- Page 1 Assembly Instructions W06F4053W W06F4054C Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.
-
Page 4: Table Of Contents
Plastic wedge Cam bolt Cam lock Wooden dowel Cam bolt Cam lock Ø6x29mm Ø14x11mm Ø8x30mm Ø6x35mm Ø15x11mm x 24 x 12 x 12 Screw Flat-head screw Glue tube Screw Handle Handle bolt Ø4x40 Ø3x16mm Ø4x30 Ø5/32x12mm x 20 Screw Screw Screw Footpads Screw... -
Page 5: A X
●The provided glue(H) is to secure When first inserting dowels, locate the wood dowels(A) in place. appropriate hole for the dowel , place a small amount of glue in the hole and insert the dowel. Wipe away excess glue immediately. ●... - Page 6 · Attach panels (6) to panels (4,5). x 12 · Insert and secure cam locks (C) to panels (4,5) to lock it. · Attach panels (9) to panels (4,5) with screw (I).
-
Page 7: M X
Step 1 Step 2 Slider arm Slider bracket · Separate the slide bracket from the slide arm as per diagram. - Page 8 · Attach slider arms to panels (4,5) with screws (N) correctly. x 12...
- Page 9 · Insert dowels (A) into panel (2). · Attachpanels (4,5) to panel (2) correctly. · Insert and secure camlocks (C) to panel(2) to lock it.
-
Page 10: B X
· Screw Cam bolts (B) into panel (1). · Attach panels (4,5) to panel (1). · Insert and securecamlocks (C) to panels (4,5) to lock it. - Page 11 · Carefully slide panel (7) into place along the back of the assembly. · Attach panel (3) to panels (4,5) with screws (J).
- Page 12 · Attach legs (8) to panel (3) . · Stick the skid pad (O) on the bottom of the legs (8).
-
Page 13: U X
· Attach socket (U) to panel (1) with screws (P) correctly. · Secure parts (F) with Screws (G). - Page 14 · Attach panels (11,12) to panel (13) with screws (I). · Carefully slide panel (14) into place along the bottom of the assembly...
-
Page 15: K X 4 L X
Rotate 90° · Screw Cam bolts (E) into panels (10). · Attach Handles (L) to panels (10) with bolts (K). · Attach panels (10) to panels (11,12). · Insert and secure cam locks (D) to panels (11,12) to lock it. - Page 16 Rotate 180° x 12 · Attach slider brackets to panels (11,12) with screws (N) correctly.
- Page 17 Slider arm Slider bracket Adjust Height · Assembled the drawers as per diagram Note : If the drawer does not go in smoothly. Press or lift the plastic release lever. Pull out the slider bracket from the slider arm. Loosen the screws (N) on slider brackets, You can adjust up or down by a few mm.
-
Page 18: Q X 1 R X
WARNING Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from tipping over we recommend that it is permanently fixed to the wall. Wall anchor and hardware are included with this product. Please make sure hardware is suitable for your walls before installing, as different wall materials may require different types of anchors.
