Table of Contents

F F L C 1 3 1 # 2 L E D F L C 1 3 1 # 2 L f f d a s f d s f a d s f d s a f a s d f d s a f d s a f a s d f e
Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Projector
FLC121 #2 LED
FLC131 #2 LED
FLC131 #3 LED
FLC141 #3 LED
INSTALLER
HOTLINE
+61 458 933 399
7am – 7pm AEST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLC121 and is the answer not in the manual?

Questions and answers

Related Manuals for WE-EF FLC121

Summary of Contents for WE-EF FLC121

  • Page 1 Installation and Maintenance Instructions Projector FLC121 #2 LED FLC131 #2 LED FLC131 #3 LED F F L C 1 3 1 # 2 L E D F L C 1 3 1 # 2 L f f d a s f d s f a d s f d s a f a s d f d s a f d s a f a s d f e...
  • Page 2 Projector FLC121 #2 FLC131 #2 ø 105 FLC131 #3 FLC141 #3 ø 180 IP66, Class I /II , ta= 40°C ø 6.5-10.5 mm Weight for FLC121 #2 for FLC131 #2 for FLC131 #3 for FLC141 #3...

  • Page 3: Mounting Accessories

    Mounting Accessories Short Post EM EM1-2/M8 for FLC100 #2 or 3 146-0253 Planted root ESV4 for FLC100#2 or 3 300-0461 Short Post EM Planted root Note: The luminaire must be installed on an elevated concrete surface in landscape areas with poor drainage.

  • Page 4: Maintenance

    Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out by a suitably quali ed and trained professional.

  • Page 5: Installation

    Installation The product must be installed and maintained by a suitably quali ed professional in compliance with latest building/construction and/or electrical regulations and relevant legislation. Warning: Switch off mains electrical supply prior to installing and connecting the luminaire. Notice: If the luminaire is modi ed by anybody other than the original manufacturer, then the warranty will no longer be valid and shall become the full respon- sibility of the modifying person/organisation.

  • Page 6: Installation Procedure

    Drill relevant holes E and insert wall plugs F. Warning: Ensure not to damage any electrical 12/17 IP66 cable, water pipe or other devices while drilling holes. FLC121-LED 220-240V50-60/Hz 145-XXXX E XXXXXXX LED 3000K 12W item no. XXX (example)
  • Page 7 Feed mains supply cable G through the pressure 6) Connect mains supply cable G leads to screw I, while setting mounting ange A in respective terminals in terminal connector C position. To x mounting ange A, insert and (L = Phase, N = Neutral, = Earthing).
  • Page 8 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com INSTALLER HOTLINE +61 458 933 399 7am – 7pm AEST TO9206W0519 FLC100TYP23_150221_REV1 © WE-EF 2021 Technical speci cations are subject to change.
