HPSBOC 5524C
v.1.0
HPSBOC 27,6V/5A/2x17Ah/OC
Buffer, switch mode power supply unit
with automatic operation control
EN
Edition: 2 from 13.02.2013
Supersedes edition: ______
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HPSBOC 5524C and is the answer not in the manual?

Questions and answers

Related Manuals for Pulsar HPSBOC 5524C

Summary of Contents for Pulsar HPSBOC 5524C

  • Page 1 HPSBOC 5524C v.1.0 HPSBOC 27,6V/5A/2x17Ah/OC Buffer, switch mode power supply unit with automatic operation control Edition: 2 from 13.02.2013 Supersedes edition: ______...

  • Page 2: Table Of Contents

    PSU, with high energy efficiency. The PSU is housed in a metal enclosure (colour RAL 9003) which can accommodate two 17Ah/12V batteries. A micro switch indicates door opening (front cover). OPTIONAL POWER SUPPLY CONFIGURATIONS: (visualisation available at: www.pulsar.pl) 1. Buffer power supply unit HPSBOC 27,6V/5x1A/2x17Ah. - HPSBOC5524C + LB8 5x1A (AWZ579 or AWZ580) + 2x17Ah 2.

  • Page 3: Block Diagram

    HPSBOC5524C 6. Buffer power supply unit HPSBOC 27,6V/2x24V/10x0,5A/2x17Ah. - HPSBOC5524C + 2 x RN25024(27,6V/24V) + 2xLB8 10x0,5A (AWZ578 or AWZ580) + 2x17 Ah 7. Buffer power supply unit HPSBOC 27,6V/2x24V/16x0,3A/2x17Ah. - HPSBOC5524C + 2 x RN25024(27,6V/24V) + 2xLB8 16x0,3A (AWZ577 or AWZ580) + 2x17 Ah 8.
  • Page 4 HPSBOC5524C Fig. 2. The view of the PSU. Element no. Description [Fig. 2] PSU module TAMPER, contact, sabotage protection (NC) Tab.2. Output terminals of the PSU. Fig.3. The view of the PSU.

  • Page 5: Specifications

    HPSBOC5524C 1.4 Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) Electrical parameters (tab. 3). Mains supply 176÷264V AC Current up to 1.4A@230VAC Supply power 155W max. Efficiency Output voltage 22V÷ 27,6V DC – buffer operation 19V÷27,6V DC –...

  • Page 6: Installation

    HPSBOC5524C Operation safety (tab.5). Protection class PN-EN 60950-1:2007 I (first) Protection grade PN-EN 60529: 2002 (U) IP20 Electrical strength of insulation: - between input and output circuits of the PSU (I/P-O/P) 3000 V/AC min. - between input circuit and PE protection circuit (I/P-FG) 1500 V/AC min.

  • Page 7: Installation Procedure

    HPSBOC5524C 2.2 Installation procedure. 1. Before installation, cut off the voltage in the 230V power-supply circuit. 2. Mount the PSU in a selected location and connect the wires. 3. Connect the power cables (~230Vac) to L-N clips of the PSU. Connect the ground wire to the clip marked by the earth symbol PE (PSU module connector).

  • Page 8: Operation And Use

    HPSBOC5524C CAUTION! In Fig.2. the contact set in the potential-free status corresponds to a state with no AC power (AC power failure). FPS – technical output indicating absence of DC voltage at the PSU: OC type output indicating the PSU failure.
  • Page 9 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects, unless such...
