Directed XpressStart Basic Installation Instructions page 4

KeylessGo Connection
Tools and Parts Required:
T-20 Driver
Pick Tool
Panel Removal Tool
Description
In order to activate KeylessGo vehicle entry during remote start, an extra harness will have to be run to a separate CAN connector
in the vehicle. The aforementioned harness will be plugged into the 2 pin port next to the main connector on the XPRESSSTART
module. These instructions assume the XPRESSSTART has already been installed in the vehicle and is working properly.
Instructions
1. Locate the CAN distribution block that houses the KeylessGo connector. (see location chart below)
2. Remove all connectors from the block that contain brown and brown/red twisted wires.
3. Locate the KeylessGo module (see location chart below)
4. Unplug the KeylessGo module.
5. Unclip and remove the connector cover from the KeylessGo connector.
6. Locate the twisted brown and brown/red wires in the plug.
7. Insert a 10k resistor between the brown and brown/red wires in the connector.
8. Using your meter, measure the resistance between the two wires on each plug at the CAN block that were removed in step 2
until you find the plug that reads 10k across the two wires.
9. Plug all the other connectors back into the CAN block except for the KeylessGo connector that you located in step 8
10. Using a pick tool or small flat blade, open the retaining clip that holds the connecting terminals on the side of the connector
housing.
11. Using a pick tool or small flat blade release the tabs on each pin and remove them from the connector housing. There are 2
separate times the release tab will need to be pressed down to remove it from the connector housing.
12. Close the retaining clip and put the empty connector housing back into the CAN block.
13. Insert the pins into the provided plug housing making sure the polarity is correct with the extension harness coming from the
XPRESSSTART. Brown/red--->Brown/red and Brown--->Brown
14. Close the retaining clip on the new connector.
15. Plug the connector in to the harness from the XPRESSSTART.
Note: Please visit www.xpresskit.com for vehicle specific installation instructions.
Location chart
Vehicle CAN Block
2006-2012 GL Right side compartment in cargo area
2006-2011 ML* Passenger front kick panel*
2006-2010 R* Passenger front kick panel*
2011-2012 R* Passenger front kick panel*
2007-2010 S, CL Under rear of driver's front seat
2011-12 S, CL Under rear of driver's front seat
2010-12 E cpe/sdn Passenger front door jamb in wire trough
2012 CLS Passenger front door jamb in wire trough
2010-12 E convert. Passenger front door jamb in wire trough
2008-2012 C Passenger front door jamb in wire trough
2010-2012 GLK Passenger front door jamb in wire trough
2011-12 E Wagon Passenger front door jamb in wire trough
2012 ML** CONNECT DIRECTLY TO KG MODULE
2013 GL** CONNECT DIRECTLY TO KG MODULE
* ML and R class do not require to change connector plug (steps 10-14 not required). They just need to be plugged into the
extension harness once the correct connector is found in the block.
** 2012 ML uses a special KeylessGo harness that is connected directly to the KeylessGo module instead of to the CAN block like
other vehicles. Please see the specific W166 keyless go instructions.
