Distech Controls ECB Series Hardware Installation Manual page 14

Commissioning ECB-Series Controllers
When using an Allure EC-Smart-Vue Series Communicating Sensor for commissioning ECB Series controllers (the DIP switch located on the faceplate is
set to 0 (all off) and before code is downloaded to the controller from EC- gfx Program ), connect an Allure EC-Smart-Vue Series Communicating Sensor
to the controller with its Subnet ID set to 1.
During commissioning, the sensor is used to set the controller's BACnet
Set the connected controller's MAC Address as follows:
1. Connect an Allure EC-Smart-Vue Series Communicating Sensor to the controller with a Cat 5e patch cable. Wait for the display to show the room
temperature.
2. Press and hold the Menu button
3. Use the down button to set the number to 9995 (this is the default password).
4. Press the Menu button
5. Press the down button
dress.
6. Use the up and down buttons
7. Press the Menu button
8. Press and hold the Menu button
Once the controller's network is operational, the controller can be programmed with EC- gfx Program. For each Allure EC-Smart-Vue Series Communicat-
ing Sensor, set its Subnet ID number to the block number of its associated ComSensor block in EC- gfx Program. This is done in the sensor's GEN CFG
menu under SUBNET ID.
14 / 20
for 5 seconds to enter the password menu. 10000 is shown on the display.
to submit the password. Upon submitting the password, the GEN CFG menu appears on the display.
once to enter the GEN CFG submenu. The MAC ADDRESS menu is shown with the current controller's BACnet MAC Ad-
to set the controller's MAC Address. Only addresses from 1 to 127 are recommended to be used.
once to apply the value.
for 5 seconds to exit the configuration menu.
®
MAC Address.
Screen Timeout: 15 seconds
OR
Screen Timeout: 15 seconds
OR
Screen Timeout: 30 seconds
OR
Screen Timeout: 30 seconds
OR
