evoheat CS Series Owner's Manual

Hide thumbs Also See for CS Series:

Advertisement

Quick Links

Download this manual
CS Owner's Manual
Updated: June 2019
Page: 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CS Series and is the answer not in the manual?

Questions and answers

Related Manuals for evoheat CS Series

Summary of Contents for evoheat CS Series

  • Page 1 CS Owner’s Manual Updated: June 2019 Page: 1...

  • Page 2: Table Of Contents

    Maintenance Energy Saving Tips Warranty details Warrant registration card Cautions and warnings EvoHeat have their own dedicated EvoHeat YouTube Channel that features step by step video instructions on using your EvoHeat controller. https://www.youtube.com/channel/UCfYiOxHuybBuC1NZcqUnrcA Updated: Dec 2019 CS Owner’s Manual Page: 2...
  • Page 3 CONTROLLER USAGE & OPERATION Updated: Dec 2019 Page: 3 CS Owner’s Manual...
  • Page 4 USAGE OF WIRE CONTROLLER Updated: Dec 2019 Page: 4 CS Owner’s Manual...
  • Page 5 STARTING & SHUTTING DOWN Updated: Dec 2019 Page: 5 CS Owner’s Manual...
  • Page 6 SWITCHING MODES SYSTEM STATE CHECKING Updated: Dec 2019 Page: 6 CS Owner’s Manual...
  • Page 7 CHANGING TEMPERATURE CLOCK SETTING Updated: Dec 2019 Page: 7 CS Owner’s Manual...
  • Page 8 Press" 'f :o sel r ct needing param Hour bit flashing Date: 31/01/2011 Date: 31/0 /2011 Press" Time: : 55 ITime 05. 55 � � Week: Thursday Week: Thursday � � Timer Timer Date format _e..fo+.m � •�;=: Press" l Hour bit flashing Minute bit flashing or"...
  • Page 9 Follow: TIMER SETTING Updated: Dec 2019 Page: 9 CS Owner’s Manual...
  • Page 10 Press " � " to enter Timer setting interface Hour bit flashing Timer1 :00:00-00:001 Timer1 :[ �:00-00:00 Press '\, " � < Timer2:00:00-00:00 Timer2:00:00-00:00 ► "f "f � � Timer3:00:00-00:00 Timer3:00:00-00:00 Timer4:00:00-00:00 Timer4:00:00-00:00 � ; ., � � < ,..,;=: �...
  • Page 11 "+ Press "� Timer1 :07:30-22:00 I Timer zone Ti mer2 :00:00-00:00 Press "e ) ' Daily timer Timer3:00:00-00:00 ► o back to upp r Timer4:00:00-00:00 interface Press " e ) ' to back to � upper interfac Date: 31/01/2011 ON: Cooling Press ..
  • Page 12 " Press Timer zone Press "�" Mon.:Timer1 IDaili '. timer Tue.: Timer1+ Timer3 Wed.: ON �o enter � , Thu.: Timer3+ Timer1 � � "Daily time Fri.: Timer4 Sat.: Timer2+ Timer4 � Sun.: � \® Press "'f' Flashing 1 t' Mon.:Timer1 Mon.:T imer1...
  • Page 13 Press "e)' to back to upper interface • Date: 31/01/2011 Timer zone Press ' e) " Time: 05: 55 Daily timer Week: Thursday � to back to Timer ► Date format upper interface � Press "e) " to back to upper interface •...
  • Page 14 C. Temperature timing settings ON: Cooling 5ate, 31/01/20111 Press "ij" Time: 05: 55 � Inlet tem p 25.0'C Week: Thursday ► Outlet tem p � � 25.0'C to enter cloc, Timer Date format interface 31/01/2011 06:55 THU. � ..� "...
  • Page 15 " 1 Press " A or " Y " e) A Timer 1 set temp. 5.0'C Timer 1 set temp. 5.0'C Press "�" Timer 2 set temp. 5.0'C Timer 2 set tern 5.0'C � Timer 3 set temp. 19.0'CI !Timer 3 set tern:. 9.o-cl Timer 4 set temp.
  • Page 16 KEYBOARD LOCK MALFUNCTION DISPLAY MEANING DEFAULT REMARKS Set-point of cooling target temp. 27 degrees Adjustable Set-point of heating target temp. 27 degrees Adjustable Set-point of auto mode target temp. 27 degrees Adjustable Updated: Dec 2019 Page: 16 CS Owner’s Manual...
  • Page 17 WATER OUT temp is higher than the WATER IN temp. Check also the INLET WATER TEMP is lower than the HEAT TEMP set point. If the gauge shows less than 0.8MPA contact EvoHeat tech support to check the refrigerant system. Example of normal...

  • Page 18: Drainage & Condensation

    If the water has no chlorine then it is condensation and is it normal – see drainage and condensation for more information. If the water has chlorine, it is a water leak and you need to contact EvoHeat tech support on 1300 859 933.
  • Page 19 ERROR CODES CODE FAILURE REASON SOLUTION Power on Normal working Inlet temp. sensor failure The temp sensor is broken or Check or change the temp. sensor short circuit Outlet temp. sensor failure The temp sensor is broken or Check or change the temp. sensor short circuit Ambient temp.
  • Page 20 ERROR CODES - CONTINUED SOLUTION CODE FAILURE REASON SOLUTION Low pressure 4 protection The high-pressure switch is Check the pressure switch and cold circuit broken Water flow failure No water/little water in water Check the pip water flow and water pump system Electrical-heat over heat failure Electrical-heat is over heat...

  • Page 21: Maintenance

    DO I NEED TO GET MY UNIT SERVICED? It is recommended that you get your EvoHeat unit serviced once a year by your local certified air conditioning or refrigeration technician. If your unit is located in a coastal area, more frequent maintenance may be necessary.

  • Page 22: Energy Saving Tips

    ENERGY SAVING TIPS If your pool water is allowed to cool significantly, it may take several days to return to the desired swimming temperature. For weekend use, it is more economical to maintain the pool water temperature at or near your desired swimming temperature.

  • Page 23: Warranty Details

    WARRANTY EVOHEAT HEAT PUMP WARRANTY 1. The titanium heat exchanger tubing is guaranteed against corrosion for a period OF TWENTY five (25) years from the date of purchase when used with chlorine, salt, bromine or sea water. (*25 year warranty on the titanium heat exchanger is valid for Evo heat pumps purchased post 15.05.2018.
  • Page 24 Postcode: * _______________________________________________________________________ State: * _________________________________________________________________________ Email: * _________________________________________________________________________ Please tell us about which EvoHeat product you bought, who you bought it from and what you will be using it for. Product & Model: *_________________________________________________________________ Serial Number:* ____________________________________________________________________ Authorised Installer:* _______________________________________________________________...

  • Page 25: Cautions And Warnings

    CAUTIONS & WARNINGS The unit can only be repaired by qualified personnel or an authorised dealer. This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
