WE-EF FLC121 Installation And Maintenance Instructions Manual

Hide thumbs Also See for FLC121:

Download this manual

Do not open during installation

This product is factory-sealed.

Refer to the instructions contained in this

document for details.

Surge Protection

This product features built-in surge protection circuitry in compliance with

applicable standards.

For comprehensive protection of a luminaire installation against lightning and

electrical surges, it is essential to cover mains supply and data input lines at

the distribution board level, by using respective primary (Type 1) and secondary

(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.

Warning

Ensure that all required surge protection measures are in place and activated

prior to luminaire installation. Also, disconnect luminaires before operating

high-power devices such as, for example, electrical arc welders.

WE-EF LEUCHTEN

Installation and Maintenance

Instructions

Projector

FLC121 #2 LED

FLC131 #2 LED

FLC141 #3 LED

Need help?

Do you have a question about the FLC121 and is the answer not in the manual?

Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Projector FLC121 #2 LED FLC131 #2 LED FLC141 #3 LED Do not open during installation Surge Protection This product is factory-sealed. This product features built-in surge protection circuitry in compliance with Refer to the instructions contained in this applicable standards.
Page 2 Projector FLC121 #2 ø 105 FLC131 #2 FLC141 #3 ø 180 IP67, Class I, ta= 40°C Weight for FLC121 #2 for FLC131 #2 for FLC141 #3 ø 6.5-10.5 mm...
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out Warning: Do not open luminaire while mains supply is switched on.
Page 4: Installation Procedure
Installation Installation Procedure The product must be installed and maintained by a 1) Switch off mains electrical supply. A by loosening screw B. building/construction and/or electrical regulations and Detach terminal connector C. relevant legislation. 3) Check that rating shown on luminaire label conforms with mains electrical supply.
Page 6 Fig. I...
Page 7 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com WE-EF LIGHTING United Kingdom Tel +44 844 880 5346 Fax +44 844 880 5347 info.uk@we-ef.com TO9206W0617 © WE-EF 2017 subject to change.

Flc131 Flc141
