The contents of this manual are important and must be kept in close proximity of the UniNet™ Facilities Monitoring
System. If building ownership is changed, this manual and all other testing and maintenance information must also
be passed to the current owner of the facility. A copy of this manual was shipped with the equipment and is also
available from the manufacturer.
NFPA Standards
•
National Fire Protection Association Standards 72 (NFPA 72).
•
National Electric Code (NFPA 70).
•
Life Safety Code (NFPA 101).
Underwriters Laboratories U.S. Documents
•
UL-864 Control Units for Fire Protective Signaling Systems (Ancillary monitoring only).
Other
•
Requirements of the Local Authority Having Jurisdiction (LAHJ).
WARNING:
WARNING:
WARNING:
WARNING:
WARNING: Improper installation, maintenance, and lack of routine testing could result in system malfunction.
The NION-Simplex 4010 is a plug-in component of the UniNet™ 2000 Workstation. It allows a workstation to
view events and other data originating from a Simplex 4010 panel.
UniNet™ consists of graphical workstations monitoring and controlling, local or remote twisted pair or fiber optic
networks. Remote network monitoring is achieved through the use of a Building Communications Interface (BCI).
A twisted pair network topology (FT-10) may be a maximum length of 6000 feet per network segment with no T-
taps, allowing communications between 64 nodes in each segment. In addition FT-10 allows dedicated runs of
8000 feet point-to-point or multiple T-taps within 1500 feet of any other node on the segment. Fiber optic cable is
another option and can be configured in either a bus or ring topology. The network has a maximum system
capacity of 200 nodes. The network is supervised for shorts, opens, and node failures, as dictated in Style 4, 6 and
7 wiring.
The network power is 24 VDC nominal and receives operating power from a power limited, filtered source listed for
use with fire protective signaling units.
Technical Manuals Online! - http://www.tech-man.com
Introduction
Network Installation M anual
Workstation
System Utilities
BCI ver. 3-3
Local Area Server
Related Documentation
Simplex 4010 NION Installation/Operation Manual Version 2 Document 51998 Rev. A1 03/26/03
firealarmresources.com
Foreword
51539
UniLogic
51540
AM2020/AFP1010 Instruction M anual
51592
51543
51544
UniNet Online
51547
52020
UniTour
51550
IRM/IM
51591
51994
