- Page 1 HPSBOC 2524B v.1.0 HPSBOC 27,6V/2,2A/2x7Ah/OC Buffer, switch mode power supply unit with automatic operation control. Edition: 1 from 30.09.2014 Supersedes edition: -------------...
-
Page 2: Table Of Contents
Maximum battery charge current: 0,3A Total device current + battery: 2,5A max OPTIONAL POWER SUPPLY CONFIGURATIONS: (visualisation available at: www.pulsar.pl) 1. Buffer power supply unit HPSBOC27,6V/2x1A/2x7Ah. - HPSBOC2524B + LB2 2x1A (AWZ586) + 2x7Ah 2. Buffer power supply unit HPSBOC 27,6V/4x0,5A/2x7Ah. -
Page 3: Block Diagram
GREEN POWER plus www.pulsar.pl HPSBOC2524B - HPSBOC2524B + RN25024 (27,6V/24V) + LB2 2x1A (AWZ586) + 2x7Ah 5. Buffer power supply unit HPSBOC27,6V/24V/4x0,5A/2x7Ah. - HPSBOC2524B + RN25024 (27,6V/24V) + LB4 4x0,5A (AWZ574 or AWZ576) + 2x7Ah 6. Buffer power supply unit HPSBOC27,6V/5V÷18V/5V÷18V/2A÷1,3A/2x7Ah. - Page 4 GREEN POWER plus www.pulsar.pl HPSBOC2524B Fig. 2. The view of the PSU. Element no. Description [Fig. 3] PSU module TAMPER, contact, sabotage protection (NC) Tab.2. Output terminals of the PSU. Fig.3. The view of the PSU.
-
Page 5: Specifications
GREEN POWER plus www.pulsar.pl HPSBOC2524B 1.4 Specifications - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) Electrical parameters (tab. 3) PSU type A (EPS - External Power Source) 176÷264V AC Mains supply Current up to 0,72A@230VAC max. -
Page 6: Installation
GREEN POWER plus www.pulsar.pl HPSBOC2524B Operation safety (tab.5) Protection class PN-EN 60950-1:2007 I (first) Protection grade PN-EN 60529: 2002 (U) IP20 Electrical strength of insulation: - between input and output circuits of the PSU (I/P-O/P) 3000 V/AC min. - between input circuit and PE protection circuit (I/P-FG) 1500 V/AC min. -
Page 7: Installation Procedure
GREEN POWER plus www.pulsar.pl HPSBOC2524B 2.2 Installation procedure. 1. Before installation, cut off the voltage in the 230V power-supply circuit. 2. Mount the PSU in a selected location and connect the wires. 3. Connect the power cables (~230Vac) to L-N clips of the PSU. Connect the ground wire to the clip marked by the earth symbol PE (PSU module connector). -
Page 8: Technical Outputs
GREEN POWER plus www.pulsar.pl HPSBOC2524B 3.2 Technical outputs The PSU has indication outputs: FAC - absence of AC supply output: - OC type output that indicates AC power loss. Under normal status, with 230V AC supply, the output is connected to ground (L level –... -
Page 9: Maintenance
GREEN POWER plus www.pulsar.pl HPSBOC2524B 4.3 Maintenance. Any and all maintenance operations may be performed following the disconnection of the PSU from the power supply network. The PSU does not require performing any specific maintenance measures, however, in case of significant dust rate, its interior is recommended to be cleaned with compressed air. In case of fuse... - Page 10 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects, unless such...
