC supply, the output is connected to ground (L level –... -
Page 9: Operation And Use
GREEN POWER plus www.pulsar.pl HPSBOC3524C 4. Operation and use. 4.1 Overload or short circuit of the PSU output (SCP on) In case of overload, the output voltage is automatically shut off, and so is the LED indicator. The restoration of the voltage takes place immediately after the failure (overload) is over. - Page 10 The power supply unit is adapted for a sealed lead-acid battery (SLA). After the operation period it must not be disposed of but recycled according to the applicable law. Pulsar Siedlec 150, 32-744 Łapczyca, Poland Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50 e-mail: biuro@pulsar.pl, sales@pulsar.pl http:// www.pulsar.pl, www.zasilacze.pl...
