- Page 1 V1504 VERTICAL PLATFORM LIFT ENCLOSURE INSTALLATION GUIDE Part No. 000615 21-m03-2023...
-
Page 2: Hazards And Warnings
ELECTRICAL SHOCK HAZARD • Plumb bob and line • Chalk line Savaria Concord Lifts, Inc. is not responsible for any • Reversible hand drill modifications of the product made by the user. • Step drill bit, 2 hole, 7/8” to 1-1/8” (to enlarge cable holes) Do not allow unqualified personnel to use equipment. -
Page 3: Table Of Contents
• April 24, 2019 – Revised STEP 23 on page 24 • August 9, 2019 – Enhanced line drawings throughout Appendix A: Cleaning • January 7, 2020 – Added new STEP 8 on page 12 to ensure enclosure trim clips are installed Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide... -
Page 4: Description Of Enclosure Walls
Detail 1 Detail 2 Typical door-wall installation Typical wall-wall installation WALL WALL SCREW #6 X 3/4 SCREW #6 X 3/4 DOOR Detail 3 SCREW #8 X 3/4 TOWER SCREW #6 X 3/4 V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023... - Page 5 They should already be installed at the top of the level 1 and intermediate walls. View 2: Typical top level door View 1: Typical top level wall Extrusion 27 WALL DOOR Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide...
-
Page 6: Assemble Enclosure Base (As Applicable)
Side piece Figure 2 Enclosure base assembly Corner piece Side piece Front piece Hole for jack bolt (use to Side piece level) Holes for anchoring (use shims as needed) Front piece Side piece V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023... - Page 7 (from kit 320448) inserted through the slots in the wall channel holders and into the pem nuts in the base pieces (see below). Figure 4 Install wall support channels Install wall support channel on base pieces at non-entrance sides (use bolts from kit 320448) Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide...
-
Page 8: Install Flexible Conduit For Wiring
IMPORTANT: If the enclosure is flush with the tower, you must install the tower cap first before installing the corner pieces in the next step. SCREW #6 X 3/4 V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023... -
Page 9: Install Narrow A And B Walls
Detail 1 or 2 below (as applicable). Repeat steps 1 through 4 for the second narrow wall. Detail 1 Detail 2 Typical door-wall installation Typical wall-wall installation WALL WALL SCREW #6 X 3/4 SCREW #6 X 3/4 DOOR Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide... -
Page 10: June 14, 2021 - Updated Step
Refer to Detail 1 or 2 at the right (as applicable). SCREW Figure 11 #6 X 3/4 Outside D wall SCREW #6 X 3/4 DOOR Figure 10 End E wall Outside D wall End E wall V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023... -
Page 11: Install End C Or E Wall
BC corner post using #6 x 3/4 flush screws. Refer to Detail 1 or 2 below (as applicable). Detail 1 Detail 2 Typical door-wall installation Typical wall-wall installation WALL WALL SCREW #6 X 3/4 SCREW #6 X 3/4 DOOR Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide... -
Page 12: Ensure Trim Clips Installed
Ensure that all enclosure walls have the trim clips installed. • 324758 - trim clip, small size • 32475A - trim clip, medium size • 324758-B - trim clip, large size Figure 13 Trim clips 324758-A 324758-B 324758 V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023... -
Page 13: Install Adjustable Sill (If Applicable)
Adjust the sill up or down as required (3/4” play up or down). Secure the sill to the enclosure using eight #6 screws. Figure 15 Adjustable sill - view from inside Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide... -
Page 14: Install Pit Switch In Narrow Wall
Relocate the strain relief connector where the hole is created. Route the cable through the hole on the enclosure panel and into the E-Stop box and complete the connections to the E-Stop contacts. V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023... -
Page 15: June 15, 2012 - Updated Step 14 And Removed Step
NOTE A GFI receptacle may be required depending on your local code. Savaria offers an optional kit P/N 324602 to meet this code requirement. Note that in most cases, a light is also required. It must be a very slim light that won’t interfere with cab operation). -
Page 16: Pull Wires Through And Feed Into Tower
Repeat the steps 1 and 2 for any wires at the other side of the tower. Route the wiring up to the terminal strip in the controller and connect per the wiring diagrams shipped with the lift. Figure 18 Flexible conduit installed Extrusion 23 V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023... -
Page 17: Install Tower-To-Enclosure Connecting Brackets
These brackets help to square the enclosure to the tower. Figure 21 Secure in place with hardware provided. Enclosure safety covers (at landing) Figure 20 Tower to enclosure connecting brackets 320204 320201 320204-L 320201-L Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide... - Page 18 For jobs with filler type extrusions, you need to the install the covers shown below at the top of the tower on both sides. Figure 22 Enclosure safety covers (at top of tower) BEFORE COVER COVER INSTALLED V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023...
-
Page 19: Install Base Conduit Covers
1/4” hardware (bolts, flat washers, lock washers) from kit 320448. Figure 23 Install conduit covers on base pieces Install covers on base pieces (front and sides) Install conduit covers on base pieces Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide... -
Page 20: Anchor Enclosure To Pit/Floor
Screws bolts under the base pieces. Figure 24 Anchor enclosure to pit/floor Hole for jack bolt (use to level) Use to anchor enclosure (install shims as needed) Figure 25 Shim 320651 V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023... -
Page 21: Install Sloped Roof
Procedure NOTE This procedure applies to the dome and sloped roof ONLY. Install caps on the tops of the enclosure walls and on the corner posts. Figure 27 Install caps Extrusion 27 Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide... -
Page 22: March 1, 2019 - Added Bracket Installation
Secure the dome to the top enclosure extrusions using #8 x 3/4 self-tapping pan head screws. The screws will be inserted horizontally through the vertical flanges. V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023... -
Page 23: Install The Sloped Roof (Optional)
At each corner, be sure to seal the entire joint of the roof support using silicone. Secure the roof to the top enclosure extrusions using #8 x 3/4 self-tapping pan head screws. Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide... -
Page 24: April 22, 2019 - Added New Step
Route the fan harnesses (323872) and connect them to the Y-adapter harness. Install bracket P/N 320620 in the gap between the tower cap and the dome roof as shown at the right. V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023... -
Page 25: Install The U Brackets (Optional)
Figure 32 U brackets U BRACKET (view from underneath) Secure the U bracket to the enclosure using the supplied brackets (as shown). Figure 34 Secure U bracket to enclosure ENCLOSURE U BRACKET Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide... -
Page 26: Install Tower Joint Plate (As Needed)
Position the plate at the proper location and then mark and drill the required holes in the back panel. See the drawing on the next page for details. Use the hardware in kit P/N 324236-KIT to secure the plate. Figure 35 Install tower joint plate TOWER JOINT PLATE V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023... - Page 27 Page 27 Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide...
-
Page 28: March 21, 2023 - Added Appendix A: Cleaning To
Apply a thin, even coat with a soft clean cloth and polish slightly with cotton flannel or a microfiber towel. Then wipe with a damp cloth to help eliminate electrostatic charges that can attract dust particles. V1504 Enclosure Installation Guide Part No. 000615, 21-m03-2023... - Page 29 • Any citrus-based cleaners. These above lists are for reference only and are not comprehensive. If you have any questions about the acceptability of a specific cleaner, please contact your authorized dealer. Part No. 000615, 21-m03-2023 V1504 Enclosure Installation Guide...
