VBOX Micro
Memory
External memory support
Recording time
Inputs
CAN Bus – RLVBMIC01
VCI CAN Input – RLVBMIC01C
Outputs
CAN Bus
Bit rate
Identifier type
Data available
Power
Input Voltage range
Current
Environmental and physical
Weight
Size
Operating temperature
Storage temperature
Definitions
** CEP = Circle of Error Probable
Hardware / Software Support
One Year Hardware/Lifetime Software Support Contract.
Compact Flash Card
Dependant on CF capacity. Approximately 4.4MB per hour at 100ms
per sample (10Hz) log rate, logging all standard GPS channels.
CAN connection for Racelogic modules only.
Allows the user to log incoming CAN data from other systems. Note:
Unit does not connect to other Racelogic CAN modules when VCI CAN
input is active.
125 kbit/s, 250kbit/s, 500kbit/s & 1Mbit/s selectable baud rate
Standard 11bit and Extended 29bit 2.0A
Satellites in view, UTC time, Latitude, Longitude, Speed, Heading,
Altitude, Vertical velocity, Longitudinal acceleration, Lateral
acceleration, Distance since reset
6-30V DC
Typically 70mA
Approx 275 grammes
105mm x 85 x 30mm
-10°C to +60°C
-40°C to +85°C
95% CEP (Circle Error Probable) means 95% of the time the position
readings will fall within a circle of the stated radius.
Lifetime Software Support Contract is valid for a minimum of 5 years
from the date of purchase and limited to original purchaser. Contract
includes telephone/email technical support provided by local VBOX
distributor and firmware/software upgrades where applicable.
