Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
ESD Sensitive Product
This product is Electrostatic Discharge
sensitive. The cable provided is
connected directly to the LED PCB.
Ensure appropriate grounding measures
are taken when installing this product.
Surge Protection
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and
secondary (Type 2) surge arrestors in compliance with EN61643-11/
IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and
activated prior to luminaire installation. Also, disconnect luminaires before
operating high-power devices such as, for example, electrical arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Projector
FLC121 #1 LED
FLC131 #1 LED
FLC141 #1 LED
INSTALLER
HOTLINE
+61 458 933 399
7am – 7pm AEST
Advertisement
Related Manuals for WE-EF FLC121
Summary of Contents for WE-EF FLC121
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Projector FLC121 #1 LED FLC131 #1 LED FLC141 #1 LED INSTALLER HOTLINE +61 458 933 399 7am – 7pm AEST Do not open during installation Surge Protection This product is factory-sealed. For comprehensive protection of a luminaire installation against lightning and...
-
Page 2: Mounting Accessories
Projector FLC121 #1 FLC131 #1 FLC141 #1 IP66, Class I, ta = 40°C Mounting Accessories SF-FLD1 for FLD/FLC100 #1 145-9535 SF-FLD1 CF-FLD1 for FLD/FLC100 #1 145-9536 CF-FLD1... -
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out Warning: Do not open luminaire while mains supply is switched on. - Page 4 Installation Procedure Installation – Installation – 1) Switch off and isolate the mains electrical supply. 1) Switch off and isolate the mains electrical supply. 2) Detach strain relief clip K D and cable Attention: Keep strain relief clip K for locking cable entry hole F.
- Page 5 Fig. I Strain relief clip locking...
- Page 8 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com WE-EF LIGHTING INSTALLER United Kingdom HOTLINE Tel +44 844 880 5346 +61 458 933 399 Fax +44 844 880 5347 7am – 7pm AEST info.uk@we-ef.com TO9210W0817 © WE-EF 2018 subject to change.
