Savaria V-1504 Owner's Manual

Hide thumbs Also See for V-1504:
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

SERVICES INDUSTRIELS
SAVARIA INC.
V-1504
OWNER'S MANUAL
07/2003
-3-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-1504 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Savaria V-1504

Summary of Contents for Savaria V-1504

  • Page 1 SERVICES INDUSTRIELS SAVARIA INC. V-1504 OWNER’S MANUAL 07/2003...

  • Page 2: Opening The Door

    (FIGURE 1.0). The key is in the operating position when it can not be pulled out. Always take the key out when the unit is not in operation. Apply constant pressure on the appropriate button to call the platform to the landing. The V-1504 will not move if one the doors is open.
  • Page 3 CAB CONTROLS FIGURE 2.0 KEY SWITCH ALARM BUTTON BUTTON DOWN EMERGENCY BUTTON STOP Key switch Needs to be on to activate the operating buttons. Up button Will move the platform in the up direction. Down button : Will move the platform in the down direction. Emergency stop : (Optional equipment) Will stop the platform instantly.

  • Page 4: Emergency Door Opening

    DOOR STRIKE ON DOORS PROVIDED BY SAVARIA The door can be opened manually using a ¼ inch allen key through the front hole in the door (see figure 4.0) This key is for emergency use only.
  • Page 5 REMOTE EMERGENCY MANUAL LOWERING DEVICE 120V AC PUMP The manual lowering box is located on the side of the V-1504. When you pull on the steel cable located inside the manual lowering box, the platform comes down. This mechanism should be used in case of emergency only.

  • Page 6: Maintenance

    A key switch, allowing to lower the platform manually, is located on the side of the V-1504. Insert the key (the same one than for the call/send control) and turn it in the operating position to lower the platform. This mechanism should be used in case of emergency only.
  • Page 7 chains connecting links chain pulleys and shafts parts holding the chains on the rollers supports chain tensioners on the rail (make sure they are tight) cylinder head (cotter pins, cracks, welds) state of the rollers up relays have relays (solenoids or contactors), make sure one of them is not stuck in the activated position.
  • Page 8 8 .0 Diagnosis Platform goes up but does not come down : Verify the underpan sensor (if equipped). Pull down on it to ensure the pan is not stuck in the activated position. Platform goes down but does not go up : Verify the power supply (breaker, cord, battery etc.).
  • Page 9 SERVICES INDUSTRIELS SAVARIA INC. warrants to the original consumer purchaser of this Savaria lift, that the company will repair or exchange, at its option, any part of the lift that fails by reason of defective material or workmanship as follows: Ø...
