- Page 1 Assembly Instructions W11F7140W-W11F7141C Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.
- Page 4 ●The provided glue(A) is to secure wood dowels(B,C) in place . When first inserting dowels, locate WOODEN DOWEL WOODEN DOWEL CAM LOCK GLUE the appropriate hole for the dowel , Ø15 x 9mm Ø8x30mm Ø6x30mm place a small amount of glue in the x 46 x 16 x 30...
- Page 5 Tipping restraint hardware kit (inside plastic bag) Tools Required (Not included)
- Page 6 ●Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratches. · Insert dowels (B) into panels (3,4). · Screw cam bolts (E) into panels (3,4).
- Page 7 · Insert dowels (B) into panels (6,9,10). x 10 · Screw cam bolts (E) into panels (9,10). · Attach panel (11) to panel (10) with screws (L).
- Page 8 2 Person Task · Attach panels (6,9) to panel (4). · Insert and secure cam locks (D) to panels (6,9) to lock it.
- Page 9 2 Person Task · Attach panels (6,9,10) to panels (3,4). · Insert and secure cam locks (D) to panels (6,9,10) to lock it. · Attach panel (11) to panels (3,4) with screws (P) .
- Page 10 x 12 · Insert dowels (B) into panels (7,12).
- Page 11 2 Person Task ·Attach panels (7) to panels (9,10) with screws (L).
- Page 12 ·Attach panel (12) to panels (9,10) . ·Insert and secure cam locks (D) to panel (12) to lock it.
- Page 13 2 Person Task x 10 ·Attach panel (2) to panels (3,4,6,12) with screws (L).
- Page 14 · Attach legs (8,15) to panel (2). · Stick the skid pads (M) on the bottom of the legs (8).
- Page 15 Carefully slide part (5) into place along the back of the assembly. ·...
- Page 16 · Screw cam bolts (E) into panel (1).
- Page 17 2 Person Task · Attach panel (1) to panels (3,4,7) . · Insert and secure cam locks (D) to panels (3,4,7) to lock it. · Adjust part (15) to level the unit.
- Page 18 · Stick stickers (F) on cam locks (D). x 18 x 10 x 10 · Secure parts (N) to panels (1,3,4) using screws (O).
- Page 19 · Screw cam bolts (E) into panel (13,14,16). x 12...
- Page 20 · Attach panels (17,18) to panel (19) with screws (K). x 12 · Carefully slide part (20) into place along the back of the assembly.
- Page 21 · Attach Handles (G) to panels (13,14,16) with bolts (H). · Attach panels (13,14,16) to panels (17,18). · Insert and secure cam locks (D) to panels (17,18) to lock it. x 12...
- Page 22 · Screw cam bolts (E) into panels (21,22). x 16 x 16 · Insert dowels (C) into panels (23,24).
- Page 23 · Attach panels (23,24) to panel (25) with screws (K). x 16 · Carefully slide part (26) into place along the back of the assembly.
- Page 24 · Attach Handles (I) to panels (21,22) with bolts (J). · Attach panels (21,22) to panels (23,24). · Insert and secure cam locks (D) to panels (23,24) to lock it. x 16...
- Page 25 · Stick stickers (F) on cam locks ( D). x 28 Slider arm Slider bracket · Assembled the drawers as per diagram Note : If the drawer does not go in smoothly. Press or lift the plastic release lever. Pull out the slider bracket from the slider arm.
- Page 26 WARNING Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from tipping over we recommend that it is permanently fixed to the wall. Wall anchor and hardware are included with this product. Please make sure hardware is suitable for your walls before installing, as different wall materials may require different types of anchors.
