How the Plasma Power Supply Operates
Figure 43 – 380 V CCC / 400 V CE plasma power supply (power PCB removed)
1
2
1 Output bridge diode
2 Pilot arc IGBT
3 Inverter snubber resistor
4 Inverter IGBT module
5 Bulk capacitors
162
10 9
3
4
810430
5
6 Input diode bridge
7 Ground
8 Power switch (S1)
9 Output snubber resistor
10 Optional serial PCB
