- Page 1 Hero Series Manual Inverter Air Source Water Heat Pump Floor heating and Air-con Unit Installation and Instruction Manual...
-
Page 2: Table Of Contents
CONTENT 1 Preface 2 Safety Precaution (1) Mark notes (2) Icon Notes (3) Warning (4) Attention 3 Specification (1) Nomenclature of the heat pump (2) Appearance and Structure of the heat pump (3) Specification data (4) Unit Dimension 4 Installation (1) Application of heat pump (2) Choose a right heat pump unit (3) Installation place... -
Page 3: Preface
Preface In order to provide the customers with high quality, strong reliability and good versatility product, this heat pump is produced by strict design and manufacture standards. This manual includes all the necessary information about installation, debugging, discharging and maintenance. Please read this manual carefully before you open or maintain the unit. -
Page 4: Safety Precaution
Safety Precaution To prevent the users and others from the harm of this unit, and avoid damage on the unit or other property, and use the heat pump properly, please read this manual carefully and understand the following information correctly. Mark Notes Meaning Mark... -
Page 5: Warning
Safety Precaution Warning 安装前注意事项 Meaning Installation The heat pump must be installed by qualified personals, to avoid improper installation which can lead to water Professional installer leakage, electrical shock or fire. is required. Please make sure that the unit and power connection have good earthing, otherwise may cause electrical shock. -
Page 6: Attention
Safety Precaution ATTENTION 安装前注意事项 Meaning Installation The unit CANNOT be installed near the flammable gas. Once there is any leakage of the gas, fire can be occur. Installation Place Make sure that the basement of the heat pump is strong enough, to avoid any decline or fall down of the unit Fix the unit Make sure that there is circuit breaker for the unit, lack of... -
Page 7: Specification
Specification 1. Appearance and Structure of the heat pump H15A Air outlet in horizontal direction Water outlet tube Water intlet tube Remote Controller (Manually) The longest distance of installing the remote controller is 200 meters. Remote Controller (Manually) Air outlet in horizontal direction The longest distance of installing the remote controller is 200 meters. -
Page 8: Specification Data
Specification 2. The data of unit Model H15A Cooling Capacity BTU/h 34000 23800 Heating Capacity BTU/h 51000 30600 Electric Heating Power Cooling Power Input Heating Power Input Operation Electric Current(cooling/heating) 14.1/14.1 11.8/11.8 Cooling Capacity Range 6.0～15.0 2.0～10 Heating Capacity Range 6.0～18.0 2.5～11.5 Cooling Power Input Range... -
Page 9: Unit Dimension
Specification Unit dimension Models: H15 A Water outlet 1 1/4'' Condensate outlet 1 1/4'' Water pump wire Water inlet 1 1/4'' Water outlet 3/4'' 51.5 266.5 1000 Models: Water outlet 1'' Water inlet 1'' 465 440... -
Page 10: Installation
Installation Unit features 1. Plate heat exchanger Use the SWEP efficient heat exchanger with small size and high efficiency. 2.Environmentally friendly refrigerant Use the new generation of environmentally friendly refrigerant R410, which is harmless to the ozone sphere. 3. Heating in frigid environment. Optimized designed unit can achieve the heating function normally even when the ambient temperature is -15℃. -
Page 11: Choose A Right Heat Pump Unit
Installation Choose a right heat pump unit 2.1 Based on the local climate condition, construction features and insulation level, calculate the required cooling(heating) capacity per square meter. 2.2 Conclude the total capacity which will be needed by the construction. 2.3 According to the total capacity needed, choose the right model by consulting the heat. pump features as below: Heat pump features ℃... -
Page 12: Water Loop Connection
Installation 5 Water loop connection Please pay attention to below matters when the water pipe is connected: Try to reduce the resistance to the water from the piping. The piping must be clear and free from dirty and blocks. Water leakage test must be carried out to ensure there is no water leaking. -
Page 13: Transit
Installation 8 Transit When the unit need to be hung up during installation, a 8 meters cable is needed, and there must be soft material between the cable and the unit to prevent damage to the heat pump cabinet. (See picture 1) Picture 1 WARNING DO NOT touch the heat exchanger of the heat pump with fingers or other objects！... -
Page 14: Usage
Usage 1.Interface 2.Function and Display Icon Icon Key name Key functions Long press "Mode", to switch between cooling Mode and heating Fan Speed Short press "Fan Speed", to enter the Query interface In OFF state, long press "ON/OFF", to enter the Startup interface On/Off In ON state, long press "ON/OFF", to enter the Shutdown interface Short press "UP", to modify the temperature or clock... - Page 15 Usage Icon Key name Key functions Inlet Inlet icon Outlet icon Outlet When the compressor starts up, in the main display area, thecompressor status icon is on, and when Compressor the compressor shuts down, the icon is off. When the Pump starts up, in the main display area, the Pump status icon is on, and when the Pump shuts down, Pump the icon is off.
-
Page 16: Usage Of Wire Controller
Usage 3.Usage Of Wire Controller 3.1 Startup & Shutdown Long press for For 1 minute without second to operation, screen out enter the Startup interface Long press for Short press any key, second to back to the Startup enter the Shutdown interface interface Note: the Startup &... - Page 17 Usage 3.3 Temperature Set temperature flashing Short press enter thetemperature setting interface Short press , back and save Note: In the temperature setting interface, for 20 seconds without operation, the system will automatically record the setting, and back to the main interface. 3.4 State parameter query Short press to enter the Query interface;...
- Page 18 Usage 3.5 State query list: State Name State No Inlet Temperature Outlet Temperature Suction Temperature Discharge Temperature Ambient Temperature Coil Temperature Low Pressure High Pressure Electronic Expansion Valve Steps Compressor Actual Frequency Compressor Setting Frequency Suction gas Superheating/10 Discharge gas Superheating Fan 1 Set Speed Fan 2 Set Speed...
- Page 19 Usage 3.6 Clock Setting 3.6.1 Time Setting Short press Long press for flashing by at the same time for the hour two seconds Short press to change flashing Short press by the hour back to the main interface Short press Short press to change flashing for flashing by...
-
Page 20: Error Interface
Usage 4 Error Interface 4.1 Interface Error Code Error No. Error Quantiy Note: 1）. On the Error Interface, short press "ON/OFF", back to the main interface, and short press "UP" or "DOWN" to display multiple errors. On the main interface, short press "ON/OFF" to back to the Error Interface. For 10 seconds without operation, automatically back to the Error Interface. -
Page 21: Electronic Control Error Table
Usage 5 Electronic Control Error Table We can use Error Code to find the cause and the solution. Error Code Protection/Error None Standby None Normal Startup Inlet Temperature Error Outlet Temperature Error Ambient Temperature Suction Temperature Error Discharge Temperature Error Low Pressure Sensor Erro High Pressure Sensor Erro High Pressure Protection... -
Page 22: Controller Interfaces And Definitions
Usage 6 Controller interfaces and definitions Main board interfaces PC8002 485_B 485_A CAN_H 485_A CAN_L 485_B... - Page 23 Usage Instruction Instruction Main board Main board Power Null Wire DI 01 High voltage switch input Power Live Wire DI 02 Low voltage switch input Flow switch input DI 03 RO 01 Not Used DI 04 Emergency switch input RO 02 Pump DI 05 4-way valve...
-
Page 24: Maintenance
Form of Troubleshooting A. Form of Troubleshooting Fault Way of troubleshooting Protection/fault Cause display Standby Normal booting Water inlet temp sensor is in open Check and replace temp. sensor Water inlet temp. sensor error circuit or short circuit Water outlet temp sensor is in Check and replace temp. -
Page 25: Failure And Solution
Form of Troubleshooting B. Or make judgment and troubleshooting by reference to the following form Failure Solutions Possible causes for the failure 1 shut off the power and check power supply; Heat pump 1 Wrong power supply 2 check power cable and make right connection 2 power supply cable loose cannot 3 check for the cause and replace the fuse or... -
Page 26: Appendix (1) Appendix
Appendix Appendix 1 Install sketch map Especial installation（ expandable water tank） automatic Pressure fill-water leakage valve valve Technical request： 1.Each connection must be connected tightly and have no leakage. 2.the arrowhead orientation of automatic filled- water must accord with water supply. 3.The pressure of automatic filled-water has been set,and please do not remove screw. -
Page 27: Appendix 2
Appendix Appendix 2： The installation explanation of automatic filled-water When automatic filled-water valve is installed,the arrowhead orientation of inlet water must accord with the orientation of valve ; 2 Automatic filled-water has been adjusted in advance to 1.5bar； 3 If readjust the pressure of inlet water,please operate as follows： * open the screw cap（C）；... -
Page 28: Appendix
Appendix Appendix 3： The installation explanation of the leakage pressure valve. 1 The action pressure of leakage pressure valve 'is more than 3bar(valve is open)， but the pressure can not be adjusted. 2 The valve will open automatically to make sure that the water loop of air-con system is safe when the water pressure in the backwater side is higher than the set pressure. -
Page 29: Appendix
Appendix Appendix 5、 Ways of connection to remote controller The following ways of connection to control system are optional based on user demand: A. Simultaneously connect remote controller and networking interface: PC8002 Remote controller WiFi module Note: 1、In the mode of unit operation, it is necessary to complete value setting by remote controller. 2、It is advised to control equipment by mobile terminal after connection to WiFi module. -
Page 30: Appendix
Appendix Appendix 6、 Caution & Warning 1. The unit can only be repaired by qualified installer centre personnel or an authorised dealer.（for Europe market） 2. This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 31: Appendix 7
Appendix Appendix 7、Cable specification 1. Single phase unit Nameplate Creepage protector Signal line maximum Phase line Earth line current No more 2×1.5mm 1.5mm 30mA less than 0.1 sec than 10A 2×2.5mm 2.5mm 30mA less than 0.1 sec 10~16A 2×4mm 30mA less than 0.1 sec 16 ~25A 2×6mm 6 mm... - Page 32 Code:20160612-0003...
