Technical Data - Fluke VIBCODE VIB 8.660 Manual

Technical data

PARAMETER
Signalling system
Transmission factor
(Ref.: 159 Hz; 25 °C [77°F])
Frequency range
Measurement range r.m.s.
Resonance frequency
Linearity range
Power supply
Noise, rms
Output impedance
Degree of protection
Transverse sensitivity
Temperature sensitivity
Magnetic sensitivity
Temperature range,
VIB 8.660
Temperature range,
VIB 8.660 HEX
Mounting
Weight
Cable connector
PARAMETER
Mounting
Material
Material
Resistance
Temperature range
Material
Resistance
Temperature range
VIBCODE sensor
Current Line Drive (CLD)
1.0 µA/ms ± 4%
-2
± 3dB 1.5 Hz ... 20 kHz
961 ms [ 98 g ]
-2
36 kHz
± 10% ± 50 ms [ ± 5 g ]
-2
> 10 mA / 7-18 VDC
< 1 mms / Hz
-2
> 500 kOhm
IP 65, w/ cable connected
< 10 % of axial value
< 0.3 ms /K
-2
< 14 ms /T bei 50 Hz
-2
- 10 °C ... + 70 °C [ 14°F ... +158°F ]
- 20 °C ... + 80 °C [ -4°F ... +176°F ]
bayonet mount
390 g
TNC
VIBCODE stud
Screw thread, adhesive, locking nut,
extension post
S t a i n l e s s s t e e l ( VA 1 . 4 3 0 5 /
VA1.4571)
Hostaform
®
coolant
Oil,
-40°C ... +130°C [ -40°F ... +270°F ]
Desmopan
®
coolant
Oil,
-30°C ... +100°C [ -22°F ... +212°F ]
at 10 Hz
-1/2
Dimensions
136 mm
5 3/8"
39 mm
1 5/8"
5
