- Page 1 AIR SOURCE WATER HEAT PUMP HIGH TEMPERATURE UNITS Installation & Instruction Manual Polaris MT 70 Manual...
-
Page 2: Table Of Contents
CONTENT 1 Preface 2 Safety Precaution Marking Description Icon Description 2.3 Warning 2.4 Caution 3 Specification Performance Parameter List Outline Dimensional Drawing Unit Function Description 5 Installation Installation Space Installation Schematic Diagram Model Selection Selection of the Installation Position 5.5 Installation Mode Water Pipe Connection Electrical Wiring Moving... -
Page 3: Preface
1.Preface This manual includes all the necessary information about installation, debugging, discharging and maintenance. Please read this manual carefully before you open or maintain the unit. Read these operating and installation instructions carefully and keep them safe. Should the equipment change hands, pass these instructions to the subsequent owner. Pass them to the trained contractors for servicing purposes. -
Page 4: Safety Precaution
2.Safety Precaution To prevent the user himself or others from personal and property damage and ensure correct and safe use of the unit, please read the important contents described in this Manual carefully. Read the text with full understanding of the following contents (marking and icon), and follow the following precautions. 2.1 Marking Description Description Marking... -
Page 5: Warning
2.Safety Precaution 2.3 Warning Description Installation Warning Please entrust the professionals for installation. The installation by others may cause installation Entrust the professionals imperfections, resulting in water leakage, electric for installan shock or fire. Verify whether the grounding is proper. Improper grounding may cause electric shock. -
Page 6: Caution
2.Safety Precautions 2.4 Caution Do not install it in a place where flammable gas leak easily occurs. Verify the Once the flammable gas leaks and stays around the installation site outdoor unit, this may cause a fire. Installation precaution Verify whether the installation base is solid. If the base is not solid, the outdoor unit may fall and then result in accidents. -
Page 7: Specification
3.Specification 3.1 Performance Parameter List Unit Model ALLHT1170R134 Heating Output 117.0 Recycled-heating Power Input 37.5 Running Current 70.0 Power Supply 380V/3N～/50Hz Compressor Quantity Scroll Compressor Type Refrigerant Type R134a Fan Quantity Fan power input 2000×2 Fan speed Noise dB(A) Water pipe connection DN80 (Subject to drawings of the heat pump) Unit dimension (L/W/H) -
Page 8: Outline Dimensional Drawing
3.Specification 3.2 Outline Dimensional Drawing Models: ALLHT1170R134 Air-out direction Water outlet DN80 flange Water inlet DN80 flange 2180 Electrical control box 4-Φ16 Installation Bottom Outlet... -
Page 9: Unit Function Description
4.Unit Function Description Heating capacity The unit absorb energy from outside and release the heat according to the heat exchanger, if the environment temperature is low, the heating capacity will be attenuation. 3 minutes protection When the unit stop, if you restart the unit or turn on the manual switch, the unit will not run in 3 minutes, it's the protection for the compressor. -
Page 10: Installation
5.Installation 5.1Installation Space Schematic Diagram of Unit Dimensions Installation Position Outline Dimensional Drawing - Parallel Units Air-out direction L(mm) L(mm) L(mm) Maintenance space above 1800mm Parallel Mode Double- Unit spacing above 1500mm 2180 3160 2030 connected unit Maintenance space above 1500mm Tripartite- 5240 2180... -
Page 11: Model Selection
5.Installation 5.3 Model Selection (1)Make comprehensive consideration of the required refrigerating (heating) capacity per unit area according to climatic conditions, building use and heat preservation; (2)Calculate the total load according to the unit load and the total area; (3)Select the appropriate unit based on the total load and the application scope of the unit. (4)Application occasions: 5.4Selection of the Installation Position The unit can be installed on balconies, roofs, floors, or any other places easy to install... -
Page 12: Installation Mode
5.Installation 5.5 Installation Mode The unit is directly secured to the cement base with the expansion bolts. Use channel steel to make the installation base, place shockproof rubber pads on the ground or the roof, and ensure that the unit is placed levelly. Figure 1 Installation Schematic Diagram of Snow Shed Air-out direction Caution... -
Page 13: Water Pipe Connection
5.Installation 5.6 Water Pipe Connection Note the following items during connection of water inlet and outlet pipes: Minimize the resistance of the water pipe outside the unit. The entire piping system should be clean and free of dirt and rust to prevent pipe clogging. - Page 14 5.Installation Three-core signal line Power cablee Model 576S-V 3×0.5mm 3×16mm +2×25mm (R,S,T,N, ground) Notes: （1） The unit uses the three-phase power supply, and the cable specification in the table above refers to the cable specification of each phase. （1）Both the neutral line and the ground line use the 4mm cables, and both the three-core signal line and the defrosting coordination line use the 0.5mm wires.
-
Page 15: Moving
5.Installation 5.8 Moving When lifting is needed, use four sling wires longer than 8m for lifting; during the lifting, use the special lifting hole (hook) on the unit base. Pads shall be provided at the contact between the housing and the sling to prevent the damage to the housing, as shown in Figure 2. - Page 16 5.Installation 5.9.2 Trial Operation Turn on the machine with on the remote controller, and then immediately check whether the water pump operates normally; if it is normal, observe the water flow switch and the water pressure gauge of the water system: when the water flow switch is in the ON state, the water pressure gauge shall show the water pressure of about 0.2MPa.
-
Page 17: Usage
6.Usage 6.1 Function of wire controller Welcome V1.0 v1.0 Loading..Button Name Function Press this button to start up/shut off the unit, ON/OFF cancel current operation or back to upper interface. Press this button to check button function HELP or system state. Press this button to confirm current operation. -
Page 18: Usage Of Wire Controller
6.Usage 6.2 Usage of wire controller 6.2.1 The way to use You can use “ ”at any interface, it will show relevant button function of current interface. You can press “ ”to exit the "help" interface. For example： Press “ ”at main interface, system will show all button function;... - Page 19 6.Usage Press “ ”at clock interface, the screen shows as follow: Both are OK when system shows ON or OFF ON：Heating Date： 20/07/2016 ” Press“ Time： 08：40 Inlet temp.: 35.0℃ to enter Week： Monday Outlet temp.: 65.0℃ Timer Date format 2016/07/20 08:40 MON.
- Page 20 6.Usage 6.2.3 The operation of system state ”twice, press“ ” At any interface, you can enter system working state by pressing“ （pageup）or “ ”（pagedown）to select the needing parameter, press“ ”to enter, and press “ ”to exit. For example： ON：Heating Pressing this key could turn ”...
- Page 21 6.Usage 6.2.4 The operation of parameter At main interface, press“ ”or“ ”to enter parameter setting interface, press “ ”（increasing）or“ ”（decreasing）can change parameter value, press“ ”to save the setting and exit . Press“ ”can not save the setting but exit.（You can refer to parameter table to set relevant temperature.）...
- Page 22 6.Usage Press“ ”to select needing parameter Hour bit flashing Date： 16/07/2016 Date： 16/07/2016 Time： 05：55 Press“ ” Time： 05：55 Week： Thursday Week： Thursday Timer Timer Date format Date format Press“ ” Hour bit flashing or“ ” Minute bit flashing Date： 16/07/2016 Date：...
- Page 23 6.Usage Hour bit flashing Date： 16/07/2016 ON：Heating No operation Time： 06：55 in 10s Inlet temp.: 35.0℃ Week： Thursday Outlet temp.: 65.0℃ Timer Date format 2015/07/20 06:55 MON. It has been changed 6.2.6 The operation of timer You can set four timer on and timer off according to you needing. At main interface, press “...
- Page 24 6.Usage ” Press“ to enter Timer setting interface Hour bit flashing Timer1:00:00-00:00 Timer1:00:00-00:00 ” Press“ Timer2:00:00-00:00 Timer2:00:00-00:00 Timer3:00:00-00:00 Timer3:00:00-00:00 Timer4:00:00-00:00 Timer4:00:00-00:00 ” Press“ Minute bit flashing ” Hour bit flashing or“ Timer1:07:00-00:00 Timer1:07:00-00:00 ” Timer2:00:00-00:00 Timer2:00:00-00:00 Press“ Timer3:00:00-00:00 Timer3:00:00-00:00 Timer4:00:00-00:00 Timer4:00:00-00:00 ”...
- Page 25 6.Usage ” Press“ Timer1:07:30-22:00 Timer zone ” Timer2:00:00-00:00 Press“ Daily timer Timer3:00:00-00:00 to back to upper Timer4:00:00-00:00 interface ” Press“ to back to upper interface Date： 16/07/2016 ON：Heating Time： 05：55 ” Press“ Inlet temp.: 35.0℃ Week： Thursday Outlet temp.: 65.0℃ to back to Timer upper interface...
- Page 26 6.Usage ” Press“ Mon.:Timer1 ” Timer zone Tue.: Timer1+ Timer3 Press“ Wed.: ON Daily timer Thu.: Timer3+ Timer1 to enter Fri.: Timer4 Sat.: Timer2+ Timer4 “Daily timer ” Sun.: OFF ” Press“ Flashing Mon.:Timer1 Mon.:Timer1 Tue.: Timer1+ Timer3 Tue.: Timer1+ Timer3 ”...
- Page 27 6.Usage ” Press“ to back to upper interface Date： 20/07/2016 Timer zone ” Press“ Time： 05：55 Daily timer Week： Monday to back to Timer Date format upper interface ” Press“ to back to upper interface ON：Heating Inlet temp.: 35.0℃ Outlet temp.: 65.0℃...
- Page 28 6.Usage 6.2.7 Keyboard lock To avoid mis-operations, please lock the controller after parameter setting. At the main interface, pressing “ ”for 5 seconds，the keyboard will be locked. ”for 5 seconds, the keyboard will be unlocked. When the keyboard is locked, pressing“ Locked ON：Heating ON：Heating...
-
Page 29: Maintenance And Inspection
7.Maintenance and inspection 7.1 Malfunction table You can refer to the malfunction table to find out the failure cause and solution. Malfunction Display Resolution Reason Power on Normal working The temp. Sensor is broken or Inlet temp. Sensor failure Check or change the temp. Sensor short circuit The temp. -
Page 30: Appendix
8.Appendix 8.1 Connection of PCB illustration PC8001 Connections explanation： Meaning Symbol Meaning Symbol Live line System protection signal DI11 Null line Water input temperature input AI 01 Compressor 1 output(220VAC) RO 01 AI 02 Water output temperature output Compressor 2 output(220VAC) RO 02 System 1 fan coil temperature input AI 03... - Page 31 8.Appendix . Connection of PCB illustration CC04 RO04 CC03 RO03 CC02 RO02 CC01 RO01 RLY4 RLY3 RLY2 RLY1 BHB10 Connections explanation： Symbol Meaning System1 mangtic valve outlet（220-230VAC） RO01 System2 mangtic valve outlet（220-230VAC） RO02 System1 alert outlet（220-230VAC） RO03 System2 alert outlet（220-230VAC） RO04 System1 mangtic valve inlet（220-230VAC）...
-
Page 32: Caution & Warning
8.Appendix 8.2 Caution & Warning 1. The unit can only be repaired by qualified installer centre personnel or an authorised dealer.（for Europe market） 2. This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 33: Appendix
8.Appendix 8.3Appendix 9 (1) Caution & Warning 1. The unit can only be repaired by qualified installer centre personnel or an authorised dealer.（for Europe market） 2. This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 34 8.Appendix (2) Cable specification 1. Single phase unit Nameplate Creepage protector Signal line maximum Phase line Earth line current No more 2×1.5mm 1.5mm 30mA less than 0.1 sec than 10A 2.5mm 30mA less than 0.1 sec 10~16A 2×2.5mm 30mA less than 0.1 sec 16 ~25A 2×4mm 6 mm...
- Page 35 Note:...
- Page 36 Code :20170803-0003...
