Table 2. Chassis Activity LEDs for a IBM SAN48C-6 Switch (continued)
Indicator Location
PSU Status Faceplate of
Indicators each PSU
Fan Status Faceplate of
each fan module
The following table describes the Ethernet port LEDs for an IBM SAN48C-6 Fan switch.
LED Position
Left
Right
The following table describes the Fibre Channel port LEDs for an IBM SAN48C-6 switch.
Status
Solid Green
Regular Blinking Green
Intermittent Blinking Green
Solid Orange
Blinking Orange
Off

Transceivers

SFP+ transceivers are field replaceable. You can use any combination of SFP+ transceivers that are
supported by the switch. The only restrictions are that SWL transceivers must be paired with SWL
Function Color
PSU input/output Green
PSU operation Amber
Fan module Green
Amber
Status
Off
Solid Green
Off
Blinking Yellow
State
The link is up.
The link is up and the port beacon is active.
The link is up (and traffic is flowing through the port).
The link is disabled by the software.
A fault condition exists.
No link.
Chapter 1. Overview of the IBM SAN48C-6 Fibre Channel Switch 7
Status State
Off No input to the PSU.
Solid on PSU output is OK.
Blinking PSU output is not OK, but
input is OK.
Off PSU is operating normally.
Solid on One of the following
conditions exists in the
PSU:
• Over voltage
• Over current
• Over temperature
• Fan failure.
Blinking PSU has a fault, but is still
operational.
Solid on Fan module is operating
normally.
Solid on The fan in the fan module
has failed.
State
There is no link.
Indicates a physical link.
There is no link traffic.
Indicates link traffic.
