Summary of Contents for Rexing V1P SE
- Page 1 V1P SE User Manual The information in this manual is subject to change without notice. Rexing All Rights Reserved www.rexingusa.com 202307REV1...
- Page 2 Activate Your 18-Month Warranty & Choose Your FREE Gift! Activate within 30 days of purchase to claim your free gift and extend your limited 12-month warranty to 18 months. Scan The QR To Activate & Select Your Free Gift https://www.rexingusa.com/productreg/...
- Page 3 (877) 740-8004 Our support team will respond to you as soon as possible. Always a surprise in Rexing. Check us out here • https://www.facebook.com/rexingusa/ • https://www.instagram.com/rexingdashcam/ • https://www.rexingusa.com/support/registration/ •...
-
Page 4: Package Contents
Rexing All Rights Reserved Paste the bracket into this circular area www.rexingusa.com www.rexingusa.com 202307REV1 Rexing V1P SE Dash Cam Cable Management Tool Rear camera with rear camera cable Safety Guide Mini-USB Cable (for transfer files only) User Manual Mount Plate & 3M Adhesive... -
Page 5: Camera Overview
Camera Overview Micro SD Card Slot OK (Confirm) Button Power Button MIC (Microphone) Button Reset Button Screen Button Menu Button Mini-USB Power Port Mode Button Rear Camera Port REC (Record) Button Lens Angle Adjustment Dial... - Page 6 00:00:20 00:00:20 UHD P24+FHDP24 UHD P24+FHDP24 AAAAAAAA AAAAAAAA 04 / 10 / 2021 17 : 25 : 45 04 / 10 / 2021 17 : 25 : 45 Recording Mode Time (24H) Recording (On) Current Date Time WDR Mode (On) MIC (Off) G-Sensor Sensitivity Level Exposure Value...
-
Page 7: Get Started
Get Started Step 1 Installing the Electrostatic Stickers 1.1 Prepare Your Windshield Thoroughly cleanse your windshield with either water or alcohol. Follow this by wiping it dry using a clean, dry cloth to ensure a spotless surface. 1.2 Position the Sticker Next, carefully peel off the protective film from the electrostatic sticker. - Page 8 Important! Ensure the T-interlock on the mount is oriented in the correct direction. Firmly press the mount onto the windshield. Wait at least 20 minutes before mounting the camera. Orient the mount as shown Step 3 Mount the Rear Camera Mount the rear camera as shown below.
- Page 9 Step 5 Insert the Memory Card The Rexing V1P SE accepts Class 10/ UHS-1 or higher Micro SD memory cards up to 512GB. You will need to insert a memory card before recording. Before inserting or removing a memory card, ensure you've powered down the device.
- Page 10 To ensure the V1P SE records to your memory card properly and without error, we strongly recommend you to format the card within the camera when you're using the dash cam for the first time.
- Page 11 To format the memory card, first press the REC button to stop recording. Then press the MENU button twice to enter the Setup Settings. Use the REC and MIC buttons and toggle to the Format. Pres the OK button to confirm the format.
-
Page 12: Basic Operation
Basic Operation Device Power The device is automatically powered on when plugged into a 12V accessory socket or cigarette lighter and receives a charge (i.e.: the vehicle is started). To turn the device on manually, press and hold the POWER button until the welcome screen appears. - Page 13 Menu Settings Power the camera on, then press the REC button to stop recording. Press the MODE button and switch among video mode, image mode and playback mode. Press the MENU button once to enter the Video Settings, or press the MENU button twice to enter the Setup Settings menu.
- Page 14 Video Recording The camera will automatically start recording when the device receives a charge. The LED lights and the red dot will blink when the device is recording. Press the REC button to stop recording. 00:00:20 UHD P24+FHDP24 These indicators will blink in red when the dash cam is recording.
- Page 15 During playback, use the OK (pause), MIC (fast forward) and REC (rewind) buttons to control the video playback. Playback mode 20210922162043_000014B FHD P30 21/09/22 16:20 Control playback with these buttons To playback a video by using an SD card reader, remove the memory card and insert it into an SD card adapter.
- Page 16 Parking Monitor (Parking Surveillance Mode) Parking monitor provides surveillance on your parked vehicle. When the engine is off, the hardwire kit is used to provide continuous power and protect your car battery from being discharged. Option 1: Vibration Detection To enable the Parking Monitor, you'll need to connect it with a Smart Hardwire Kit (UPC：857080006565, sold separately).
- Page 17 WITHOUT connecting a smart hardwire kit. They may cause a malfunction. Option 2: Motion Detection To use this feature, you need to connect it with a Rexing Intelligent Hardwire Kit (UPC：810046603178, sold separately). Make sure that the Parking Mode is turned off on your dash cam, otherwise it may cause a malfunction.
- Page 18 Wi-Fi Connect Step 1 With your dash cam powered on, hold the REC/MIC navigation button to enable the Wi-Fi function. The Wi-Fi name (aka the SSID) and password for the dash cam should be displayed on-screen. Step 2 On your mobile device, navigate to your Wi-Fi settings. Connect to your dash cam's Wi-Fi by tapping its name when it appears.
- Page 19 Step 3 Once you're connected to the dash cam, open the Rexing Connect app on your mobile device. Please select "Keep Trying Wi-Fi" if you see the notification on the right. Step 4 In the app, hit the "Connect" button to connect to your dash cam, allowing you to access live view and view/download your recordings.
- Page 20 Easily download the app by scanning the QR code below or search via the App Store or Google Play. Wi-Fi Connect Troubleshooting If you bring up the Rexing connect app and cannot connect your phone to the dash cam please go to https://www.rexingusa.com/wifi-connect/...
- Page 21 Built-in GPS Logger GPS logger will record the speed and location of your vehicle as you drive. You can then access this information while playing back your recordings using the GPS Video player. Press the MENU button twice and enter the Setup Settings. Toggle to the GPS Speed Unit and select your preferred speed unit.
- Page 22 Taking and Reviewing Photos take a photo, press REC button to stop recording. Press the MODE button twice to enter photo mode. Then press the OK button to take a photo. To view/delete a photo, stop video recording and enter the Playback Mode. Toggle through the videos and photos to the one you want to view/delete.
-
Page 23: Warranty And Support
Warranty & Support Warranty The Rexing V1P SE Dash Cam comes with a full 12-month warranty. If you register your product on our official site (https://www.rexingusa.com/support/registration), you can extend the warranty to 18 months. Support If you have any questions regarding your product, please do not hesitate to contact us at care@rexingusa.com, or call us at... - Page 24 FCC ID: 2AW5W-V1PGW This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
