- Page 1 Instruction Manual The QuickSpin Model Series: 3001 (000) 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2024 Gold Medal Products Co. Part No. 110324...
-
Page 2: Table Of Contents
The QuickSpin Model Series: 3001 (000) Table of Contents SAFETY PRECAUTIONS ........................... 3 INSTALLATION INSTRUCTIONS ........................5 Inspection of Shipment ............................5 Manual ..................................5 Model Description ..............................5 Items Included with this Unit ........................... 5 Setup for Use ................................6 Electrical Requirements ............................. -
Page 3: Safety Precautions
Read and understand operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862 022_060215 gmpopcorn.com... - Page 4 Unit is for cotton candy. Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions.
-
Page 5: Installation Instructions
The QuickSpin Model Series: 3001 (000) INSTALLATION INSTRUCTIONS Inspection of Shipment After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should be filed immediately with the transportation company. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control (reference warranty in back of manual). -
Page 6: Setup For Use
The QuickSpin Model Series: 3001 (000) Setup for Use General images shown for reference purposes only. 1. Make sure Power 2. Latch pan in Center head Switch is OFF. (4) places. in pan. Set unit on level Label goes on surface;... -
Page 7: Electrical Requirements
We recommend this equipment be on a dedicated and protected circuit. Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold Medal Products Co.’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety concerns, and may cause sacrificed and/or reduced performance. -
Page 8: Operating Instructions
The QuickSpin Model Series: 3001 (000) OPERATING INSTRUCTIONS Controls and Their Functions MAIN POWER SWITCH ON/OFF lighted rocker switch - supplies power to the control. HEAT MODE Switch (2 positions); HEAT STATUS Indicator Light Make Floss: Controls the floss head motor and heating element. Blinking Green QuickStart mode: Unit heating up to floss making temp. -
Page 9: Operating Instructions
The QuickSpin Model Series: 3001 (000) Operating Instructions For best results, use Gold Medal Flossugar in this machine (available in many flavors/colors). Images shown are for general reference only—see Setup section to prepare unit for operation. To Make Floss Floss should float upwards to be gathered, for issues see Troubleshooting section. -
Page 10: Shut Down Procedure/Care And Cleaning
The QuickSpin Model Series: 3001 (000) Shut Down Procedure/ Care and Cleaning DANGER Machine must be properly grounded to prevent electrical shock to personnel. DO NOT immerse in water. DO NOT clean appliance with a water jet or steam cleaner. Always unplug the equipment before cleaning or servicing. 025_051321 WARNING Burn Hazard. -
Page 11: Clean Unit Cabinet
The QuickSpin Model Series: 3001 (000) 8. After head cools, use a 9. Wipe, to clean off all fine grit steel wool pad, soap or residue. dampened with water, to remove carbon. (S.O.S. type pad ® is acceptable.) 10. When head is dry, reinstall cap and screws. - Page 12 The QuickSpin Model Series: 3001 (000) Issue Possible Cause Solution Error Detection: Indicator light is Blinking Yellow Two blinks repeating A. Shorted triac error. A. Control malfunction - unit is heating despite board current being turned off. Turn unit OFF; do not use the machine.
-
Page 13: The Following Sections Are For Qualified Service Personnel Only
The QuickSpin Model Series: 3001 (000) THE FOLLOWING SECTIONS ARE FOR QUALIFIED SERVICE PERSONNEL ONLY MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. Make sure all machine switches are in the OFF position before plugging the equipment into the receptacle. -
Page 14: Parts Installation
The QuickSpin Model Series: 3001 (000) Parts Installation Part installation or removal must be performed by qualified service personnel only. Unit must be OFF, unplugged and completely cool before beginning any service on this unit. General images shown for reference purposes only. When servicing, reference wire diagram for unit. Remove/Install Top Cover Remove top cover to access interior parts (save fasteners for reuse)—... -
Page 15: Replace The Belt
The QuickSpin Model Series: 3001 (000) Replace the Belt Instructions shown are to remove belt for reuse (save fasteners for reuse)—replace or install a new belt in reverse order. 1. Remove the top cover (see Remove/Install Top Cover section). To Reinstall: Make sure cap screws are fastened tight. -
Page 16: Replace Motor/Capacitor
The QuickSpin Model Series: 3001 (000) Replace Motor/Capacitor Instructions shown are to remove motor (save fasteners for reuse)—reinstall in reverse order. 1. Remove the top cover (see Remove/Install Top Cover section). 2. Open the front control panel (see Open/Close Control Panel section). Capacitor Disconnect Neutral from... -
Page 17: Replace The Spinner Head And Axes
(save fasteners for reuse): Important: Removing the Spinner Head from the Axes can damage the parts (break wiring/connectors) see examples below. Gold Medal recommends replacing both items if separated—damaged parts are not covered under warranty and must be replaced at your own expense. - Page 18 The QuickSpin Model Series: 3001 (000) Install a New Spinner Head and Axes Connect Neutral to terminal block. Connect Red to HEATER pos. on board. Axes Screws 2. Connect (2) heater wires to control panel— 1. Install axes in cabinet, fasten with (4) screws.
-
Page 19: Ordering Spare Parts
4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Address all parts orders to Parts Department, Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 or place orders by phone or online:... -
Page 20: Interior View
Reference the Maintenance section for instructions on accessing interior parts and for important replacement instructions. *Important Note: Removing the Spinner Head from the Axes can damage wiring/connectors. Gold Medal recommends replacing 7, 8 both items if they are separated (reference Maintenance section). General images shown for reference only (actual part view may vary). -
Page 21: Wiring Diagram
The QuickSpin Model Series: 3001 (000) Wiring Diagram Model No. 3001-00-000 gmpopcorn.com Page 21... - Page 22 The QuickSpin Model Series: 3001 (000) Model No. 3001-01-000 gmpopcorn.com Page 22...
-
Page 23: Warranty
No claim under this warranty shall be honored in the event that components in the unit at the time of the claim were not supplied or approved by Gold Medal Products Co. This warranty is effective only when electrical items have been properly attached to city utility lines only at proper voltages.
