Removal and replacement procedures

Required tools

You need the following items for some procedures:
•
T-15 Torx screwdriver
•
Diagnostics Utility

Safety considerations

Before performing service procedures, review all the safety information.

Preventing electrostatic discharge

To prevent damaging the system, be aware of the precautions you need to follow when setting up the
system or handling parts. A discharge of static electricity from a finger or other conductor may damage
system boards or other static-sensitive devices. This type of damage may reduce the life expectancy of the
device.
To prevent electrostatic damage:
•
Avoid hand contact by transporting and storing products in static-safe containers.
•
Keep electrostatic-sensitive parts in their containers until they arrive at static-free workstations.
•
Place parts on a grounded surface before removing them from their containers.
•
Avoid touching pins, leads, or circuitry.
•
Always be properly grounded when touching a static-sensitive component or assembly.

Workstation blade warnings and cautions

WARNING:
remove the workstation blade access panel and then install the workstation blade into the
enclosure.
WARNING:
internal system components to cool before touching them.
CAUTION:
the workstation blade in this manner results in improper airflow and improper cooling that can
lead to thermal damage.
To reduce the risk of shock or injury from high-current electrical energy, do not
To reduce the risk of personal injury from hot surfaces, allow the drives and the
Do not operate the workstation blade with the access panel removed. Operating
