- Page 1 Assembly Instructions K-QUA1501A...
- Page 3 １...
- Page 4 Screw Shelf support pin Screw Wooden dowel Cam bolt Cam lock Ø4x50mm Sticker Ø8x5x16mm Ø4x38mm Ø8x30mm Ø6x35mm Ø15x11mm G x 4 F x 8 A x 28 B x 12 C x 12 D x 12 E x 12 Handle bolt Bolt Plastic wedge Flat-head screw...
- Page 5 · Screw parts (B) into panels (7). Ø6x35mm ３...
- Page 6 · Insert dowels(A) into panels(3,6). · Attach panels (7) to panels (3,6). · Insert and secure cam lock (C) to panels (3,6) to lock it. Ø8x30mm Ø15x11mm ４...
- Page 7 · Insert dowels(A) into panels(8). · Attach panels (3,6) to panels (8) using screws(G) Ø8x30mm Ø4x38mm ５...
- Page 8 · Insert dowels(A) into panels(3,4,5,6). · Attach panels (3,4,5,6) to panel (2) using screws(F). x 10 Ø8x30mm Ø4x50mm ６...
- Page 9 ·Carefully slide panels (9,10,11) into place along the back of the assembly. ７...
- Page 10 · Screw parts (B) into panels (1) · Attach parts(P) to panels(1) using screws(Q) as shown. Ø3x15mm ８...
- Page 11 · Insert dowels(A) into panels(3,4,5,6). x 10 · Attach panel (1) to panels (3,4,5,6). · Insert and secure cam lock (C) to panels (3,4,5,6) to lock it. Ø8x30mm Ø15x11mm ９...
- Page 12 · Attach parts (17) to parts (16) using Bolts(K). Ø6x13mm １０...
- Page 13 x 12 · Attach parts(16,17) to panel(2) using Bolts(L). Ø6x57mm １１...
- Page 14 x 14 x 14 · Secure parts(H) using Screws(I). Ø3x17mm １２...
- Page 15 x 12 · Attach panelS(12,13) to panels(3,4,5,6) using parts(E). Ø8x5x16mm １３...
- Page 16 · Attach parts(S) to panels(14,15) using Screws(T). · Attach parts(O) to panels(14,15) using Screws(N). · Attach parts(R) to back of panels(14,15) using Screws(T). x 14 Ø5/32"x22mm Ø3x12mm １４...
- Page 17 x 12 Attach panels(14,15) to panels(7) using Screws(T). Ø3x12mm １５...
- Page 18 WARNING Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from tipping over we recommend that it is permanently fixed to the wall. Wall anchor and hardware are included with this product. Please make sure hardware is suitable for your walls before installing, as different wall materials may require different types of anchors.
- Page 19 · Stick stickers(D) on cam lock(C). x 12 Final Assembly １７...
