Kolver EDU2AE Manual page 2

EDU 2AE and EDU 2AE/HP power supply/control units are an innovative system for controlling the torque
of any current control PLUTO electric screwdriver: PLUTO 3, PLUTO 6, PLUTO 10, PLUTO 15, PLUTO
20 and PLUTO 35, either inline, pistol, with angle head or for automation. It's also possible to use the
following clutch models: PLUTO 3FR, PLUTO 5FR and PLUTO 7FR.
EDU 2AE and EDU 2AE/HP deliver all the advantages of precision torque control electric tools at a fraction
of the price of transdurized tools. The state-of-the-art electronic control circuit cuts the power supply to the
motor calculating the correct torque in response to 3 parameters; voltage, frequency and current, according
to the selected options.
Model
PLUTO 3P
PLUTO 6P
PLUTO 10 P/N
PLUTO 15 P/N
PLUTO 3P/U
PLUTO 6P/U
PLUTO 10 P/U/N
PLUTO 15P/U/N
PLUTO 3D
PLUTO 6D
PLUTO 10 D/N
PLUTO 15 D/N
PLUTO 20CA/SR
PLUTO 35CA/SR
PLUTO 3CA
PLUTO 6CA
PLUTO 10CA/N
PLUTO 15CA/N
PLUTO 20CA
PLUTO 35CA
PLUTO 08 ANG
PLUTO 15 ANG
PLUTO 20 ANG
PLUTO 3FR
PLUTO 5FR
PLUTO 7FR
Torque (Nm)
Code
SOFT
Pistol grip (PLUTO P)
130204 0,3-2,0
130207 0,5-6,0
130210/N 2,0-8,0
130215/N 2,0-15,0
Pistol grip top connector (PLUTO P/U)
130204/U 0,3-2,0
130207/U 0,5-6,0
130210/U/N 2,0-8,0
130215/U/N 2,0-15,0
130203 0,3-2,0
130206 0,5-6,0
130211/N 2,0-8,0
130216/N 2,0-15,0
133221/SR 2,0-18,00
133236/SR 2,0-35,0
Automation (PLUTO CA)
130303 0,3-2,0
133206 0,5-6,0
130211/N 2,0-8,0
133216/N 2,0-15,0
133221 2,0-18,00
133236 2,0-35,0
With angle head (PLUTO ANG)
130208 1,0-6,5
130216/A 2-13,0
133220 2,0-17,0
With friction (PLUTO FR)
131203 0,5-3,2
131205 0,7-5,0
131207 1,5-7,0
Speed
HARD Min
0,3-3,0 370
0,5-8,00 200
1,5-10,0 110
2,0-15,0 60
0,3-3,0 370
0,5-8,00 200
1,5-10,0 110
2,0-15,0 60
In-line (PLUTO D)
0,3-3,0 370
0,5-8,00 200
1,5-10,0 110
2,0-15,0 60
2,0-20,00 40
40
0,3-3,0 370
0,5-8,00 200
1,5-10,0 110
2,0-15,0 60
2,0-20,00 40
40
1,0-8,0 110
2,0-13,0 100
2,0-19,0 60
800
0,5-3,2
600
0,7-5,0
350
1,5-7,0
Output
Max
1200 Hex 1/4"
920 Hex 1/4"
600 Hex 1/4"
320 Hex 1/4"
1200 Hex 1/4"
920 Hex 1/4"
600 Hex 1/4"
320 Hex 1/4"
1200 Hex 1/4"
920 Hex 1/4"
600 Hex 1/4"
320 Hex 1/4"
210 Sq 3/8 ''
140 Sq 3/8 ''
1200 Hex 1/4"
920 Hex 1/4"
600 Hex 1/4"
320 Hex 1/4"
210 Sq 3/8 ''
140 Sq 3/8 ''
600 Hex 1/4"
320 Sq 3/8 ''
210 Sq 3/8 ''
Hex 1/4"
1300
Hex 1/4"
1000
600
Hex 1/4"
Dimensions L x ø
mm
150x150x45
150x150x45
150x150x45
150x150x45
150x150x45
150x150x45
150x150x45
150x150x45
216x40
216x40
216x40
216x40
232,10x47
246,60x57
164x40
164x40
164x40
164x40
232,10x47
246,60x57
260x40
350,55x54
421,90x57
273x40
273x40
273x40
