SPARE PARTS

Position Description

1 Upper panel
2 Main PCB
3 Washer M3
4 Ground cable
5 Nut M3
PCB display
6
PCB display/HP
7 Spacer 15 mm
8 Front panel
Membrane
9
Membrane/HP
10 Connector M12 5 poles + nut
11 3x5 Button head screw
12 Plastic support
Bottom panel
13
Bottom panel/HPS
14 Transformer fixing plate
Transformer 230V 200VA
15
Transformer 110V 200VA
16 Transformer fixing screw M6x50
17 Serial print board/USB (optional)
18 Board support
19 I/O Connector 10 pin spacing 3,81
20 Fuse
21 Filtered plug
Quantity
1
1
2
2
6
1
4
1
1
1
13
4
1
1
1
1
1
2
1
2
1
Code
818003
852521
800041
800090/E
800056
852522
852522/HP
890004
818002
818004
818005
201666/R
872443
800016/B
818001
818007
See ref. 15
848009
848009/110
872430/N
852424
872442
800102
800619
8000718
