- Page 1 CS Installation Manual Updated: June 2019 Page: 1...
-
Page 2: Table Of Contents
EvoHeat heat pump themselves. Heater electrical installation undertaken by an unlicensed installer will void the warranty. Installation of your EVOHEAT heat pump must be in accordance with the procedures in the product manual. Always check that your installation will comply with local building and council regulations. - Page 3 CS RANGE DIMENSIONS CS38, CS47 & CS57 Updated: Dec 2019 CS Installation Manual Page: 3...
- Page 4 CS-GEN2 DIMENSIONS CS95- GEN2 CS120-GEN2 & CS145-GEN2 CS200-GEN2 Updated: Dec 2019 CS Installation Manual Page: 4...
-
Page 5: Prior To Installation
It is CRITICAL that there is sufficient water flow to the unit. Incorrect water flow can cause a loss of efficiency and possible damage to the unit. Optimal water flow rates are listed in the EvoHeat brochure and tech data sheets. It is imperative that water flow is kept as close as possible to these flow rates. -
Page 6: Installation & Connection Diagrams
RUBBER FEET EvoHeat highly recommend that the rubber feet are installed – the rubber feet help reduce vibration of the unit. General installation information disclaimer: Install your EVOHEAT heat pump in accordance with the procedures in the product manual. -
Page 7: Installation Requirements
4. Adequate water flow 1. LOCATION & MINIMUM CLEARANCES RECOMMENDATIONS EvoHeat recommend the heat pump should ONLY be installed in an outdoor location with appropriate ventilation. Installing the heater indoors without adequate ventilation, or in a poorly ventilated enclosed space, will result in very poor performance and can, in extreme cases, damage the heater. - Page 8 Leave sufficient space for servicing the units, ensure the service doors can be easily accessed by the service technician. If you do not have a location with these suggested clearances, please contact our EvoHeat Tech Support Specialist to discuss appropriate installation locations.
- Page 9 Correct phase connection is important with 3 phase heaters. NOTE: if 2 lights are showing on the 3 PHASE relay monitor this means the EvoHeat heat pump has been wired correctly (one orange light and one green light). If only one light is showing, the phases are out of rotation and need to be rotated to get the correct phase rotation.
-
Page 10: Water Pump Connection
WATER PUMP CONNECTION IMPORTANT: A Variable speed pump or bypass valve and plumbing MUST be fitted to allow water flow to be adjusted through the heater. Do not direct connect a water pump with higher flow than required to the heat pump. -
Page 11: Remote Controller Connection
REMOTE CONTROLLER CONNECTION All Evo heaters can be controlled remotely by any device capable of opening and closing a circuit. The circuit must be low voltage 5V or lower. Remove the cable loop noted on the wiring diagram on the PCB and connect the remote cable from the external controller into these terminals –... -
Page 12: Time Delay
INITIAL START UP OF THE UNIT NOTE: In order for the unit to heat the pool or spa, the filter pump must be running to circulate water through the heat exchanger. START-UP PROCEDURE After installation is completed, follow the steps below: 1. -
Page 13: Cable Specifications
CABLE SPECIFICATIONS If the unit is to be installed outdoors, ensure that a cable is used which has protection against UV. Updated: Dec 2019 CS Installation Manual Page: 13... -
Page 21: Cautions & Warnings
CAUTIONS & WARNINGS The unit can only be repaired by qualified personnel or an authorised dealer. This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
