Bijur Delimon V5 Assemblies

V5 Lubricator Assemblies
Automatic Continuous
Operation
The V5 Lubricator assemblies consist of a reservoir, low level switch, motor-driven gear pump, and
threaded return port or return filter. Pump also includes a built-in flow bypass valve. (Constant
volume) The fully automatic lubricating system is preset to max discharge from the factory.
Discharge volume may be adjusted by turning the bypass valve counter-clockwise to reduce.
Technical Data
Motor Type
Motor Voltage
Frequency
Speed
Start Amperage
Run Amperage
Maximum Ambient Temperature
Pump Discharge
Pump Inlet filter
Relief Valve
Motor Type
Motor Voltage
Frequency
Speed
Maximum Ambient Temperature
Pump Discharge
Pump Inlet filter
Relief Valve
Discharge Adjustment
The V5 Lubricator is fitted with a flow bypass valve(Constant volume). Pressure is limited internally to
130 psi by a relief valve (Some models limited to 200 psi). See page 23 for details.
System & Limitations
Use Type C control units. Viscosity range is 20 to 1500 cSt at operating temperature.
See Bijur Engineering Manual for system limitations.
1
72123/72124/72125/ CONTINUOUS DUTY, T.E.N.V.
72125-RF
72126/72126-RF CONTINUOUS DUTY, T.E.F.C.
115 VAC 1/20 hp, NEMA Frame L330, continuous duty
60/50 Hz
1725/1425 rpm (60/50Hz)
2.3/2.5 amp
0.78/0.67 amp (60/50Hz)
104°F (40°C)
132cc/min (110cc/min 50 Hz)
125 Micron
130 psi
72127/72127-RF CONTINUOUS DUTY, T.E.F.C.
230-240/400-415 VAC 50 Hz 0.10 / 0.08 hp 60/50 Hz
260-280/440-480VAC 60 Hz
60/50 Hz
1480/1230 rpm 60/50 Hz
104°F (40°C)
120cc/min (100cc/min 50 Hz)
125 Micron
200 psi
V5 72125
Use clean oil only of the type and viscosity
recommended by machine manufacturer.
Replace filter group annually.
Refer to the following data sheets
for available reservoirs:
+ Tech sheet #TS030
V5W Replacements
