Summary of Contents for Rexing W202 Mini
- Page 1 W202 Mini User Manual The information in this manual is subject to change without notice. www.rexingusa.com...
-
Page 3: Safety Information
REXING Dash Cam is not intended to be touched, modified, or calibrated while operating a vehicle. REXING is not responsible for any damages resulting from the user's misuse of the camera. Do not use damaged power cords or plugs, or loose electrical sockets. Faulty connections can cause electric shock or fire. - Page 4 Using an incompatible charger can cause serious personal injury or damage to your device. - REXING cannot be responsible for the user's safety when using accessories or supplies that are not approved by REXING. Do not drop the charger or device, or subject them to impact. Handle and dispose of the charger and device with care.
- Page 5 If you notice strange smells or sounds coming from your device, or if you see smoke or liquid leaking from the device, stop using the device immediately and take it to a REXING Service Center. Failure to do so may result in fire or explosion.
- Page 6 - Any changes or modifications to your device can void your manufacturer's warranty. If your device needs servicing, take it to an authorized REXING Service Center. Clean your device and charger by wiping with a towel or eraser. Do not use chemicals or detergents.
-
Page 7: Correct Disposal Of This Product
Correct disposal of this product (applicable in countries with separate waste collection systems) Waste Electrical & Electronic Equipment This symbol, found on the device, accessories or accompanying literature, indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste. - Page 8 "THIRD PARTY CONTENT AND SERVICES ARE PROVIDED "AS IS." REXING DOES NOT WARRANT CONTENT OR SERVICES SO PROVIDED, EITHER EXPRESSLY OR IMPLIEDLY, FOR ANY PURPOSE. REXING EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
-
Page 9: Warm Prompt
Third party services may be terminated or interrupted at any time, and REXING makes no representation or warranty that any content or service will remain available for any period of time. Content and services are transmitted by third parties by means of networks and transmission facilities over which REXING has no control. - Page 10 2. Please ensure that the Micro SD Card is inserted in the right way. If it is inserted backwards, it might damage the dash cam and Card. 3. If the Micro SD Card is not compatible with the dash cam, please DO NOT insert it again, as you will damage the Card and the dash cam.
- Page 11 11. If you want to playback the videos, we recommend unplugging your micro SD card and plugging into your PC with card reader. We recommend using VLC Video player Windows OS, and Movist + VLC on MAC OS. 12. After several weeks of daily recording it may be necessary for you to format your Micro SD Card - if that is the case, please note that you will lose all of your files, so please back up a copy on your computer first in a unique dash cam Folder that you have created.
-
Page 12: Device Layout
Device Layout... - Page 13 Button Functions • Press to turn on and off screen • Press and hold 3 seconds to turn the device on or off • Press to confirm a selection while in Setting Mode • Recording Mode Hot Key: Emergency Lock (Press to manually lock the file during recording) •...
-
Page 14: Installation
2. Connecting the charger to the car's 12V DC outlet Be sure to connect only the REXING-approved at least a 2A charger designed and supplied specifically for use with your device. Using an incompatible charger can cause serious personal injury or damage to your device. -
Page 15: Inserting The Memory Card
Inserting the memory card Your device accepts memory cards with a maximum capacity of 128GB. Depending on the memory card manufacturer and type, some cards may not be compatible with your device. Using an incompatible card may damage the device or the memory card, or corrupt the data stored on it. -
Page 16: Removing The Memory Card
Do not remove the memory card while the device is transferring or accessing information. Doing so can result in data loss or corruption, or damage to the memory card or device. REXING is not responsible for losses that result from the use of damaged memory cards, including the loss of data. - Page 17 We recommend formatting the card on dash cam before using. 1. Press the REC button to stop the device from recording 2. Press the MENU button twice to enter System Settings 3. Press the DOWN button to navigate to the "Format" option 4.
-
Page 18: Loop Recording
Loop Recording With Loop Recording Mode enabled, the device will continuously erase older video as it records new video, keeping only the images captured over a user-selected time range. All video older than this range will be replaced with new video. (Note: any locked video files on the memory card will remain protected, and will not be automatically deleted during Loop Recording.) It is recommended that you reformat a memory card after every time... -
Page 19: Record Audio
When enabled, this feature automatically adjusts exposure settings to improve recording quality in particularly bright or dim environments, providing balanced lighting and clearer recorded video. 1. Press MENU once to enter Video Settings 2. Press the UP or DOWN button to navigate to the "WDR" option 3. -
Page 20: Date Stamp
3. Press OK to view the current ON/OFF status for this feature 4. Press the UP or DOWN button to enable or disable this feature 5. Press OK to confirm your entry 6. Press MENU to exit Video Settings Alternatively, you can use a hot key shortcut for this feature. During Recording Mode, press the DOWN button to mute / unmute the microphone for video recording. -
Page 21: Plate Number
most crucial footage. Locked videos can be found on the memory card under “\CARDV\MOVIE\RO”. Note: Locked video files won’t be erased by Loop Recording, they will remain on the memory card until they are manually deleted, or when the card is formatted. Plate Number Enable this feature to enter a vehicle plate number for video recording. -
Page 22: System / Video Settings
Pull Mirror Default setting: Off Flip the image of the inside camera horizontally. SYSTEM / VIDEO SETTINGS Wi-Fi Default setting: Off Turn this feature on to temporarily enable Wi-Fi mode (See: Page 26). Date / Time Use the following procedure to change the device’s time and date: 1. -
Page 23: Beep Sound
When enabled, this option allows the device to shut down automatically if Recording Mode is not engaged. 1. Press MENU twice to enter System Settings 2. Press the UP or DOWN button to navigate to the "Auto Power Off" option 3. -
Page 24: Screen Saver
Language Use the following procedure to change the device’s time and date. Language availability may vary depending on the region. 1. Press MENU twice to enter System Settings 2. Press the DOWN button to navigate to the "Language" option 3. Press OK to view the current language selection 4. -
Page 25: Daylight Saving
1. Press MENU twice to enter System Settings 2. Press the UP or DOWN button to navigate to the "Screen Saver" option 3. Press OK to view the current selection: 1min / 3min / OFF 4. Press the UP or DOWN button to make your selection 5. -
Page 26: Default Settings
Format Performing this operation will format the memory card, clearing it of all files. Note: Locked videos will also be cleared, so ensure you have backed up your important footage before formatting the card. Default Settings Performing this operation will reset all of your device's settings to their original values. -
Page 27: Deleting Files
2. Press and hold the Menu button for about 3 seconds to switch from Recording to Playback Mode 3. Press and hold the UP or DOWN button to navigate through the stored video files 4. Press OK to start playback for the selected video 5. - Page 28 Store™ and Google Play Store™. • Android users: Enter the Google Play Store™, search for ‘TimaCam’, or ‘Rexing Connect’ download and install, following this user manual to connect the Wi-Fi and operate. • iPhone users: Enter the Apple App Store™, search for ‘TimaCam’, or ‘Rexing Connect’...
- Page 29 Operating System: Windows 7, 8, or 10 Display Resolution: 1280x720 Software Installation Please download the software via our official website below. https://REXING.us/download/ If you can’t install the MSI file on Windows 10, please search for “windows 10 msi installer issues” on Google.com. Accessing Video Files Insert the SD card into your computer to access the video files.
- Page 31 FCCID: 2AW5W-S1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
