SMC Networks ITV1000 Series Operation Manual page 9

System configuration / Applications / Specifications
This product is connected to the field bus (PROFIBUS) as a DP slave.
Other DP equipment
< Example of system configuration >
As shown in the structure example above, this product is to control air pressure for pneumatic
equipment. Do not use it for any other application.
Specifications
Model
Minimum supply pressure
Maximum supply pressure
Set pressure range
Voltage
Power
source Current consumption
Linearity
Hysteresis
Repeatability
Sensitivity
Temperature characteristics
Ambient temperature
Standards
Protective structure
Model
Size (mm×mm×mm)
Weight (No option)
Master
PROFIBUS-DP
Slave1
・
Other DP equipment
ITV1010
ITV2010
ITV3010
0.2MPa
0.005〜0.1MPa
ITV10※0
50×50×124
350ｇ
Power SUP.(DC24V)
Slave2
・
The compress
air is supplied
from the first
side.
ITV1030
ITV2030
ITV3030
Set pressure + 0.1MPa
1.0MPa
0.005〜0.5MPa
DC２４V±１０％
０．１６A or less
±１％F.S. or less
０．５％F.S. or less
±０．５％F.S. or less
０．２％F.S. or less
±０．１２％F.S. or less／℃
0 to 50℃(No freezing)
CE marking, UL(CSA)
IP65
ITV20※0
50×50×146
450ｇ
―9―
The pressure
proportional
to the signal
on the second
side is
obtained.
ITV1050
ITV2050
ITV3050
1.0MPa
0.005〜0.9MPa −1.3〜−80kPa
IP65 equivalent
ITV30※0
66×66×167
−
ITV2090
−
Set pressure
−13.3kPa
−101kPa
750ｇ
