Nidec RINDCODE NRX Series Instruction Manual page 10

3-3 Oil filling and draining
■ Never mix different types of oil. Failure to follow this could result in adverse effect due to the change in oil quality.
■ Oil leakage could result in accidents. Wipe away oil spills at the time of filling or draining.
[ For the speed change section ]
■ Add oil up to the specified level of the oil gauge when the speed drive stops.
Note : Continuing operation with insufficient oil could result in damage to internal parts.
Check the oil level every day.
Horizontal
type
Lubrication level
(when the unit stops)
Vertical
type
(200B, 400B, 750, 11K, or larger models)
Note : For the vertical type, be sure to set the unit vertically before adding oil. If oil
is added with the unit placed horizontally, the amount of oil will differ, and proper
lubrication management cannot be performed. If oil has been added excessively, remove
the drain plug, and drain out surplus oil to adjust the amount.
Note : Before adding oil in the vertical type of models 200B to 1500, be sure to remove the attached pressure relief plug for lubrication, which can be used to release the internal air pressure.
After adding oil, attach the pressure relief plug.
3-4 Proper amount of oil, and oil filling/draining plug positions
NRX □ (L)
Horizontal type Vertical type
Model
Speed change Speed change
section section
200B 0.2 0.4
400B 0.2 0.4
750 0.5 1.0
1500 0.8 1.9
2200 1.8 2.7
3700 2.5 4.8
5500 2.8 5.4
7500 2.2 5.4
11K 5.0 15
15K 5.0 15
18K 5.0 15
NRX □ - □ -G □ Planetary/Pinion reducer (L)
Horizontal type
Reduction
Speed
Model
ratio
change
section
200B G3M/G5M 0.2
400B G3M/G5M 0.2
750 G3/6 0.5
1500 G3/6 0.8
2200 G3/6 1.8
3700 G3/6 2.5
5500 G3/6 2.8
7500 G3/6 2.2
11K G3/5 5.0
15K G3/5 5.0
18K G3/5 5.0
Horizontal
SC・O Lubrication level
type N・RX
(when the unit stops)
Vertical
Lubrication level
type
(when the unit stops)
(1500 to 7500)
Pressure relief plug for lubrication(200B to 1500)
Oil filling port
Oil filling port
Oil gauge
Oil drain port
200B to 7500
Vertical type
Speed Speed Speed
reduction change reduction
section section section
Grease 0.4 Grease
Grease 0.4 Grease
0.4 1.0 0.4
0.5 1.9 0.8
1.0 2.7 1.3
1.5 4.8 2.3
1.8 6.5 3.5
1.8 6.5 3.5
9.0 15 18.2
9.0 15 18.2
9.0 15 18.2
[For the speed reduction section]
■ The plug position in the center of the speed reduction section indicates
the proper oil level. Remove the upper lubrication plug and level plug, and
fill with oil until oil flows out of the level plug.
Oil filling port
Level plug
Drain plug
(with the CORONET reducer)
(with the planetary
reducer)
■ For the grease lubricated system <Frame A/B/C of N(G)11 to 71>,
additional refill is not required in the middle of the replacement interval.
When replacing oil, disassemble the unit for overhaul before lubrication.
Oil drain port
Oil drain port
Oil gauge
Oil filling port in
the speed change
Oil filling port
section
in the speed
reduction section
Oil gauge
Oil level
Oil drain port in the speed
change section
Oil drain port in the
speed reduction section
Oil filling port in the
speed change section
Oil filling port in the
speed reduction section
Oil gauge
Oil drain port in the
speed change section
Oil gauge
Oil drain port in the
Oil drain port in the
speed reduction section
speed reduction section
Model 11K, 15K, 18K
9
Tube type oil gauge
Oil filling port
(The band position
indicates the proper
Level plug
Drain plug Drain plug
(with the worm reducer)
Oil filling port
Oil filling port
Oil gauge
Oil drain port
Model 11K, 15K, 18K
Pressure relief plug for
lubrication(200B to 1500)
Oil filling port in the
speed change section
Oil drain port
in the speed
change
section
Oil drain port in the Oil level
speed reduction section
200B to 7500
Oil filling port in the
speed change section
speed reduction section
Oil drain port in the
speed change section
Oil filling
port
oil level)
Drain plug
(with the inscribed
planetary reducer)
Oil gauge
Oil gauge
Oil filling port in the speed
reduction section
Oil gauge
Oil filling port in the
Oil gauge
