Summary of Contents for evoheat CS
-
Page 2: Table Of Contents
Page 1 EvoHeat CS & CS-GEN2 Series Manual Contents 1. Introduction ............................... 2 2. Unit Dimensions ............................3 3. Safety Instructions ............................ 4 4. Installation ..............................4 4.1 System Installation ..........................4 4.2 Location of Installation ........................5 4.3 Airflow Clearances ..........................5 4.4 Adequate Water Flow .......................... -
Page 3: Introduction
The data above is based on the EVO heat pump only, it does not include auxiliary devices. Product specification information provided above is correct at the date of printing, this data may change without notice. Please speak with an EvoHeat Specialist for the most current product specifications. -
Page 4: Unit Dimensions
Page 3 EvoHeat CS & CS-GEN2 Series Manual 2. Unit Dimensions Unit: mm A (L) B (W) C (H) CS38, 47 & 57 1490 1200 1464 CS95-GEN2 2170 1070 1920 CS120 & 145-GEN2 2175 1070 2030 1800 1020 CS200-GEN2 2180... -
Page 5: Safety Instructions
EVOHEAT ACCESSORIES – DO NOT THROW AWAY All EvoHeat units are provided with rubber feet, controller and leads for the controller– do not throw them away as they are required as part of the installation. -
Page 6: Location Of Installation
If you do not have a location with these suggested clearances, please contact our EvoHeat Tech Support Specialist to discuss appropriate installation locations. -
Page 7: Adequate Water Flow
It is CRITICAL that there is sufficient water flow to the unit. Incorrect water flow can cause a loss of efficiency and possible damage to the unit. Optimal water flow rates are listed in the EvoHeat manual. It is imperative that water flow is kept as close as possible to these flow rates. -
Page 8: Electrical Connection
3 phase heaters. If 2 lights are showing on the 3 PHASE relay monitor this means the EvoHeat heat pump has been wired correctly (one orange light and one green light). If only one light is showing, the phases are out of rotation and need to be rotated to get the correct phase rotation. -
Page 9: Operation
Page 8 EvoHeat CS & CS-GEN2 Series Manual 5. Operation 5.1 The Controller Press this button to start up/shut off the unit, ON/OFF cancel current operation or go back to previous interface. Press this button to check button function of HELP system state. -
Page 10: System State Checking
Page 9 EvoHeat CS & CS-GEN2 Series Manual 5.2.4 System State Checking At any interface you can enter the system working state by pressing TWICE, then using the UP and DOWN arrow keys to highlight the required parameter, then press to enter. - Page 11 Page 10 EvoHeat CS & CS-GEN2 Series Manual 5.2.7.1 Timer Each timer has an ON value when the unit will turn on an OFF value when the unit will turn off (00:00-00:00). These timers are required for the Daily Timers & Temperature Timers to work.
-
Page 12: Keyboard Lock
Page 11 EvoHeat CS & CS-GEN2 Series Manual 5.2.8 Keyboard Lock You may wish to lock the keyboard to prevent unauthorised users from adjusting settings. When the keyboard is locked, a small lock symbol will be displayed on the screen. -
Page 13: Troubleshooting
WATER IN temp. Check also the INLET WATER TEMP is lower than the HEAT TEMP set point. If the gauge shows less than 0.8MPA contact EvoHeat tech support to check the refrigerant system. IS THE FAN... -
Page 14: Error Codes
Page 13 EvoHeat CS & CS-GEN2 Series Manual 6.1 Error Codes CODE FAILURE REASON SOLUTION Power on Normal working Inlet temp. sensor failure The temp sensor is broken or short circuit Check or change the temp. sensor Outlet temp. sensor failure The temp sensor is broken or short circuit Check or change the temp. -
Page 15: Appendix
Page 14 EvoHeat CS & CS-GEN2 Series Manual 7. Appendix 7.1 Cable Specifications Single Phase Unit Nameplate maximum current Phase line Earth line Creepage Protector Signal Line No more than 10A 2 x 1.5mm 1.5mm 10~16A 2 x 2.5mm 2.5mm... -
Page 16: Wiring Diagrams
Page 15 EvoHeat CS & CS-GEN2 Series Manual 7.3 Wiring Diagrams info@evoheat.com.au 1300 859 933 www.evoheat.com.au... - Page 17 Page 16 EvoHeat CS & CS-GEN2 Series Manual info@evoheat.com.au 1300 859 933 www.evoheat.com.au...
- Page 18 Page 17 EvoHeat CS & CS-GEN2 Series Manual info@evoheat.com.au 1300 859 933 www.evoheat.com.au...
- Page 19 Page 18 EvoHeat CS & CS-GEN2 Series Manual info@evoheat.com.au 1300 859 933 www.evoheat.com.au...
- Page 20 Page 19 EvoHeat CS & CS-GEN2 Series Manual info@evoheat.com.au 1300 859 933 www.evoheat.com.au...
- Page 21 Page 20 EvoHeat CS & CS-GEN2 Series Manual info@evoheat.com.au 1300 859 933 www.evoheat.com.au...
- Page 22 Page 21 EvoHeat CS & CS-GEN2 Series Manual info@evoheat.com.au 1300 859 933 www.evoheat.com.au...
-
Page 23: Maintenance
EvoHeat CS & CS-GEN2 Series Manual 8. Maintenance It is recommended that you get your EvoHeat unit serviced once a year by your local certified air conditioning or refrigeration technician. If your unit is located in a coastal area, more frequent maintenance may be necessary. During the service,... -
Page 24: Warranty
REGISTER YOUR WARRANTY EvoHeat highly recommend customers complete their warranty details online to ensure efficient warranty claim processing. To register your warranty, scan our QR Code or head to our website and fill in the Warranty Registration Form: https://evoheat.com.au/warranty-registration/... - Page 25 It’s more than just a routine check, keep your Evo heat pump operating at its optimum performance with our Commercial Services Plan. Contact us on service@evoheat.com.au or Ph:1300 859 933 to get more information on our EvoHeat commercial service plan...
