VBOX Micro

Configuring the VBOX Micro

Configuration of any of the VBOX Micro settings is performed using the VBOX Micro Setup
software supplied with the unit. You will need to power the VBOX Micro and make a connection
from its USB socket to a USB socket on your computer.
When you connect to the VBOX Micro via USB for the first time you will be required to install USB
drivers, please see the section 'Using USB' below.
Installing the VBOX Micro Setup Software
Insert the supplied CD-ROM into the CD drive of your computer. An installation dialog will
automatically appear; follow the onscreen instructions to complete the installation of the setup
software.
After installation the CD-ROM can be removed and two icons should have appeared on your
desktop that will allow you to start the VBOX Micro Setup software and the VBOXTools software
for post-processing data.
Running the VBOX Micro Setup Software
First, click on the Options button to select the correct COM port on your computer.
Now click the "Read Settings" button to enter the VBOX Micro setup screen.
Note: After changing any settings in the setup software you will
need to press the " Write Settings" button to confirm the changes in the
datalogger.
