Programming examples :
OPTION
The following example represents 3 different way to obtain a simple programming; the activation of the CMX-
2 output module as reply to a detector in alarm (or any other input device for the alarm).
OPTION A
Fire detection device
LOOP 1 – detector 1
Output device
LOOP 1 – output module 1
Equation of the detector = (G1)
Equation of the module = OR (G1)
GENERAL ALARM
The following example represents the method to programm the control panel for the general alarm.
Device for the
fire detection
L1S1
Software
Group
1
Output device
L1M2
The output module L1M2 is associated to the group G1 and will be activated in case of alarm on the
detectors L1S1 and L1S2.
The output module L1M3 is associated to the group G2 and will be activated in case of alarm on the detector
L1S3 or on the input module L1M1.
The output module L1M4 works like a device for the general alarm.
As all the device for the fire detection are associated to the group G3, it will be activated in case of alarm on
any device for the fire detection (detector or input module).
AM-1000
AM1000_manu
OPTION B
Fire detection device
LOOP 1 – detector 1
Output device
LOOP 1 – output module 1
Equation of the detector = ( )
Equation of the module = OR (L1S1)
Device for the
fire detection
L1S2
Software
Group
2
Output device
L1M3
Programming manual
Doc. M-145.2-AM1000-ENG Rev A.1
Fire detection device
LOOP 1 – detector 1
Output device
LOOP 1 – output module 1
Equation of the detector = (L1M1)
Equation of the module = OR ( )
Device for the
fire detection
L1S3
Software
Group
3
Output device
L1M4
OPTION C
Device for the
fire detection
L1M1
Page 39
