VIBCODE sensors of series VIB 8.660 are used in
industry to measure the following parameters:
– Vibration acceleration on rotating machines
– Cavitation in pumps
– Shock pulse signals in roller bearings
The VIBCODE sensor is operated together with
a compatible, portable measuring device. For
measurement, the VIBCODE sensor is connected
to a coded VIBCODE stud, which is permanently
installed on the machine.
VIBCODE sensors of series VIB 8.660 HEX are per-
mitted for use in the Ex-zone in accordance with
ATEX guidelines.

Safety instructions

• Read these operating instructions carefully and
keep them in a safe place.
• Observe the operating instructions of the devic-
es to be connected.
• Only use the sensors as intended and only for
the permitted purpose of application.
• Only use original accessories.
• Replace defective sensors and cables.
• Have installation of the VIBCODE studs carried
out by qualified personnel exclusively.
• Comply with the applicable safety regulations
when performing installation tasks on the ma-
chine in operation.
• Observe the technical specifications and permis-
sible operating conditions. If in doubt, contact
PRUFTECHNIK.
• VIBCODE sensors are compliant with the appli-
cable European directives. The complete Decla-
ration of Conformity is available under www.
pruftechnik.com/certificates.
Safety instructions for installation and operation
in the Ex-zone:
• Only VIBCODE sensors of series VIB 8.660 HEX
are permitted to be operated in the Ex-zone.
• Sensors of series VIB 8.660 HEX are only to be
connected to certified intrinsically safe circuits
giving due consideration to the following max-
imum values:
U = 30 V; I = 63 mA; P
i i
C = 347 nF; L = negligibly small.
i i
• The following devices may also be connected
to the VIBCODE VIB 8.660 HEX with their
intrinsically safe analogue output circuits. The
connection must take place via a cable with a
maximum length of 10 m an inductance per
2
= 300 mW;
i
unit length of L' < 1µH/m and a capacitance per
unit length of C' < 120 pF/m.
– VIBSCANNER type VIB 5.400 EX / EC-Type Ex-
amination Certificate No. TÜV 01 ATEX 1699
– VIBXPERT type VIB 5.300 EX - xx / EC-Type Ex-
amination Cert. No. ZELM 07 ATEX 0355 X
• The permissible ambient temperature range is
between -20°C and +80°C [-4°F ... + 176°F].
• The European installation regulations are to be
observed (EN 60079-14).
• The information in the type-examination cer-
tificate is to be observed: TÜV 02 ATEX 1890,
incl. 1st supplement, issued october 6th, 2008.
Available on www.pruftechnik.com.
• Labeling of the sensors:
II 2G Ex ib IIC T4
Compatibility
• VIBCODE - VIB 8.660 HEX, S.N. > 00101
Device:
– VIBSCANNER EX, firmware > 1.66
– VIBXPERT EX, all versions
• VIBCODE - VIB 8.660, S.N. > 2362
Device:
– VIBSCANNER, firmware > 1.66
– VIBXPERT, all versions

Maintenance and repair work

Operation of the sensors does not require any
maintenance. Repair work by the user is not
possible.
Storage
• Store the VIBCODE sensor in the case of the
device.
• Conditions at the storage location:
– Dry and free of dust
– Temperatures are within the permissible range
– Vibration-free
– No high electromagnetic fields
– No corrosive materials
Disposal
After use, dispose of the sensor in an environ-
mentally friendly manner and in accordance with
national provisions.
