- Page 1 Instruction Manual The Lemonator Model No. 5314 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2022 Gold Medal Products Co. Part No. 110015...
-
Page 2: Table Of Contents
The Lemonator Model No. 5314 Table of Contents SAFETY PRECAUTIONS ........................... 3 INSTALLATION INSTRUCTIONS ........................4 Inspection of Shipment ............................4 Manual ................................... 4 Items Included with this Unit ..........................4 Setup ....................................4 OPERATING INSTRUCTIONS ......................... 5 Unit Disassembly/Assembly Instructions ..................6 Care and Cleaning ............................ -
Page 3: Safety Precautions
Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions. -
Page 4: Installation Instructions
1. Remove all packaging and tape. 2. Place the Cup Holder in position (see installation images below). 3. After setup, Gold Medal recommends that this unit be cleaned prior to use (see Care and Cleaning section of this manual). Pins provided to set Cup... -
Page 5: Operating Instructions
The Lemonator Model No. 5314 OPERATING INSTRUCTIONS 1. Place the unit on a smooth, level surface and attach it with the suction cups. 2. Put the Lemon Squeezer Bowl and one of the Cone options in place and ensure they are in the correct orientation (see image below). -
Page 6: Unit Disassembly/Assembly Instructions
The Lemonator Model No. 5314 Unit Disassembly/Assembly Instructions The following instructions are for disassembling and assembling the Lemonator. Use the Steps below to disassemble unit for general cleaning or repair: (2) Thumb Screws Step 1: Lift the Lemon Squeezer Cone Guide and Bowl out of the stand. -
Page 7: Care And Cleaning
The Lemonator Model No. 5314 Care and Cleaning Good sanitation practice demands that all food preparation equipment be cleaned regularly (only use non-toxic, food grade cleaners). A clean looking, well-kept machine is one of the best ways of advertising your product. Follow the directions below to clean and sanitize the unit each day after use. -
Page 8: Maintenance Instructions
The Lemonator Model No. 5314 MAINTENANCE INSTRUCTIONS DANGER Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death. Any alterations to this equipment will void the warranty and may cause a dangerous condition. This appliance is not intended to be operated by means of an external timer or separate remote-control system. -
Page 9: Ordering Spare Parts
4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Address all parts orders to Parts Department, Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 or place orders by phone or online:... -
Page 10: The Lemonator - Parts Breakdown
The Lemonator Model No. 5314 The Lemonator – Parts Breakdown gmpopcorn.com Page 10... - Page 11 The Lemonator Model No. 5314 The Lemonator – Parts List Part Number Item Part Description 5314 FRAME 38371 KNOB DUMP HANDLE 47110 HANDLE LEVER 38374 THUMB SCREW 1/4-20 X 3/4” (2 required) 38379 PUSH BLOCK 111334 GUIDE ROD 38376 RETURN SPRING (one used on each Guide Rod) 111480 CONE (with seeds) 114341...
-
Page 12: Warranty
The Lemonator Model No. 5314 WARRANTY Model 5314 parts are covered by a 10 Year Limited Warranty. gmpopcorn.com Page 12...
